Beiträge von eukalyptus

**eukalyptus**

Hier hab ich ein Midi-In-Beispiel:
es werden 2 Buffer verwendet und die Daten via RegisterMsg empfangen (CALLBACK_WINDOW)

So lassen sich AutoIt Scripte relativ einfach über einen MIDI-Controller steuern.

Spoiler anzeigen

[autoit]

#include <GUIConstantsEx.au3>
#include <WinAPI.au3>
#include <MIDI.au3>

[/autoit] [autoit][/autoit] [autoit]

Opt("MustDeclareVars", 1)
Opt("GUIOnEventMode", 1)

[/autoit] [autoit][/autoit] [autoit]

Global $hGui = GUICreate("Midi In Example", 1000, 420)
GUISetOnEvent($GUI_EVENT_CLOSE, "_Exit")
Global $cCombo = GUICtrlCreateCombo("", 10, 10, 400, 20)
Global $cButton_Start = GUICtrlCreateButton("Start", 420, 10, 80, 20)
GUICtrlSetOnEvent(-1, "_Midi_Start")
Global $cButton_Stop = GUICtrlCreateButton("Stop", 510, 10, 80, 20)
GUICtrlSetOnEvent(-1, "_Midi_Stop")
GUICtrlCreateLabel("MIM_DATA", 10, 40, 100, 20)
Global $cEdit_Data = GUICtrlCreateEdit("", 10, 60, 485, 350)
GUICtrlCreateLabel("MIM_LONGDATA", 505, 40, 100, 20)
Global $cEdit_LongData = GUICtrlCreateEdit("", 505, 60, 485, 350)
GUISetState()

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

_Midi_Startup()
Global $tBuffer1 = _CreateBuffer()
Global $tBuffer2 = _CreateBuffer()
_GetDevices()

[/autoit] [autoit][/autoit] [autoit]

Global $hMidi = 0
Global $bRelease = False
Global $iDeviceCurrent = -1

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

GUIRegisterMsg($MM_MIM_CLOSE, "_MidiWinProc")
GUIRegisterMsg($MM_MIM_DATA, "_MidiWinProc")
GUIRegisterMsg($MM_MIM_ERROR, "_MidiWinProc")
GUIRegisterMsg($MM_MIM_LONGDATA, "_MidiWinProc")
GUIRegisterMsg($MM_MIM_LONGERROR, "_MidiWinProc")
GUIRegisterMsg($MM_MIM_MOREDATA, "_MidiWinProc")
GUIRegisterMsg($MM_MIM_OPEN, "_MidiWinProc")

[/autoit] [autoit][/autoit] [autoit]

While Sleep(100)
WEnd

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _ProcessLongData($pData, $iBytes)
Local $tGetData = DllStructCreate("byte[" & $iBytes & "];", $pData)
GUICtrlSetData($cEdit_LongData, DllStructGetData($tGetData, 1) & @CRLF, 1)
EndFunc ;==>_ProcessLongData

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _ProcessData($iMidiMessage)
Local $iLoWord = _WinAPI_LoWord($iMidiMessage)
Local $iHiWord = _WinAPI_HiWord($iMidiMessage)

[/autoit] [autoit][/autoit] [autoit]

Local $bStatus = BitAND($iLoWord, 0xFF) ;LoByte
Local $bData1 = BitShift($iLoWord, ;HiByte
Local $bData2 = BitAND($iHiWord, 0xFF) ;LoByte

[/autoit] [autoit][/autoit] [autoit]

Local $Chan = BitAND($bStatus, 0xF)
Local $MidiMsg = BitShift($bStatus, 4)

[/autoit] [autoit][/autoit] [autoit]

GUICtrlSetData($cEdit_Data, "StatusByte: " & $bStatus & @TAB & "DataByte1: " & $bData1 & @TAB & "DataByte2: " & $bData2 & @CRLF, 1)

[/autoit] [autoit][/autoit] [autoit]

Switch $MidiMsg

[/autoit] [autoit][/autoit] [autoit]

Case 0x8 ; Note Off
GUICtrlSetData($cEdit_Data, @TAB & "NoteOff: MidiChannel: " & $Chan & @TAB & "NoteNumber: " & $bData1 & @TAB & "Velocity: " & $bData2 & @CRLF, 1)

[/autoit] [autoit][/autoit] [autoit]

Case 0x9 ; Note On
GUICtrlSetData($cEdit_Data, @TAB & "NoteOn: MidiChannel: " & $Chan & @TAB & "NoteNumber: " & $bData1 & @TAB & "Velocity: " & $bData2 & @CRLF, 1)

[/autoit] [autoit][/autoit] [autoit]

Case 0xA ; Polyphonic aftertouch
GUICtrlSetData($cEdit_Data, @TAB & "Polyphonic aftertouch: MidiChannel: " & $Chan & @TAB & "NoteNumber: " & $bData1 & @TAB & "Poly Pressure: " & $bData2 & @CRLF, 1)

[/autoit] [autoit][/autoit] [autoit]

Case 0xB ; Control Change
GUICtrlSetData($cEdit_Data, @TAB & "Control Change: MidiChannel: " & $Chan & @TAB & "Controller: " & $bData1 & @TAB & "Value: " & $bData2 & @CRLF, 1)

[/autoit] [autoit][/autoit] [autoit]

Case 0xC ; Program Change
GUICtrlSetData($cEdit_Data, @TAB & "Program Change: MidiChannel: " & $Chan & @TAB & "Programm: " & $bData1 & @CRLF, 1)

[/autoit] [autoit][/autoit] [autoit]

Case 0xD ; Channel aftertouch
GUICtrlSetData($cEdit_Data, @TAB & "Channel aftertouch: MidiChannel: " & $Chan & @TAB & "Aftertouch : " & $bData1 & @CRLF, 1)

[/autoit] [autoit][/autoit] [autoit]

Case 0xE ; Pitch Bend
GUICtrlSetData($cEdit_Data, @TAB & "Pitch Bend: MidiChannel: " & $Chan & @TAB & "LSB: " & $bData1 & @TAB & "MSB: " & $bData2 & @CRLF, 1)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

EndSwitch

[/autoit] [autoit][/autoit] [autoit]

EndFunc ;==>_ProcessData

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _MidiWinProc($hWnd, $iMsg, $wParam, $lParam)
Switch $iMsg
Case $MIM_OPEN
ConsoleWrite("> MIM_OPEN" & @CRLF)

[/autoit] [autoit][/autoit] [autoit]

Case $MIM_CLOSE ;hMidi Handle ab jetzt ungültig
ConsoleWrite("> MIM_CLOSE" & @CRLF)
$hMidi = 0

[/autoit] [autoit][/autoit] [autoit]

Case $MIM_DATA ; Normale Midi MSG
ConsoleWrite("> MIM_DATA" & @CRLF)
_ProcessData($lParam)

[/autoit] [autoit][/autoit] [autoit]

Case $MIM_MOREDATA
ConsoleWrite("> MIM_MOREDATA" & @CRLF)

[/autoit] [autoit][/autoit] [autoit]

Case $MIM_LONGDATA
ConsoleWrite("> MIM_LONGDATA" & @CRLF)

[/autoit] [autoit][/autoit] [autoit]

Switch $bRelease
Case False ; SysEx Daten kommen rein
Local $tMidiHDR = DllStructCreate($MIDIHDR, $lParam)
Local $iBytesRecorded = DllStructGetData($tMidiHDR, "dwBytesRecorded")
ConsoleWrite("+ LONGDATA IN: " & $iBytesRecorded & " bytes" & @CRLF)

[/autoit] [autoit][/autoit] [autoit]

_ProcessLongData(DllStructGetData($tMidiHDR, "lpData"), $iBytesRecorded)

[/autoit] [autoit][/autoit] [autoit]

_MidiIn_AddBuffer($hMidi, $lParam, 48)

[/autoit] [autoit][/autoit] [autoit]

Case Else ; Druch _MidiIn_Reset wird hier der Buffer zurückgegeben und muss hier "unprepared" werden
ConsoleWrite("! Unprepare Buffer" & @CRLF)
_MidiIn_UnprepareHeader($hMidi, $lParam, 48)

[/autoit] [autoit][/autoit] [autoit]

EndSwitch

[/autoit] [autoit][/autoit] [autoit]

Case $MIM_ERROR
ConsoleWrite("> MIM_ERROR" & @CRLF)

[/autoit] [autoit][/autoit] [autoit]

Case $MIM_LONGERROR
ConsoleWrite("> MIM_LONGERROR" & @CRLF)
_MidiIn_AddBuffer($hMidi, $lParam, 48)

[/autoit] [autoit][/autoit] [autoit]

EndSwitch
EndFunc ;==>_MidiWinProc

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Midi_Start()
ConsoleWrite(@CRLF & "!=============================" & @CRLF)
ConsoleWrite("! starting..." & @CRLF & @CRLF)
Local $aRegExp = StringRegExp(GUICtrlRead($cCombo), "<(\d+)>", 3)
If @error Or Not IsArray($aRegExp) Then Return
Local $iDevice = $aRegExp[0]

[/autoit] [autoit][/autoit] [autoit]

If $iDevice = $iDeviceCurrent Then
ConsoleWrite("- already running" & @CRLF)
Return
EndIf

[/autoit] [autoit][/autoit] [autoit]

$bRelease = False

[/autoit] [autoit][/autoit] [autoit]

Local $iRet

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

If $hMidi <> 0 Then _Midi_Stop()
$hMidi = _MidiIn_Open($iDevice, $hGui, 0, BitOR($CALLBACK_WINDOW, $MIDI_IO_STATUS))
ConsoleWrite("! MidiIn Open: " & $hMidi & " error: " & @error & @CRLF)
$iDeviceCurrent = $iDevice

[/autoit] [autoit][/autoit] [autoit]

$iRet = _MidiIn_PrepareHeader($hMidi, DllStructGetPtr($tBuffer1, "lpData"), 48)
ConsoleWrite("! Prepare Header: " & $iRet & " error: " & @error & @CRLF)
$iRet = _MidiIn_PrepareHeader($hMidi, DllStructGetPtr($tBuffer2, "lpData"), 48)
ConsoleWrite("! Prepare Header: " & $iRet & " error: " & @error & @CRLF)

[/autoit] [autoit][/autoit] [autoit]

$iRet = _MidiIn_AddBuffer($hMidi, DllStructGetPtr($tBuffer2, "lpData"), 48)
ConsoleWrite("! Add Buffer: " & $iRet & " error: " & @error & @CRLF)
$iRet = _MidiIn_AddBuffer($hMidi, DllStructGetPtr($tBuffer1, "lpData"), 48)
ConsoleWrite("! Add Buffer: " & $iRet & " error: " & @error & @CRLF)

[/autoit] [autoit][/autoit] [autoit]

$iRet = _MidiIn_Start($hMidi)
ConsoleWrite("! MidiIn Start: " & $iRet & " error: " & @error & @CRLF)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

EndFunc ;==>_Midi_Start

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Midi_Stop()
ConsoleWrite(@CRLF & "!=============================" & @CRLF)
ConsoleWrite("! stopping..." & @CRLF & @CRLF)

[/autoit] [autoit][/autoit] [autoit]

$bRelease = True

[/autoit] [autoit][/autoit] [autoit]

Local $iRet
$iRet = _MidiIn_Reset($hMidi)
ConsoleWrite("! MidiIn Reset: " & $iRet & " error: " & @error & @CRLF)
$iRet = _MidiIn_Stop($hMidi)
ConsoleWrite("! MidiIn Stop: " & $iRet & " error: " & @error & @CRLF)
$iRet = _MidiIn_Close($hMidi)
ConsoleWrite("! MidiIn Close: " & $iRet & " error: " & @error & @CRLF)

[/autoit] [autoit][/autoit] [autoit]

$iDeviceCurrent = -1
EndFunc ;==>_Midi_Stop

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _GetDevices()
Local $tMidiInCaps = DllStructCreate($MIDIINCAPS)
Local $pMidiInCaps = DllStructGetPtr($tMidiInCaps)
Local $iMidiInCaps = DllStructGetSize($tMidiInCaps)

[/autoit] [autoit][/autoit] [autoit]

Local $iDeviceCnt = _MidiIn_GetNumDevs()
Local $sDevice = ""
Local $sDefault = ""

[/autoit] [autoit][/autoit] [autoit]

For $i = 0 To ($iDeviceCnt - 1)
_MidiIn_GetDevCaps($i, $pMidiInCaps, $iMidiInCaps)
$sDevice &= "<" & $i & "> " & DllStructGetData($tMidiInCaps, "szPname") & "|"
If $i = 0 Then $sDefault = "<" & $i & "> " & DllStructGetData($tMidiInCaps, "szPname")
Next

[/autoit] [autoit][/autoit] [autoit]

GUICtrlSetData($cCombo, $sDevice, $sDefault)
EndFunc ;==>_GetDevices

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _CreateBuffer($iSize = 256, $iID = 0)
Local $tBuffer = DllStructCreate("uint BufferSize; byte BufferData[" & $iSize & "];" & $MIDIHDR)

[/autoit] [autoit][/autoit] [autoit]

DllStructSetData($tBuffer, "BufferSize", $iSize)
DllStructSetData($tBuffer, "lpData", DllStructGetPtr($tBuffer, "BufferData"))
DllStructSetData($tBuffer, "dwBufferLength", $iSize)
DllStructSetData($tBuffer, "dwUser", $iID)

[/autoit] [autoit][/autoit] [autoit]

Return $tBuffer
EndFunc ;==>_CreateBuffer

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Exit()
Exit
EndFunc ;==>_Exit

[/autoit]

Ich hab auch die MIDI.au3 etwas angepasst: Der Inhalt kann nicht angezeigt werden, da er nicht mehr verfügbar ist.
und zwar die DllCall-Return Variable: Local $aResult
und eine errorabfrage

Ich würde auch immer $aResult[0] als Rückgabewert verwenden:

[autoit]

Switch $aResult[0]
Case 0 ;$MMSYSERR_NOERROR
Return $aResult[0]
Case Else
Return SetError(1, 0, $aResult[0])
EndSwitch

[/autoit]

Falls du dein System beibehalten willst, dann verwende aber trotzdem Switch statt If:

[autoit]

Switch $aResult[0]
Case $MMSYSERR_NOERROR
Return 1
Case $MMSYSERR_INVALHANDLE
Return SetError(1,1,0)
Case $MMSYSERR_INVALPARAM
Return SetError(2,2,0)
Case $MMSYSERR_NOMEM
Return SetError(3,3,0)
Case Else
Return SetError(4,4,0)
EndSwitch

[/autoit]

E

**eukalyptus**

Großartiges Script!

Hier hab ich ein Testscript, das ich vor kurzem erstellt hab.
Damit kann man schnell zoomen, verschieben und drehen ohne das Objekt selbst neu zu berechnen.
Es wird einfach der Ziel-GraphicsContext transformiert...

Vielleicht kannst du das ja gebrauchen.
(linke Maustaste = verschieben, Scrollrad = zoomen, linke Maustaste + Scrollrad = drehen, rechte Maustaste = reset)

Spoiler anzeigen

[autoit]

#include <GDIPlus.au3>
#include <GUIConstantsEx.au3>
#include <WinAPI.au3>
#include <WindowsConstants.au3>

[/autoit] [autoit][/autoit] [autoit]

Opt("MustDeclareVars", 1)
Opt("GUIOnEventMode", 1)

[/autoit] [autoit][/autoit] [autoit]

Global $iWidth = 1000;@DesktopWidth
Global $iHeight = 580;@DesktopHeight

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_Startup()
Global $hGui = GUICreate("Test", $iWidth, $iHeight)
GUISetOnEvent($GUI_EVENT_CLOSE, "_Exit")
GUISetOnEvent($GUI_EVENT_SECONDARYDOWN, "_ResetGraphicsTransform")
Global $hDC = _WinAPI_GetDC($hGui)
Global $hBMP = _WinAPI_CreateCompatibleBitmap($hDC, $iWidth, $iHeight)
Global $hBmpTmp = _GDIPlus_BitmapCreateFromHBITMAP($hBMP)
_WinAPI_DeleteObject($hBMP)
$hBMP = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hBmpTmp)
_GDIPlus_BitmapDispose($hBmpTmp)
Global $hCDC = _WinAPI_CreateCompatibleDC($hDC)
Global $hOBJ = _WinAPI_SelectObject($hCDC, $hBMP)
Global $hGfxBuffer = _GDIPlus_GraphicsCreateFromHDC($hCDC)
_GDIPlus_GraphicsSetSmoothingMode($hGfxBuffer, 2)
_GDIPlus_GraphicsClear($hGfxBuffer, 0xFFFFFFFF)

[/autoit] [autoit][/autoit] [autoit]

Global $hPenR = _GDIPlus_PenCreate(0xFFAA0000, 1)
Global $hBrushR = _GDIPlus_BrushCreateSolid(0x88AA0000)
Global $hPenG = _GDIPlus_PenCreate(0xFF00AA00, 1)
Global $hBrushG = _GDIPlus_BrushCreateSolid(0x8800AA00)
Global $hPenB = _GDIPlus_PenCreate(0xFF0000FF, 1)
Global $hBrushB = _GDIPlus_BrushCreateSolid(0x880000FF)

[/autoit] [autoit][/autoit] [autoit]

GUIRegisterMsg($WM_PAINT, "WM_PAINT")
GUIRegisterMsg($WM_ERASEBKGND, "WM_PAINT")

[/autoit] [autoit][/autoit] [autoit]

Global $iMouseX, $iMouseY
GUIRegisterMsg($WM_LBUTTONDOWN, "WM_LBUTTONDOWN")
GUIRegisterMsg($WM_MOUSEWHEEL, "WM_MOUSEWHEEL")
GUIRegisterMsg($WM_MOUSEMOVE, "WM_MOUSEMOVE")
GUISetState()

[/autoit] [autoit][/autoit] [autoit]

Global $tCurve1 = _CreateCurve(Random(10, 30, 1))
Global $tCurve2 = _CreateCurve(Random(10, 30, 1))
Global $tCurve3 = _CreateCurve(Random(10, 30, 1))

[/autoit] [autoit][/autoit] [autoit]

_Draw()

[/autoit] [autoit][/autoit] [autoit]

While Sleep(10)
WEnd

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Draw()
_GDIPlus_GraphicsClear($hGfxBuffer, 0xFFFFFFFF)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipFillClosedCurve2", "hwnd", $hGfxBuffer, "hwnd", $hBrushR, "ptr", DllStructGetPtr($tCurve1, "Pnt"), "int", DllStructGetData($tCurve1, "Cnt"), "float", 0, "int", 0)
DllCall($ghGDIPDll, "uint", "GdipDrawClosedCurve2", "hwnd", $hGfxBuffer, "hwnd", $hPenR, "ptr", DllStructGetPtr($tCurve1, "Pnt"), "int", DllStructGetData($tCurve1, "Cnt"), "float", 0)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipFillClosedCurve2", "hwnd", $hGfxBuffer, "hwnd", $hBrushG, "ptr", DllStructGetPtr($tCurve2, "Pnt"), "int", DllStructGetData($tCurve2, "Cnt"), "float", 0, "int", 0)
DllCall($ghGDIPDll, "uint", "GdipDrawClosedCurve2", "hwnd", $hGfxBuffer, "hwnd", $hPenG, "ptr", DllStructGetPtr($tCurve2, "Pnt"), "int", DllStructGetData($tCurve2, "Cnt"), "float", 0)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipFillClosedCurve2", "hwnd", $hGfxBuffer, "hwnd", $hBrushB, "ptr", DllStructGetPtr($tCurve3, "Pnt"), "int", DllStructGetData($tCurve3, "Cnt"), "float", 0, "int", 0)
DllCall($ghGDIPDll, "uint", "GdipDrawClosedCurve2", "hwnd", $hGfxBuffer, "hwnd", $hPenB, "ptr", DllStructGetPtr($tCurve3, "Pnt"), "int", DllStructGetData($tCurve3, "Cnt"), "float", 0)

[/autoit] [autoit][/autoit] [autoit]

_WinAPI_BitBlt($hDC, 0, 0, $iWidth, $iHeight, $hCDC, 0, 0, 0x00CC0020)
EndFunc ;==>_Draw

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _ResetGraphicsTransform()
DllCall($ghGDIPDll, "uint", "GdipResetWorldTransform", "hwnd", $hGfxBuffer)
_Draw()
EndFunc ;==>_ResetGraphicsTransform

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func WM_LBUTTONDOWN($hWnd, $Msg, $wParam, $lParam)
$iMouseX = BitAND($lParam, 0x0000FFFF)
$iMouseY = BitShift($lParam, 16)
Return $GUI_RUNDEFMSG
EndFunc ;==>WM_LBUTTONDOWN

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func WM_MOUSEMOVE($hWnd, $Msg, $wParam, $lParam)

[/autoit] [autoit][/autoit] [autoit]

Switch BitAND($wParam, 0x0000FFFF)
Case 1
Local $iX = BitAND($lParam, 0x0000FFFF)
Local $iY = BitShift($lParam, 16)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipTranslateWorldTransform", "hwnd", $hGfxBuffer, "float", $iX - $iMouseX, "float", $iY - $iMouseY, "int", True)

[/autoit] [autoit][/autoit] [autoit]

$iMouseX = $iX
$iMouseY = $iY

[/autoit] [autoit][/autoit] [autoit]

_Draw()

[/autoit] [autoit][/autoit] [autoit]

EndSwitch

[/autoit] [autoit][/autoit] [autoit]

Return $GUI_RUNDEFMSG
EndFunc ;==>WM_MOUSEMOVE

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func WM_MOUSEWHEEL($hWnd, $Msg, $wParam, $lParam)

[/autoit] [autoit][/autoit] [autoit]

Switch BitAND($wParam, 0x0000FFFF)
Case 1
Local $fAngle = -3
If BitShift($wParam, 16) < 0 Then $fAngle = 3

[/autoit] [autoit][/autoit] [autoit]

Local $tPnt = DllStructCreate("float X; float Y;")
DllStructSetData($tPnt, "X", $iMouseX)
DllStructSetData($tPnt, "Y", $iMouseY)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipTransformPoints", "hwnd", $hGfxBuffer, "int", 0, "int", 1, "ptr", DllStructGetPtr($tPnt), "int", 1)

[/autoit] [autoit][/autoit] [autoit]

Local $fX = DllStructGetData($tPnt, "X")
Local $fY = DllStructGetData($tPnt, "Y")

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipTranslateWorldTransform", "hwnd", $hGfxBuffer, "float", $fX, "float", $fY, "int", False)
DllCall($ghGDIPDll, "uint", "GdipRotateWorldTransform", "hwnd", $hGfxBuffer, "float", $fAngle, "int", False)
DllCall($ghGDIPDll, "uint", "GdipTranslateWorldTransform", "hwnd", $hGfxBuffer, "float", -$fX, "float", -$fY, "int", False)

[/autoit] [autoit][/autoit] [autoit]

Case Else
Local $aInfo = GUIGetCursorInfo($hGui)
Local $fScale = 1.1
If BitShift($wParam, 16) < 0 Then $fScale = 0.9

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipTranslateWorldTransform", "hwnd", $hGfxBuffer, "float", -$aInfo[0], "float", -$aInfo[1], "int", True)
DllCall($ghGDIPDll, "uint", "GdipScaleWorldTransform", "hwnd", $hGfxBuffer, "float", $fScale, "float", $fScale, "int", True)
DllCall($ghGDIPDll, "uint", "GdipTranslateWorldTransform", "hwnd", $hGfxBuffer, "float", $aInfo[0], "float", $aInfo[1], "int", True)

[/autoit] [autoit][/autoit] [autoit]

EndSwitch

[/autoit] [autoit][/autoit] [autoit]

_Draw()

[/autoit] [autoit][/autoit] [autoit]

Return $GUI_RUNDEFMSG
EndFunc ;==>WM_MOUSEWHEEL

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _CreateCurve($iCnt)
Local $tCurve = DllStructCreate("uint Cnt; float Pnt[" & $iCnt * 2 & "];")
DllStructSetData($tCurve, "Cnt", $iCnt)
For $i = 0 To $iCnt - 1
DllStructSetData($tCurve, "Pnt", Random(0, $iWidth), $i * 2 + 1)
DllStructSetData($tCurve, "Pnt", Random(0, $iHeight), $i * 2 + 2)
Next
Return $tCurve
EndFunc ;==>_CreateCurve

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func WM_PAINT($hWnd, $uMsgm, $wParam, $lParam)
_WinAPI_BitBlt($hDC, 0, 0, $iWidth, $iHeight, $hCDC, 0, 0, 0x00CC0020)
Return $GUI_RUNDEFMSG
EndFunc ;==>WM_PAINT

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Exit()
_GDIPlus_PenDispose($hPenR)
_GDIPlus_BrushDispose($hBrushR)
_GDIPlus_PenDispose($hPenG)
_GDIPlus_BrushDispose($hBrushG)
_GDIPlus_PenDispose($hPenB)
_GDIPlus_BrushDispose($hBrushB)
_GDIPlus_GraphicsDispose($hGfxBuffer)
_WinAPI_SelectObject($hCDC, $hOBJ)
_WinAPI_DeleteObject($hBMP)
_WinAPI_DeleteDC($hCDC)
_WinAPI_ReleaseDC($hGui, $hDC)
_GDIPlus_Shutdown()
Exit
EndFunc ;==>_Exit

[/autoit]

E

EDIT: Hab ich ja total vergessen!
Ich hab auch mit einer 3D-Matrix experimentiert:

Spoiler anzeigen

[autoit]

#include <GDIPlus.au3>
#include <GUIConstantsEx.au3>
#include <WindowsConstants.au3>

[/autoit] [autoit][/autoit] [autoit]

Global Const $bMatrixInit = "0x000000000000F03F0000000000000000000000000000000000000000000000000000000000000000000000000000F03F0000000000000000000000000000000000000000000000000000000000000000000000000000F03F0000000000000000000000000000000000000000000000000000000000000000000000000000F03F"
Global Const $PI = ATan(1) * 4
Global Const $LENS = 2560

[/autoit] [autoit][/autoit] [autoit]

Opt("MustDeclareVars", 1)
Opt("GUIOnEventMode", 1)

[/autoit] [autoit][/autoit] [autoit]

Global $iWidth = 800
Global $iHeight = 600
Global $fCenterX = $iWidth / 2
Global $fCenterY = $iHeight / 2

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_Startup()
Global $hGui = GUICreate("Matrix Test", $iWidth, $iHeight, 20, 20)
GUISetOnEvent($GUI_EVENT_CLOSE, "_Exit")
Global $hDC = _WinAPI_GetDC($hGui)
Global $hBMP = _WinAPI_CreateCompatibleBitmap($hDC, $iWidth, $iHeight)
Global $hBmpTmp = _GDIPlus_BitmapCreateFromHBITMAP($hBMP)
_WinAPI_DeleteObject($hBMP)
$hBMP = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hBmpTmp)
_GDIPlus_BitmapDispose($hBmpTmp)
Global $hCDC = _WinAPI_CreateCompatibleDC($hDC)
Global $hOBJ = _WinAPI_SelectObject($hCDC, $hBMP)
Global $hGfxBuffer = _GDIPlus_GraphicsCreateFromHDC($hCDC)
_GDIPlus_GraphicsSetSmoothingMode($hGfxBuffer, 2)
_GDIPlus_GraphicsClear($hGfxBuffer, 0xFFFFFFFF)

[/autoit] [autoit][/autoit] [autoit]

Global $hPen = _GDIPlus_PenCreate(0xFF00FF00)

[/autoit] [autoit][/autoit] [autoit]

GUIRegisterMsg($WM_PAINT, "WM_PAINT")
GUIRegisterMsg($WM_ERASEBKGND, "WM_PAINT")

[/autoit] [autoit][/autoit] [autoit]

GUISetState()

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Global $tObj = _Create3DObject(60, 20, 18)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

While 1
Sleep(10)
_Draw()
WEnd

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Draw()
Local $tMX = _MX3D_Create()

[/autoit] [autoit][/autoit] [autoit]

Local Static $fRX = 0, $fRY = 0, $fRZ = 0, $fS = 1, $fSPlus = 0.01
$fS += $fSPlus
If ($fS >= 2.5) Or ($fS < 0.2) Then $fSPlus *= -1
$fRX += 1
$fRY += 0.42
$fRZ += 0.17

[/autoit] [autoit][/autoit] [autoit]

Local $iTimer = TimerInit()
_MX3D_RotateX($tMX, $fRX)
_MX3D_RotateY($tMX, $fRY)
_MX3D_RotateZ($tMX, $fRZ)
_MX3D_Scale($tMX, $fS, $fS, $fS)
ConsoleWrite("+ Matrix: " & TimerDiff($iTimer) & @CRLF)

[/autoit] [autoit][/autoit] [autoit]

$iTimer = TimerInit()
TransFormPoints($tObj, $tMX)
ConsoleWrite("> Transform: " & TimerDiff($iTimer) & @CRLF)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Local $iCnt = DllStructGetData($tObj, "Cnt")
Local $fX, $fY, $fR

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_GraphicsClear($hGfxBuffer, 0xFF000000)
$iTimer = TimerInit()
For $i = 0 To $iCnt - 1
If DllStructGetData($tObj, "Vis", $i + 1) = True Then
$fX = DllStructGetData($tObj, "Pnt", $i * 2 + 1)
$fY = DllStructGetData($tObj, "Pnt", $i * 2 + 2)
DllCall($ghGDIPDll, "int", "GdipDrawEllipse", "handle", $hGfxBuffer, "handle", $hPen, "float", $fX, "float", $fY, "float", 1, "float", 1)
EndIf
Next
ConsoleWrite("! Draw: " & TimerDiff($iTimer) & @CRLF)

[/autoit] [autoit][/autoit] [autoit]

_WinAPI_BitBlt($hDC, 0, 0, $iWidth, $iHeight, $hCDC, 0, 0, 0x00CC0020)
EndFunc ;==>_Draw

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _MX3D_RotateX(ByRef $tMX, $fD)
;[ 1 0 0 0 ]
;[ 0 C -S 0 ]
;[ 0 S C 0 ]
;[ 0 0 0 1 ]

[/autoit] [autoit][/autoit] [autoit]

If $fD = 0 Then Return
Local $fR = $fD * 0.0174532925199433

[/autoit] [autoit][/autoit] [autoit]

Local $fC = Cos($fR)
Local $fS = Sin($fR)

[/autoit] [autoit][/autoit] [autoit]

Local $tMX1 = _MX3D_Create()
DllStructSetData($tMX1, 1, $fC, 6)
DllStructSetData($tMX1, 1, -$fS, 7)
DllStructSetData($tMX1, 1, $fS, 10)
DllStructSetData($tMX1, 1, $fC, 11)

[/autoit] [autoit][/autoit] [autoit]

$tMX = _MX3D_MulMatrix($tMX1, $tMX)

[/autoit] [autoit][/autoit] [autoit]

EndFunc ;==>_MX3D_RotateX

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _MX3D_RotateY(ByRef $tMX, $fD)
;[ C 0 S 0 ]
;[ 0 1 0 0 ]
;[-S 0 C 0 ]
;[ 0 0 0 1 ]

[/autoit] [autoit][/autoit] [autoit]

If $fD = 0 Then Return
Local $fR = $fD * 0.0174532925199433

[/autoit] [autoit][/autoit] [autoit]

Local $fC = Cos($fR)
Local $fS = Sin($fR)

[/autoit] [autoit][/autoit] [autoit]

Local $tMX1 = _MX3D_Create()
DllStructSetData($tMX1, 1, $fC, 1)
DllStructSetData($tMX1, 1, $fS, 3)
DllStructSetData($tMX1, 1, -$fS, 9)
DllStructSetData($tMX1, 1, $fC, 11)

[/autoit] [autoit][/autoit] [autoit]

$tMX = _MX3D_MulMatrix($tMX1, $tMX)

[/autoit] [autoit][/autoit] [autoit]

EndFunc ;==>_MX3D_RotateY

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _MX3D_RotateZ(ByRef $tMX, $fD)
;[ C -S 0 0 ]
;[ S C 0 0 ]
;[ 0 0 1 0 ]
;[ 0 0 0 1 ]

[/autoit] [autoit][/autoit] [autoit]

If $fD = 0 Then Return
Local $fR = $fD * 0.0174532925199433

[/autoit] [autoit][/autoit] [autoit]

Local $fC = Cos($fR)
Local $fS = Sin($fR)

[/autoit] [autoit][/autoit] [autoit]

Local $tMX1 = _MX3D_Create()
DllStructSetData($tMX1, 1, $fC, 1)
DllStructSetData($tMX1, 1, -$fS, 2)
DllStructSetData($tMX1, 1, $fS, 5)
DllStructSetData($tMX1, 1, $fC, 6)

[/autoit] [autoit][/autoit] [autoit]

$tMX = _MX3D_MulMatrix($tMX1, $tMX)

[/autoit] [autoit][/autoit] [autoit]

EndFunc ;==>_MX3D_RotateZ

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _MX3D_Scale(ByRef $tMX, $fX, $fY, $fZ)
;[ X 0 0 0 ]
;[ 0 Y 0 0 ]
;[ 0 0 Z 0 ]
;[ 0 0 0 1 ]

[/autoit] [autoit][/autoit] [autoit]

Local $tMX1 = _MX3D_Create()
DllStructSetData($tMX1, 1, $fX, 1)
DllStructSetData($tMX1, 1, $fY, 6)
DllStructSetData($tMX1, 1, $fZ, 11)

[/autoit] [autoit][/autoit] [autoit]

$tMX = _MX3D_MulMatrix($tMX1, $tMX)

[/autoit] [autoit][/autoit] [autoit]

EndFunc ;==>_MX3D_Scale

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _MX3D_Translate(ByRef $tMX, $fX, $fY, $fZ)
;[ 1 0 0 X ]
;[ 0 1 0 Y ]
;[ 0 0 1 Z ]
;[ 0 0 0 1 ]
Local $tMX1 = _MX3D_Create()
DllStructSetData($tMX1, 1, $fX, 4)
DllStructSetData($tMX1, 1, $fY,
DllStructSetData($tMX1, 1, $fZ, 12)

[/autoit] [autoit][/autoit] [autoit]

$tMX = _MX3D_MulMatrix($tMX1, $tMX)
EndFunc ;==>_MX3D_Translate

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _MX3D_MulMatrix($tMX1, $tMX2)
Local $tMX = DllStructCreate("double[16];")

[/autoit] [autoit][/autoit] [autoit]

Local $fS
For $x = 0 To 2
For $y = 0 To 3
$fS = 0
For $z = 0 To 3
$fS += DllStructGetData($tMX2, 1, $x * 4 + $z + 1) * DllStructGetData($tMX1, 1, $z * 4 + $y + 1)
Next
DllStructSetData($tMX, 1, $fS, $x * 4 + $y + 1)
Next
Next

[/autoit] [autoit][/autoit] [autoit]

DllStructSetData($tMX, 1, 1, 16)

[/autoit] [autoit][/autoit] [autoit]

Return $tMX
EndFunc ;==>_MX3D_MulMatrix

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _MX3D_MulVector($tMX, $fX, $fY, $fZ, ByRef $fRX, ByRef $fRY, ByRef $fRZ)
$fRX = ($fX * DllStructGetData($tMX, 1, 1)) + ($fY * DllStructGetData($tMX, 1, 2)) + ($fZ * DllStructGetData($tMX, 1, 3)) + DllStructGetData($tMX, 1, 4)
$fRY = ($fX * DllStructGetData($tMX, 1, 5)) + ($fY * DllStructGetData($tMX, 1, 6)) + ($fZ * DllStructGetData($tMX, 1, 7)) + DllStructGetData($tMX, 1,
$fRZ = ($fX * DllStructGetData($tMX, 1, 9)) + ($fY * DllStructGetData($tMX, 1, 10)) + ($fZ * DllStructGetData($tMX, 1, 11)) + DllStructGetData($tMX, 1, 12)
Return True
EndFunc ;==>_MX3D_MulVector

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _MX3D_Clear(ByRef $tMX)
$tMX = 0
$tMX = DllStructCreate("double[16];")
EndFunc ;==>_MX3D_Clear

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _MX3D_Reset(ByRef $tMX)
;[ 1 0 0 0 ]
;[ 0 1 0 0 ]
;[ 0 0 1 0 ]
;[ 0 0 0 1 ]
Local $tSet = DllStructCreate("byte[128];", DllStructGetPtr($tMX))
DllStructSetData($tSet, 1, $bMatrixInit)
EndFunc ;==>_MX3D_Reset

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _MX3D_Create()
;[ 1 0 0 0 ]
;[ 0 1 0 0 ]
;[ 0 0 1 0 ]
;[ 0 0 0 1 ]
Local $tMX = DllStructCreate("double[16];")

[/autoit] [autoit][/autoit] [autoit]

DllStructSetData($tMX, 1, 1, 1)
DllStructSetData($tMX, 1, 1, 6)
DllStructSetData($tMX, 1, 1, 11)
DllStructSetData($tMX, 1, 1, 16)

[/autoit] [autoit][/autoit] [autoit]

Return $tMX
EndFunc ;==>_MX3D_Create

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func TransFormPoints($tPnt, $tMX)
Local $iCnt = DllStructGetData($tPnt, "Cnt")
Local $fX, $fY, $fZ, $fRX, $fRY, $fRZ, $fD
Local $iIdx

[/autoit] [autoit][/autoit] [autoit]

For $i = 0 To $iCnt - 1
$iIdx = $i * 3
$fX = DllStructGetData($tPnt, "3D", $iIdx + 1)
$fY = DllStructGetData($tPnt, "3D", $iIdx + 2)
$fZ = DllStructGetData($tPnt, "3D", $iIdx + 3)

[/autoit] [autoit][/autoit] [autoit]

_MX3D_MulVector($tMX, $fX, $fY, $fZ, $fRX, $fRY, $fRZ)

[/autoit] [autoit][/autoit] [autoit]

$fD = ($LENS - $fRZ)
If $fD > 0 Then
$iIdx = $i * 2
DllStructSetData($tPnt, "Pnt", $fCenterX + ($LENS * $fRX / $fD), $iIdx + 1)
DllStructSetData($tPnt, "Pnt", $fCenterY - ($LENS * $fRY / $fD), $iIdx + 2)
DllStructSetData($tPnt, "Vis", True, $i + 1)
Else
DllStructSetData($tPnt, "Vis", False, $i + 1)
EndIf
Next

[/autoit] [autoit][/autoit] [autoit]

EndFunc ;==>TransFormPoints

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Create3DObject($fRadius, $iSlices, $iBands)
Local $iCnt = $iSlices * $iBands
Local $tPnt = DllStructCreate("uint Cnt; float Pnt[" & $iCnt * 2 & "]; byte Vis[" & $iCnt & "]; float 3D[" & $iCnt * 3 & "];")
DllStructSetData($tPnt, "Cnt", $iCnt - 1)

[/autoit] [autoit][/autoit] [autoit]

Local $iPnt = 0, $iIdx, $fPhi, $fTheta
For $i = 0 To $iSlices - 1
$fPhi = $PI / ($iSlices - 1) * $i
For $j = 0 To $iBands - 1
$fTheta = 2 * (-$PI / ($iBands - 1) * $j)
$iIdx = $iPnt * 3
DllStructSetData($tPnt, "3D", -Int($fRadius * Sin($fPhi) * Cos($fTheta)), $iIdx + 1)
DllStructSetData($tPnt, "3D", -Int($fRadius * Sin($fPhi) * Sin($fTheta)), $iIdx + 2)
DllStructSetData($tPnt, "3D", -Int($fRadius * Cos($fPhi)), $iIdx + 3)

[/autoit] [autoit][/autoit] [autoit]

$iPnt += 1
Next
Next

[/autoit] [autoit][/autoit] [autoit]

Return $tPnt
EndFunc ;==>_Create3DObject

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func WM_PAINT($hWnd, $uMsgm, $wParam, $lParam)
_WinAPI_BitBlt($hDC, 0, 0, $iWidth, $iHeight, $hCDC, 0, 0, 0x00CC0020)
Return $GUI_RUNDEFMSG
EndFunc ;==>WM_PAINT

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Exit()
_GDIPlus_PenDispose($hPen)
_GDIPlus_GraphicsDispose($hGfxBuffer)
_WinAPI_SelectObject($hCDC, $hOBJ)
_WinAPI_DeleteObject($hBMP)
_WinAPI_DeleteDC($hCDC)
_WinAPI_ReleaseDC($hGui, $hDC)
_GDIPlus_Shutdown()
Exit
EndFunc ;==>_Exit

[/autoit]

**eukalyptus**

Eine weitere GdiPlus-Spielerei...
Diesmal: gebürstetes Aluminium
Der Inhalt kann nicht angezeigt werden, da er nicht mehr verfügbar ist.

Im Prinzip sind es nur 3 Schritte:
1 Schritt: Noise erstellen; zufällige Grautöne für jeden Pixel der Bitmap; wegen der Geschwindigkeit wird nur ein kleines NoiseBitmap erstellt und dann wiederholt
Das Ergebnis ist zwar nicht so schön, aber AutoIt ist etwas zu langsam, als dass man das gesammte Bild "noisen" könnte...
(Ein besseres Ergebnis hätte man vielleicht noch mit "Gaussian noise")
2 Schritt: MotionBlur; verwandlelt die Grautonpixel zu Linien
Der Effekt ergibt sich einfach, indem das Bild transparent mit einem immer größeren X-Offset wiederholt wird.
(Ist warscheinlich der schlechteste Algo, aber auch der schnellste
3 Schritt: Lichtreflexion; ein Verlauf von Transparent zu Weiß wird darübergezeichnent
-fertig

Spoiler anzeigen

[autoit]

#include <GDIPlus.au3>
#include <GDIPlusConstants.au3>
#include <GUIConstantsEx.au3>
#include <WinAPI.au3>
#include <WindowsConstants.au3>

[/autoit] [autoit][/autoit] [autoit]

Opt("MustDeclareVars", 1)
Opt("GUIOnEventMode", 1)

[/autoit] [autoit][/autoit] [autoit]

Global $iWidth = 1200
Global $iHeight = 600

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

_GDIPlus_Startup()
Global $hGui = GUICreate("GDIPlus Script by Eukalyptus", $iWidth, $iHeight)
GUISetOnEvent($GUI_EVENT_CLOSE, "_Exit")
Global $hDC = _WinAPI_GetDC($hGui)
Global $hBMP = _WinAPI_CreateCompatibleBitmap($hDC, $iWidth, $iHeight)
Global $hBmpTmp = _GDIPlus_BitmapCreateFromHBITMAP($hBMP)
_WinAPI_DeleteObject($hBMP)
$hBMP = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hBmpTmp)
_GDIPlus_BitmapDispose($hBmpTmp)
Global $hCDC = _WinAPI_CreateCompatibleDC($hDC)
Global $hOBJ = _WinAPI_SelectObject($hCDC, $hBMP)
Global $hGfxBuffer = _GDIPlus_GraphicsCreateFromHDC($hCDC)
_GDIPlus_GraphicsSetSmoothingMode($hGfxBuffer, 2)
_GDIPlus_GraphicsClear($hGfxBuffer, 0xFFFFFFFF)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

GUIRegisterMsg($WM_PAINT, "WM_PAINT")
GUIRegisterMsg($WM_ERASEBKGND, "WM_PAINT")

[/autoit] [autoit][/autoit] [autoit]

GUISetState()

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Global $hBitmap = _CreateBackground()

[/autoit] [autoit][/autoit] [autoit]

_Draw()
While 1
Sleep(10)

[/autoit] [autoit][/autoit] [autoit]

WEnd

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _CreateBackground()
Local $hBitmap_ALU = _CreateBrushedAluminum($iWidth, $iHeight)
Local $hBitmap_ALU2 = _CreateBrushedAluminum($iWidth, $iHeight, 14, 0.6, 0.2, 0.2, 0.2, 0x33FFFFFF)

[/autoit] [autoit][/autoit] [autoit]

Local $aResult = DllCall($ghGDIPDll, "uint", "GdipCreateBitmapFromScan0", "int", $iWidth, "int", $iHeight, "int", 0, "int", 0x0026200A, "ptr", 0, "int*", 0)
If @error Or Not IsArray($aResult) Then Return SetError(1, 1, False)
Local $hBitmap = $aResult[6]
Local $hContext = _GDIPlus_ImageGetGraphicsContext($hBitmap)
_GDIPlus_GraphicsSetSmoothingMode($hContext, 2)
DllCall($ghGDIPDll, "uint", "GdipSetInterpolationMode", "hwnd", $hContext, "int", 7)
_GDIPlus_GraphicsDrawImage($hContext, $hBitmap_ALU, 0, 0)

[/autoit] [autoit][/autoit] [autoit]

$aResult = DllCall($ghGDIPDll, "uint", "GdipCreatePath", "int", 0, "int*", 0)
If @error Or Not IsArray($aResult) Then Return SetError(1, 3, False)
Local $hPath = $aResult[2]

[/autoit] [autoit][/autoit] [autoit]

Local $hFormat = _GDIPlus_StringFormatCreate()
Local $hFamily = _GDIPlus_FontFamilyCreate("Arial Black")

[/autoit] [autoit][/autoit] [autoit]

_PathAddText($hPath, "Brushed", $hFamily, $hFormat, 100, 40)
_PathAddText($hPath, "Aluminium", $hFamily, $hFormat, 100)
_PathAddText($hPath, "AutoIt GdiPlus Script", $hFamily, $hFormat, 50, 80)

[/autoit] [autoit][/autoit] [autoit]

$aResult = DllCall($ghGDIPDll, "uint", "GdipClonePath", "hwnd", $hPath, "int*", 0)
If @error Or Not IsArray($aResult) Then Return SetError(1, 3, False)
Local $hPath_Clone = $aResult[2]

[/autoit] [autoit][/autoit] [autoit]

Local $hMatrix = _GDIPlus_MatrixCreate()
_GDIPlus_MatrixTranslate($hMatrix, 2, 2)
DllCall($ghGDIPDll, "uint", "GdipTransformPath", "hwnd", $hPath_Clone, "hwnd", $hMatrix)
Local $hBrush = _GDIPlus_BrushCreateSolid(0x44FFFFFF)
DllCall($ghGDIPDll, "uint", "GdipFillPath", "hwnd", $hContext, "hwnd", $hBrush, "hwnd", $hPath_Clone)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_MatrixTranslate($hMatrix, -5, -5)
DllCall($ghGDIPDll, "uint", "GdipTransformPath", "hwnd", $hPath_Clone, "hwnd", $hMatrix)
_GDIPlus_BrushSetSolidColor($hBrush, 0x88000000)
DllCall($ghGDIPDll, "uint", "GdipFillPath", "hwnd", $hContext, "hwnd", $hBrush, "hwnd", $hPath_Clone)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_MatrixDispose($hMatrix)
DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath_Clone)
_GDIPlus_BrushDispose($hBrush)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

$aResult = DllCall($ghGDIPDll, "uint", "GdipCreateTexture", "hwnd", $hBitmap_ALU2, "int", 0, "int*", 0)
If @error Or Not IsArray($aResult) Then Return SetError(1, 2, False)
$hBrush = $aResult[3]
DllCall($ghGDIPDll, "uint", "GdipFillPath", "hwnd", $hContext, "hwnd", $hBrush, "hwnd", $hPath)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_FontFamilyDispose($hFamily)
_GDIPlus_StringFormatDispose($hFormat)
DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_BrushDispose($hBrush)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_BitmapDispose($hBitmap_ALU)
_GDIPlus_BitmapDispose($hBitmap_ALU2)
Return $hBitmap
EndFunc ;==>_CreateBackground

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _PathAddText($hPath, $sText, $hFamily, $hFormat, $fSize, $fYOff = 0)
Local $tLayout = _GDIPlus_RectFCreate(0, 0, 0, 0)
Local $tBounds = _GDIPlus_RectFCreate(0, 0, 0, 0)

[/autoit] [autoit][/autoit] [autoit]

Local $aResult = DllCall($ghGDIPDll, "uint", "GdipCreatePath", "int", 0, "int*", 0)
If @error Or Not IsArray($aResult) Then Return SetError(1, 1, False)
Local $hPath_Tmp = $aResult[2]

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipAddPathString", "hwnd", $hPath_Tmp, "wstr", $sText, "int", -1, "hwnd", $hFamily, "int", 1, "float", $fSize, "ptr", DllStructGetPtr($tLayout), "hwnd", $hFormat)
DllCall($ghGDIPDll, "uint", "GdipGetPathWorldBounds", "hwnd", $hPath_Tmp, "ptr", DllStructGetPtr($tBounds), "hwnd", 0, "hwnd", 0)
DllStructSetData($tLayout, "X", ($iWidth / 2) - (DllStructGetData($tBounds, "Width") / 2) - DllStructGetData($tBounds, "X"))

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipGetPathWorldBounds", "hwnd", $hPath, "ptr", DllStructGetPtr($tBounds), "hwnd", 0, "hwnd", 0)
DllStructSetData($tLayout, "Y", DllStructGetData($tBounds, "Y") + DllStructGetData($tBounds, "Height") + $fYOff)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipAddPathString", "hwnd", $hPath, "wstr", $sText, "int", -1, "hwnd", $hFamily, "int", 1, "float", $fSize, "ptr", DllStructGetPtr($tLayout), "hwnd", $hFormat)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath_Tmp)
EndFunc ;==>_PathAddText

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Draw()
_GDIPlus_GraphicsClear($hGfxBuffer, 0xFF000000)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_GraphicsDrawImage($hGfxBuffer, $hBitmap, 0, 0)

[/autoit] [autoit][/autoit] [autoit]

_WinAPI_BitBlt($hDC, 0, 0, $iWidth, $iHeight, $hCDC, 0, 0, 0x00CC0020)
EndFunc ;==>_Draw

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _CreateBrushedAluminum($iW, $iH, $iBlurDist = 14, $fBlurTrans = 0.6, $fRed = 0.8, $fGreen = 0.9, $fBlue = 1, $iLightColor = 0xAAFFFFFF, $fLightAngle = -8, $fLightSigma = 0.48, $fLightScale = 0.83)
$iBlurDist = Ceiling($iBlurDist)
$iBlurDist += 1 - Mod($iBlurDist, 2)

[/autoit] [autoit][/autoit] [autoit]

Local $iOverSize = 0
For $i = 1 To $iBlurDist Step 2
$iOverSize += $i + $i + 1
Next

[/autoit] [autoit][/autoit] [autoit]

Local $iWO = $iW + $iOverSize

[/autoit] [autoit][/autoit] [autoit]

;=========================================
; Add Noise
;=========================================

[/autoit] [autoit][/autoit] [autoit]

Local $iNoiseSize = 40

[/autoit] [autoit][/autoit] [autoit]

Local $aResult = DllCall($ghGDIPDll, "uint", "GdipCreateBitmapFromScan0", "int", $iNoiseSize, "int", $iNoiseSize, "int", 0, "int", 0x0026200A, "ptr", 0, "int*", 0)
If @error Or Not IsArray($aResult) Then Return SetError(1, 1, False)
Local $hBmp_Noise = $aResult[6]
Local $hGfx_Noise = _GDIPlus_ImageGetGraphicsContext($hBmp_Noise)

[/autoit] [autoit][/autoit] [autoit]

Local $tData = _GDIPlus_BitmapLockBits($hBmp_Noise, 0, 0, $iNoiseSize, $iNoiseSize, BitOR($GDIP_ILMREAD, $GDIP_ILMWRITE), $GDIP_PXF32ARGB)
Local $iStride = DllStructGetData($tData, "Stride")
Local $iWidth = DllStructGetData($tData, "Width")
Local $iHeight = DllStructGetData($tData, "Height")
Local $pScan0 = DllStructGetData($tData, "Scan0")
Local $tPixel = DllStructCreate("dword[" & $iWidth * $iHeight & "];", $pScan0)

[/autoit] [autoit][/autoit] [autoit]

Local $iAmp
For $row = 0 To $iHeight - 1
For $col = 0 To $iWidth - 1
$iAmp = Random(0, 0xFF, 1)
DllStructSetData($tPixel, 1, BitOR(0xFF000000, BitShift($iAmp, -16), BitShift($iAmp, -8), $iAmp), $row * $iWidth + $col + 1)
Next
Next

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_BitmapUnlockBits($hBmp_Noise, $tData)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

;=========================================
; Create Full NoiseBitmap
;=========================================

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

$aResult = DllCall($ghGDIPDll, "uint", "GdipCreateBitmapFromScan0", "int", $iWO, "int", $iH, "int", 0, "int", 0x0026200A, "ptr", 0, "int*", 0)
If @error Or Not IsArray($aResult) Then Return SetError(1, 3, False)
Local $hBmp_Full = $aResult[6]
Local $hGfx_Full = _GDIPlus_ImageGetGraphicsContext($hBmp_Full)
_GDIPlus_GraphicsSetSmoothingMode($hGfx_Full, 2)
DllCall($ghGDIPDll, "uint", "GdipSetInterpolationMode", "hwnd", $hGfx_Full, "int", 7)

[/autoit] [autoit][/autoit] [autoit]

Local $iXOff, $iYOff, $iSizeX, $iSizeY
For $y = 0 To $iH Step $iNoiseSize / 2
For $x = 0 To $iWO Step $iNoiseSize / 2
$iXOff = Random(0, $iNoiseSize / 2, 1)
$iYOff = Random(0, $iNoiseSize / 2, 1)
$iSizeX = $iNoiseSize - $iXOff
$iSizeY = $iNoiseSize - $iYOff
_GDIPlus_GraphicsDrawImageRectRect($hGfx_Full, $hBmp_Noise, $iXOff, $iYOff, $iSizeX, $iSizeY, $x, $y, $iSizeX, $iSizeY)
Next
Next

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_GraphicsDispose($hGfx_Noise)
_GDIPlus_BitmapDispose($hBmp_Noise)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

;=========================================
; MotionBlur
;=========================================
$aResult = DllCall($ghGDIPDll, "uint", "GdipCreateBitmapFromScan0", "int", $iWO, "int", $iH, "int", 0, "int", 0x0026200A, "ptr", 0, "int*", 0)
If @error Or Not IsArray($aResult) Then Return SetError(1, 3, False)
Local $hBmp_Full2 = $aResult[6]
Local $hGfx_Full2 = _GDIPlus_ImageGetGraphicsContext($hBmp_Full2)
_GDIPlus_GraphicsSetSmoothingMode($hGfx_Full2, 2)
DllCall($ghGDIPDll, "uint", "GdipSetInterpolationMode", "hwnd", $hGfx_Full2, "int", 7)

[/autoit] [autoit][/autoit] [autoit]

Local $tColorMatrix = DllStructCreate("float[5]; float[5]; float[5]; float[5]; float[5];")
DllStructSetData($tColorMatrix, 1, 1, 1)
DllStructSetData($tColorMatrix, 2, 1, 2)
DllStructSetData($tColorMatrix, 3, 1, 3)
DllStructSetData($tColorMatrix, 4, $fBlurTrans, 4)
DllStructSetData($tColorMatrix, 5, 1, 5)

[/autoit] [autoit][/autoit] [autoit]

$aResult = DllCall($ghGDIPDll, "int", "GdipCreateImageAttributes", "ptr*", 0)
If @error Or Not IsArray($aResult) Then Return SetError(1, 4, False)
Local $hImgAttrib = $aResult[1]
DllCall($ghGDIPDll, "int", "GdipSetImageAttributesColorMatrix", "ptr", $hImgAttrib, "int", 1, "int", 1, "ptr", DllStructGetPtr($tColorMatrix), "ptr", 0, "int", 0)

[/autoit] [autoit][/autoit] [autoit]

For $i = 1 To $iBlurDist Step 2
DllCall($ghGDIPDll, "int", "GdipDrawImageRectRectI", "hwnd", $hGfx_Full2, "hwnd", $hBmp_Full, "int", $i, "int", 0, "int", $iWO, "int", $iH, "int", 0, "int", 0, "int", $iWO, "int", $iH, "int", 2, "ptr", $hImgAttrib, "int", 0, "int", 0)
If $i >= $iBlurDist Then
DllStructSetData($tColorMatrix, 1, $fRed, 1)
DllStructSetData($tColorMatrix, 2, $fGreen, 2)
DllStructSetData($tColorMatrix, 3, $fBlue, 3)
DllStructSetData($tColorMatrix, 4, 1, 4)
DllCall($ghGDIPDll, "int", "GdipSetImageAttributesColorMatrix", "ptr", $hImgAttrib, "int", 1, "int", 1, "ptr", DllStructGetPtr($tColorMatrix), "ptr", 0, "int", 0)
EndIf
DllCall($ghGDIPDll, "int", "GdipDrawImageRectRectI", "hwnd", $hGfx_Full, "hwnd", $hBmp_Full2, "int", $i + 1, "int", 0, "int", $iWO, "int", $iH, "int", 0, "int", 0, "int", $iWO, "int", $iH, "int", 2, "ptr", $hImgAttrib, "int", 0, "int", 0)
Next
DllCall($ghGDIPDll, "int", "GdipDisposeImageAttributes", "ptr", $hImgAttrib)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_GraphicsDispose($hGfx_Full2)
_GDIPlus_BitmapDispose($hBmp_Full2)
_GDIPlus_GraphicsDispose($hGfx_Full)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

;=========================================
; Add Light
;=========================================

[/autoit] [autoit][/autoit] [autoit]

$aResult = DllCall($ghGDIPDll, "uint", "GdipCreateBitmapFromScan0", "int", $iW, "int", $iH, "int", 0, "int", 0x0026200A, "ptr", 0, "int*", 0)
If @error Or Not IsArray($aResult) Then Return SetError(1, 3, False)
Local $hBmp_Alu = $aResult[6]
Local $hGfx_Alu = _GDIPlus_ImageGetGraphicsContext($hBmp_Alu)
_GDIPlus_GraphicsSetSmoothingMode($hGfx_Alu, 2)
DllCall($ghGDIPDll, "uint", "GdipSetInterpolationMode", "hwnd", $hGfx_Alu, "int", 7)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_GraphicsDrawImage($hGfx_Alu, $hBmp_Full, -$iOverSize, 0)
_GDIPlus_BitmapDispose($hBmp_Full)

[/autoit] [autoit][/autoit] [autoit]

Local $tPointF1 = DllStructCreate("float; float;")
Local $tPointF2 = DllStructCreate("float; float;")
DllStructSetData($tPointF2, 2, $iH * $fLightScale)

[/autoit] [autoit][/autoit] [autoit]

$aResult = DllCall($ghGDIPDll, "uint", "GdipCreateLineBrush", "ptr", DllStructGetPtr($tPointF1), "ptr", DllStructGetPtr($tPointF2), "uint", 0, "uint", $iLightColor, "int", 0, "int*", 0)
If @error Or Not IsArray($aResult) Then Return SetError(1, 4, False)
Local $hBrush = $aResult[6]

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipSetLineSigmaBlend", "hwnd", $hBrush, "float", $fLightSigma, "float", 1)
DllCall($ghGDIPDll, "uint", "GdipSetLineGammaCorrection", "hwnd", $hBrush, "int", True)
DllCall($ghGDIPDll, "uint", "GdipRotateLineTransform", "hwnd", $hBrush, "float", $fLightAngle, "int", 0)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_GraphicsFillRect($hGfx_Alu, 0, 0, $iW, $iH, $hBrush)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_BrushDispose($hBrush)
_GDIPlus_GraphicsDispose($hGfx_Alu)

[/autoit] [autoit][/autoit] [autoit]

Return $hBmp_Alu
EndFunc ;==>_CreateBrushedAluminum

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func WM_PAINT($hWnd, $uMsgm, $wParam, $lParam)
_WinAPI_BitBlt($hDC, 0, 0, $iWidth, $iHeight, $hCDC, 0, 0, 0x00CC0020)
Return $GUI_RUNDEFMSG
EndFunc ;==>WM_PAINT

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Exit()
_GDIPlus_BitmapDispose($hBitmap)
_GDIPlus_GraphicsDispose($hGfxBuffer)
_WinAPI_SelectObject($hCDC, $hOBJ)
_WinAPI_DeleteObject($hBMP)
_WinAPI_DeleteDC($hCDC)
_WinAPI_ReleaseDC($hGui, $hDC)
_GDIPlus_Shutdown()
Exit
EndFunc ;==>_Exit

[/autoit]

E

**eukalyptus**

Es gibt noch die Möglichkeit per $WM_COPYDATA Message - da hat ProgAndy glaub ich mal ein Beispiel gepostet...

Dann noch per NamedPipes: Deutsche Hilfe - Funktionen ohne Beispiel

Und in meiner Signatur findest du die UDF exchange Variables.

E

**eukalyptus**

Viel interessanter als Midi Dateien finde ich die Steuerung von Midifähigen Geräten, bzw. die Steuerung vom AutoItscript durch Midi Controller.
Darin hab ich etwas Erfahrung und kann auch mal ein Beispiel schreiben, wenn ich Zeit finde...

2 Sachen musst du unbedingt noch einbauen:
@error-check bzw. IsArray($ret)-check bei den DllCalls; sonst führt das evtl zu einem Scriptabsturz, wenn du direkt danach $ret[0] verwendest...

$ret als Local deklarieren - Die UDF muss auch mit Opt("MustDeclareVars", 1) funktionieren.

Ansonsten schon mal ganz ordendlich!

E

**eukalyptus**

Du kannst WM_KillFocus - Msg abfragen und jedesmal den Fokus wieder auf Parent setzen.
Das funktioniert allerdings nur, wenn keine Controls in Parent vorhanden sind, also keine Labels, Buttons usw...

E

**eukalyptus**

Am besten misst du die Zeit in der Schleife mit TimerInit und TimerDiff.
Bei einer Framerate von 40 machst du ein Sleep mit (25 - TimerDiff)

Das fiese daran ist, dass ein Sleep(1) genausoviel Zeit benötigt wie Sleep(10), also hast du trotzdem eine Schwankungsbreite von 10ms.
evtl. hilft hier die Funktion HighPrecisionSleep (hier im Forum zu finden), oder du machst es etwas anders:

Sleep(10), wenn gemessene Zeit <= 15
Wenn Zeit >= 25ms, dann werden die Berechnungen ausgeführt.
(Wenn ich mich richtig erinnere, ist dies die Methode, wie ich sie bei SuperMario verwendet hab)

Zum KollisionsCheck:
Du könnest die Bricks in Gruppen verwalten. z.B. alle Bricks einer Zeile gehören zusammen.
Somit kannst du die ganze Gruppe überspringen, wenn die Y-Koordinate des Balles nicht passt. anstatt jedesmal einen kompletten Kollisionscheck durchzuführen...

E

**eukalyptus**

Möge die Macht mit ihm sein!

**eukalyptus**

Mit MP3 schneiden meinst du wahrscheinlich ein Framegenaues Scheiden ohne die MP3 zu decodieren (also ohne Qualtiätsverlust)
Das ist in AutoIt eingentlich möglich, aber nicht leicht.
Im Printip muss du nur die FameHeader finden und bei dort abschneiden.

Schneiden mit decodieren geht mit der Bass.dll (siehe meine Signatur)

E

**eukalyptus**

Das war wie gesagt nur der erste Test.
Die Zähne sind nicht wirklich symmetrisch.
Aber ich glaub ich weiß schon, wie das besser und einfacher geht...
Das kann ich aber erst nächste Woche probieren.

Für mich ist das deshalb so interessant, weil ich selber gelernter Schreiner bin und auch etwa 4 Jahre mit einer CNC Fräse gearbeitet hab.
Das war allerdings vor fast 10 Jahren.
Damals hatten wir zwar ein verstellbares Sägemodul, aber die Neigung musste manuell verstellt werden - also hierfür nicht geeignet!

Und JA - bitte schreib eine DXF-UDF! sowas hätte ich schon ein paar mal gebraucht

E

**eukalyptus**

Das ist mal der erste Test:

Ich biege keine AutoCad-Kurve gerade, sondern berechne die Verzahnung gleich selber!

Das Script liest eine Kurve aus einer Datei (hier noch InkScape-SVG)
und berechnet dann die Verzahnungen.
Dann wird die Verzahnung 2 Mal gradegebogen und zwar einmal auf der Unterseite und einmal auf der Oberseite
Die fertige Verzahnung wird zu Testzwecken als EMF abgespeichert.

Ein großer Teil des Codes dient nur zum Visualisieren. Ein "fertiger" Code sollte dann viel kleiner und schöner sein
Deshalb auch das Durcheinander...

Script:

Spoiler anzeigen

[autoit]

#include <Array.au3>
;#include "GDIp.au3"
#include <GDIPlus.au3>
#include <GUIConstantsEx.au3>
#include <WindowsConstants.au3>

[/autoit] [autoit][/autoit] [autoit]

Global $iOffSetX = -1
Global $iOffSetY = -1

[/autoit] [autoit][/autoit] [autoit]

Opt("MustDeclareVars", 1)
Opt("GUIOnEventMode", 1)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_Startup()

[/autoit] [autoit][/autoit] [autoit]

Global Const $PI = ATan(1) * 4
Global Const $2PI = $PI * 2
Global Const $PI2 = $PI / 2
Global Const $Deg2Rad = $PI / 180
Global Const $Rad2Deg = 180 / $PI
Global $_ME_hMSVCRT = DllOpen('msvcrt.dll')

[/autoit] [autoit][/autoit] [autoit]

Global $tPath = _Load(@ScriptDir & "\Bogen2.svg")

[/autoit] [autoit][/autoit] [autoit]

Global $iWidth = 1200
Global $iHeight = 600

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Global $hGui = GUICreate("Test", $iWidth, $iHeight)
GUISetOnEvent($GUI_EVENT_CLOSE, "_Exit")
Global $hGraphics = _GDIPlus_GraphicsCreateFromHWND($hGui)
Global $hBmpBuffer = _GDIPlus_BitmapCreateFromGraphics($iWidth, $iHeight, $hGraphics)
Global $hGfxBuffer = _GDIPlus_ImageGetGraphicsContext($hBmpBuffer)
_GDIPlus_GraphicsSetSmoothingMode($hGfxBuffer, 2)
_GDIPlus_GraphicsClear($hGfxBuffer, 0xFF000000)

[/autoit] [autoit][/autoit] [autoit]

Global $hPen = _GDIPlus_PenCreate(0xFF00FF00, 1)
Global $hPen2 = _GDIPlus_PenCreate(0xFFFF0000, 1)
Global $hPen3 = _GDIPlus_PenCreate(0xFF0000FF, 1)

[/autoit] [autoit][/autoit] [autoit]

GUIRegisterMsg($WM_PAINT, "WM_PAINT")
GUIRegisterMsg($WM_ERASEBKGND, "WM_PAINT")
GUISetState()

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

_Draw()
Global $tGears = _CalcGears($tPath, 10, 40, 18)
;#cs
Global $tFlat_Up = _Flatten($tGears, 1)
Global $tFlat_Lo = _Flatten($tGears, 0)
_Show($tPath, $tFlat_Up, 0.8, 10, 100)
_Show($tPath, $tFlat_Lo, 0.8, 10, 200)
_GDIPlus_GraphicsDrawImage($hGraphics, $hBmpBuffer, 0, 0)
;MsgBox(0, "", "")

[/autoit] [autoit][/autoit] [autoit]

_Save($tFlat_Lo, @ScriptDir & "\Unten.emf")
_Save($tFlat_Up, @ScriptDir & "\Oben.emf")
;#ce

[/autoit] [autoit][/autoit] [autoit]

While 1
Sleep(10)
WEnd

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Save($tFlat, $sFileName)
Local $iCnt = DllStructGetData($tFlat, "Cnt")
Local $aResult = DllCall($ghGDIPDll, "uint", "GdipCreatePath", "int", 0, "int*", 0)
Local $hPath = $aResult[2]

[/autoit] [autoit][/autoit] [autoit]

;DllCall($ghGDIPDll, "uint", "GdipAddPathPolygon", "hwnd", $hPath, "ptr", DllStructGetPtr($tFlat, "Pnt"), "int", $iCnt)
DllCall($ghGDIPDll, "uint", "GdipAddPathCurve3", "hwnd", $hPath, "ptr", DllStructGetPtr($tFlat, "Pnt"), "int", $iCnt, "int", 0, "int", $iCnt-1, "float", 0)
;DllCall($ghGDIPDll, "uint", "GdipClosePathFigure", "hwnd", $hPath)

[/autoit] [autoit][/autoit] [autoit]

Local $tRectF = DllStructCreate("float X; float Y; float Width; float Height;")
DllCall($ghGDIPDll, "uint", "GdipGetPathWorldBounds", "hwnd", $hPath, "ptr", DllStructGetPtr($tRectF), "hwnd", 0, "hwnd", 0)
Local $hMatrix = _GDIPlus_MatrixCreate()
_GDIPlus_MatrixTranslate($hMatrix, -DllStructGetData($tRectF, "X"), -DllStructGetData($tRectF, "Y"))
DllCall($ghGDIPDll, "uint", "GdipTransformPath", "hwnd", $hPath, "hwnd", $hMatrix)
_GDIPlus_MatrixDispose($hMatrix)
DllStructSetData($tRectF, "X", 0)
DllStructSetData($tRectF, "Y", 0)

[/autoit] [autoit][/autoit] [autoit]

Local $hPen = _GDIPlus_PenCreate(0xFF000000)

[/autoit] [autoit][/autoit] [autoit]

Local $hDC = _WinAPI_GetDC($hGui)
Local $aResult = DllCall($ghGDIPDll, "uint", "GdipRecordMetafileFileName", "wstr", $sFileName, "hwnd", $hDC, "int", 5, "ptr", DllStructGetPtr($tRectF), "int", 6, "wstr", "Platte Unten", "int*", 0)
Local $hImage = $aResult[7]
Local $hContext = _GDIPlus_ImageGetGraphicsContext($hImage) ;GraphicContext vom Metafile bekommen (um darauf zu zeichnen)
DllCall($ghGDIPDll, "uint", "GdipSetPageUnit", "hwnd", $hContext, "int", 6) ; Einheit auf mm setzen

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipDrawPath", "hwnd", $hContext, "hwnd", $hPen, "hwnd", $hPath)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_GraphicsDispose($hContext) ; Metafile abschliesen und speichern
_GDIPlus_ImageDispose($hImage) ; Metafile aus Speicher löschen

[/autoit] [autoit][/autoit] [autoit]

_WinAPI_ReleaseDC($hGui, $hDC)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath)
_GDIPlus_PenDispose($hPen)
EndFunc

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _CalcGears($tPath, $fW = 10, $fH = 20, $fR =
Local $fGA = $fR * $Deg2Rad
Local $fGA_Plus
Local $fGR = $fH / Tan($PI2 - $fGA) ; X-Offset der Schräge
Local $fGH = $fH / Cos($fGA) ; Länge der Höhe
Local $fGW = $fW + $fGR

[/autoit] [autoit][/autoit] [autoit]

Local $iCnt = DllStructGetData($tPath, "Cnt")
Local $tGears = DllStructCreate("int Cnt; float Pnt[" & $iCnt * 2 & "];")
_GearAddPoint($tGears, 0, 0)

[/autoit] [autoit][/autoit] [autoit]

Local $iStep = 0, $fX1, $fY1, $fX2 = 0, $fY2 = 0, $fD, $fA, $iIdx

[/autoit] [autoit][/autoit] [autoit]

Local $aLast, $iDir = 0
Local $fATmp = _MathEx_Atan2(DllStructGetData($tPath, "Pnt", 4), DllStructGetData($tPath, "Pnt", 3))
While $iStep < $iCnt
$iStep += 1
$fX1 = DllStructGetData($tPath, "Pnt", ($iStep - 1) * 2 + 1)
$fY1 = DllStructGetData($tPath, "Pnt", ($iStep - 1) * 2 + 2)
$fD = Sqrt(($fX1 - $fX2) ^ 2 + ($fY1 - $fY2) ^ 2)
If $fD >= $fGW * 2 Then ; Suche nächten Winkelpunkt
;ConsoleWrite("! " & $fD & @CRLF)
;_GDIPlus_GraphicsDrawLine($hGfxBuffer, $fX1+$iOffSetX, $fY1+$iOffSetY, $fX2+$iOffSetX, $fY2+$iOffSetY, $hPen2)
;_GDIPlus_GraphicsDrawLine($hGfxBuffer, $fX1+$iOffSetX, $fY1+$iOffSetY, $fX1+Cos($fA)*$fD*10+$iOffSetX, $fY1+Sin($fA)*$fD*10+$iOffSetY, $hPen2)
Do
$fA = _MathEx_Atan2($fY1 - $fY2, $fX1 - $fX2)

[/autoit] [autoit][/autoit] [autoit]

Select
Case ($fA - $fATmp) < 0
If $iDir = 1 Then
$iIdx = DllStructGetData($tGears, "Cnt")
DllStructSetData($tGears, "Cnt", $iIdx - 1)
$fGA_Plus = ($fATmp - $fA) / 2
ConsoleWrite("! Plus: " & $fGA_Plus * $Rad2Deg & " A: " & $fA * $Rad2Deg & " ATmp: " & $fATmp * $Rad2Deg & @CRLF)
_GearAddPoint($tGears, $fGH, $fA + $PI2 - $fGA + $fGA_Plus)
_ShowDrawLastPnt($tGears)
$iDir = 2
EndIf
_GearAddPoint($tGears, $fW, $fA)
;_ShowDrawLastPnt($tGears)
_GearAddPoint($tGears, $fGH, $fA - $PI2 + $fGA)
;_ShowDrawLastPnt($tGears)
$fGA_Plus = ($fATmp - $fA) / 3
ConsoleWrite("> Plus: " & $fGA_Plus * $Rad2Deg & " A: " & $fA * $Rad2Deg & " ATmp: " & $fATmp * $Rad2Deg & @CRLF)
_GearAddPoint($tGears, $fW, $fA - $fGA_Plus * 1)
;_ShowDrawLastPnt($tGears)
_GearAddPoint($tGears, $fGH, $fA + $PI2 - $fGA - $fGA_Plus * 2)
;_ShowDrawLastPnt($tGears)
;MsgBox(0,"","")
;ContinueCase
Case Else
$fGA_Plus = ($fATmp - $fA) / 2
ConsoleWrite("+ Plus: " & $fGA_Plus * $Rad2Deg & " A: " & $fA * $Rad2Deg & " ATmp: " & $fATmp * $Rad2Deg & @CRLF)
_GearAddPoint($tGears, $fW, $fA + $fGA_Plus)
_GearAddPoint($tGears, $fGH, $fA - $PI2 + $fGA)
_GearAddPoint($tGears, $fW, $fA)
_GearAddPoint($tGears, $fGH, $fA + $PI2 - $fGA)
$iDir = 1
EndSelect
$fATmp = $fA

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

$iIdx = DllStructGetData($tGears, "Cnt")
$fX2 = DllStructGetData($tGears, "Pnt", ($iIdx - 1) * 2 + 1)
$fY2 = DllStructGetData($tGears, "Pnt", ($iIdx - 1) * 2 + 2)

[/autoit] [autoit][/autoit] [autoit]

Until Sqrt(($fX1 - $fX2) ^ 2 + ($fY1 - $fY2) ^ 2) < $fGW
;ExitLoop
EndIf
WEnd
;_GDIPlus_GraphicsClear($hGfxBuffer, 0xFFFFFFFF)
_Show($tPath, $tGears)
_GDIPlus_GraphicsDrawImage($hGraphics, $hBmpBuffer, 0, 0)
MsgBox(0, "", "")
;_Exit()
Return $tGears
EndFunc ;==>_CalcGears

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _ShowDrawLastPnt($tGears)
Local $iCnt = DllStructGetData($tGears, "Cnt")
DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen2, "float", _
DllStructGetData($tGears, "Pnt", ($iCnt - 2) * 2 + 1) + $iOffSetX, "float", DllStructGetData($tGears, "Pnt", ($iCnt - 2) * 2 + 2) + $iOffSetY, "float", _
DllStructGetData($tGears, "Pnt", ($iCnt - 1) * 2 + 1) + $iOffSetX, "float", DllStructGetData($tGears, "Pnt", ($iCnt - 1) * 2 + 2) + $iOffSetY)
_GDIPlus_GraphicsDrawImage($hGraphics, $hBmpBuffer, 0, 0)
EndFunc ;==>_ShowDrawLastPnt

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _GearAddPoint($tGears, $fD, $fA)
Local $iCnt = DllStructGetData($tGears, "Cnt")
Local $fX = DllStructGetData($tGears, "Pnt", ($iCnt - 1) * 2 + 1)
Local $fY = DllStructGetData($tGears, "Pnt", ($iCnt - 1) * 2 + 2)
Local $aReturn[2]
$aReturn[0] = $fX + Cos($fA) * $fD
$aReturn[1] = $fY + Sin($fA) * $fD
DllStructSetData($tGears, "Pnt", $aReturn[0], $iCnt * 2 + 1)
DllStructSetData($tGears, "Pnt", $aReturn[1], $iCnt * 2 + 2)
DllStructSetData($tGears, "Cnt", $iCnt + 1)
Return $aReturn
EndFunc ;==>_GearAddPoint

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Draw()
_GDIPlus_GraphicsClear($hGfxBuffer, 0xFFFFFFFF)

[/autoit] [autoit][/autoit] [autoit]

_Show($tPath, 0)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

_GDIPlus_GraphicsDrawImage($hGraphics, $hBmpBuffer, 0, 0)
EndFunc ;==>_Draw

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Show($tPath, $tGears, $fScale = 1, $iOffX = 100, $iOffY = 100)
Local $iPathCnt = DllStructGetData($tPath, "Cnt")
Local $iGearCnt = DllStructGetData($tGears, "Cnt")
Local $aResult = DllCall($ghGDIPDll, "uint", "GdipCreatePath", "int", 0, "int*", 0)
Local $hPathPath = $aResult[2]
$aResult = DllCall($ghGDIPDll, "uint", "GdipCreatePath", "int", 0, "int*", 0)
Local $hPathGear = $aResult[2]

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipAddPathCurve", "hwnd", $hPathPath, "ptr", DllStructGetPtr($tPath, "Pnt"), "int", $iPathCnt)
;DllCall($ghGDIPDll, "uint", "GdipAddPathCurve3", "hwnd", $hPathGear, "ptr", DllStructGetPtr($tGears, "Pnt"), "int", $iGearCnt, "int", 0, "int", $iGearCnt-1, "float", 0)
DllCall($ghGDIPDll, "uint", "GdipAddPathPolygon", "hwnd", $hPathGear, "ptr", DllStructGetPtr($tGears, "Pnt"), "int", $iGearCnt)

[/autoit] [autoit][/autoit] [autoit]

Local $tRectF = DllStructCreate("float X; float Y; float Width; float Height;")
DllCall($ghGDIPDll, "uint", "GdipGetPathWorldBounds", "hwnd", $hPathPath, "ptr", DllStructGetPtr($tRectF), "hwnd", 0, "hwnd", 0)
Local $hMatrix = _GDIPlus_MatrixCreate()

[/autoit] [autoit][/autoit] [autoit]

If $iOffSetX = -1 Then
$iOffSetX = -DllStructGetData($tRectF, "X") + $iOffX
$iOffSetY = -DllStructGetData($tRectF, "Y") + $iOffY
EndIf

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_MatrixTranslate($hMatrix, -DllStructGetData($tRectF, "X"), -DllStructGetData($tRectF, "Y"))
DllCall($ghGDIPDll, "uint", "GdipTransformPath", "hwnd", $hPathPath, "hwnd", $hMatrix)
DllCall($ghGDIPDll, "uint", "GdipTransformPath", "hwnd", $hPathGear, "hwnd", $hMatrix)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipSetMatrixElements", "hwnd", $hMatrix, "float", 1, "float", 0, "float", 0, "float", 1, "float", 0, "float", 0)
_GDIPlus_MatrixScale($hMatrix, $fScale, $fScale)
DllCall($ghGDIPDll, "uint", "GdipTransformPath", "hwnd", $hPathPath, "hwnd", $hMatrix)
DllCall($ghGDIPDll, "uint", "GdipTransformPath", "hwnd", $hPathGear, "hwnd", $hMatrix)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipSetMatrixElements", "hwnd", $hMatrix, "float", 1, "float", 0, "float", 0, "float", 1, "float", 0, "float", 0)
_GDIPlus_MatrixTranslate($hMatrix, $iOffX, $iOffY)
DllCall($ghGDIPDll, "uint", "GdipTransformPath", "hwnd", $hPathPath, "hwnd", $hMatrix)
DllCall($ghGDIPDll, "uint", "GdipTransformPath", "hwnd", $hPathGear, "hwnd", $hMatrix)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipDrawPath", "hwnd", $hGfxBuffer, "hwnd", $hPen, "hwnd", $hPathPath)
DllCall($ghGDIPDll, "uint", "GdipDrawPath", "hwnd", $hGfxBuffer, "hwnd", $hPen3, "hwnd", $hPathGear)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_MatrixDispose($hMatrix)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

;#cs
; Bemassung
$aResult = DllCall($ghGDIPDll, "uint", "GdipGetPointCount", "hwnd", $hPathGear, "int*", 0)
Local $iCnt = $aResult[2]
Local $tPoints = DllStructCreate("float[" & $iCnt * 2 & "]")
DllCall($ghGDIPDll, "uint", "GdipGetPathPoints", "hwnd", $hPathGear, "ptr", DllStructGetPtr($tPoints), "int", $iCnt)

[/autoit] [autoit][/autoit] [autoit]

Local $fX1 = 0, $fY1 = 0, $fX2, $fY2, $fD, $fA1, $fA2, $fADiff, $fATmp
For $i = 1 To $iCnt
$fX2 = DllStructGetData($tPoints, 1, ($i - 1) * 2 + 1)
$fY2 = DllStructGetData($tPoints, 1, ($i - 1) * 2 + 2)
$fD = Sqrt(Abs(($fX2 - $fX1) ^ 2 + ($fY2 - $fY1) ^ 2))
$fA2 = 180 + _MathEx_Atan2($fY2 - $fY1, $fX2 - $fX1) * $Rad2Deg
;If $fA2 > 180 Then $fA2 = 180 + _MathEx_Atan2($fY1 - $fY2, $fX1 - $fX2) * $Rad2Deg
$fADiff = Mod(180 + $fA1 - $fA2, 360)
$fATmp = 1
If $fADiff > 180 Then
$fADiff = 360 - $fADiff
$fATmp = 0
EndIf
If $fADiff < 0 Then $fADiff += 360

[/autoit] [autoit][/autoit] [autoit]

If $i > 1 Then
If $fATmp = 1 Then
;_GDIPlus_GraphicsDrawPie($hGfxBuffer, $fX1 - 10, $fY1 - 10, 20, 20, $fA2 + 180, $fADiff, $hPen)
ConsoleWrite("! " & $fX1 - 10 & " " & $fY1 - 10 & @CRLF)
Else
;_GDIPlus_GraphicsDrawPie($hGfxBuffer, $fX1 - 10, $fY1 - 10, 20, 20, $fA1, $fADiff, $hPen)
EndIf

[/autoit] [autoit][/autoit] [autoit]

;_GDIPlus_GraphicsDrawString_C($hGfxBuffer, Round($fA2, 2), $fX1 + (($fX2 - $fX1) / 2), $fY1 + (($fY2 - $fY1) / 2), "Arial", 6.5, 0, 0xFFFF0000)
;_GDIPlus_GraphicsDrawString_C($hGfxBuffer, Round($fADiff, 2), $fX1, $fY1, "Arial", 6.5, 0, 0xFF0000FF)
;_GDIPlus_GraphicsDrawImage($hGraphics, $hBmpBuffer, 0, 0)
;MsgBox(0,"","")
EndIf

[/autoit] [autoit][/autoit] [autoit]

$fX1 = $fX2
$fY1 = $fY2
$fA1 = $fA2
Next
; Bemassung
;#ce

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPathPath)
DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPathGear)
EndFunc ;==>_Show

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func __Flatten($tFlat, $iI1, $iI2)
Local $iCnt = DllStructGetData($tFlat, "Cnt")
Local $fX1, $fY1, $fX2, $fY2, $fA

[/autoit] [autoit][/autoit] [autoit]

$fX1 = DllStructGetData($tFlat, "Pnt", $iI1 * 2 + 1)
$fY1 = DllStructGetData($tFlat, "Pnt", $iI1 * 2 + 2)
$fX2 = DllStructGetData($tFlat, "Pnt", $iI2 * 2 + 1)
$fY2 = DllStructGetData($tFlat, "Pnt", $iI2 * 2 + 2)
$fA = _MathEx_Atan2($fY2 - $fY1, $fX2 - $fX1)

[/autoit] [autoit][/autoit] [autoit]

Local $hMatrix = _GDIPlus_MatrixCreate()
_GDIPlus_MatrixTranslate($hMatrix, -$fX1, -$fY1)
DllCall($ghGDIPDll, "uint", "GdipTransformMatrixPoints", "hwnd", $hMatrix, "ptr", DllStructGetPtr($tFlat, "Pnt"), "int", $iCnt)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipSetMatrixElements", "hwnd", $hMatrix, "float", 1, "float", 0, "float", 0, "float", 1, "float", 0, "float", 0)
_GDIPlus_MatrixRotate($hMatrix, -$fA * $Rad2Deg)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipTransformMatrixPoints", "hwnd", $hMatrix, "ptr", DllStructGetPtr($tFlat, "Pnt") + $iI1 * 8, "int", $iCnt - $iI1)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_MatrixDispose($hMatrix)
EndFunc ;==>__Flatten

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Flatten($tGears, $iFlag = 1)
Local $iCnt = DllStructGetData($tGears, "Cnt")
Local $tFlat = DllStructCreate("int Cnt; float Pnt[" & $iCnt * 2 & "];")

[/autoit] [autoit][/autoit] [autoit]

If $iFlag Then
$iCnt -=3
DllCall("kernel32.dll", "none", "RtlMoveMemory", "ptr", DllStructGetPtr($tFlat, "Pnt"), "ptr", DllStructGetPtr($tGears, "Pnt") + 2 * 8, "ulong_ptr", $iCnt *
Else
DllCall("kernel32.dll", "none", "RtlMoveMemory", "ptr", DllStructGetPtr($tFlat, "Pnt"), "ptr", DllStructGetPtr($tGears, "Pnt"), "ulong_ptr", $iCnt *
EndIf
DllStructSetData($tFlat, "Cnt", $iCnt)

[/autoit] [autoit][/autoit] [autoit]

Local $aResult = DllCall($ghGDIPDll, "uint", "GdipCreatePath", "int", 0, "int*", 0)
Local $hPath = $aResult[2]
Local $tRectF = DllStructCreate("float X; float Y; float Width; float Height;")

[/autoit] [autoit][/autoit] [autoit]

Local $hMatrix = _GDIPlus_MatrixCreate()

[/autoit] [autoit][/autoit] [autoit]

For $i = 0 To $iCnt - 3 Step 4

[/autoit] [autoit][/autoit] [autoit]

__Flatten($tFlat, $i, $i + 1)
If $i < $iCnt - 3 Then __Flatten($tFlat, $i + 1, $i + 4)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipResetPath", "hwnd", $hPath)
DllCall($ghGDIPDll, "uint", "GdipAddPathPolygon", "hwnd", $hPath, "ptr", DllStructGetPtr($tFlat, "Pnt"), "int", $iCnt)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipGetPathWorldBounds", "hwnd", $hPath, "ptr", DllStructGetPtr($tRectF), "hwnd", 0, "hwnd", 0)
ConsoleWrite("- " & DllStructGetData($tRectF, "X") & " " & DllStructGetData($tRectF, "Y") & " " & DllStructGetData($tRectF, "Width") & " " & DllStructGetData($tRectF, "Height") & @CRLF)
DllCall($ghGDIPDll, "uint", "GdipSetMatrixElements", "hwnd", $hMatrix, "float", 1, "float", 0, "float", 0, "float", 1, "float", 0, "float", 0)
_GDIPlus_MatrixTranslate($hMatrix, -DllStructGetData($tRectF, "X"), -DllStructGetData($tRectF, "Y"))
DllCall($ghGDIPDll, "uint", "GdipTransformPath", "hwnd", $hPath, "hwnd", $hMatrix)
_GDIPlus_GraphicsClear($hGfxBuffer, 0xFFFFFFFF)
DllCall($ghGDIPDll, "uint", "GdipDrawPath", "hwnd", $hGfxBuffer, "hwnd", $hPen3, "hwnd", $hPath)
_GDIPlus_GraphicsDrawImage($hGraphics, $hBmpBuffer, 0, 0)
;MsgBox(0,"","")
Next
DllCall($ghGDIPDll, "uint", "GdipSetMatrixElements", "hwnd", $hMatrix, "float", 1, "float", 0, "float", 0, "float", 1, "float", 0, "float", 0)
_GDIPlus_MatrixTranslate($hMatrix, -DllStructGetData($tRectF, "X"), -DllStructGetData($tRectF, "Y"))
DllCall($ghGDIPDll, "uint", "GdipTransformMatrixPoints", "hwnd", $hMatrix, "ptr", DllStructGetPtr($tFlat, "Pnt"), "int", $iCnt)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath)
_GDIPlus_MatrixDispose($hMatrix)

[/autoit] [autoit][/autoit] [autoit]

Return $tFlat
EndFunc ;==>_Flatten

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Load($sPath, $fScale = 1)
Local $sFile = FileRead($sPath)
Local $aRegExp = StringRegExp($sFile, "(?s)\<path(.*)\/\>", 3)
$aRegExp = StringRegExp($aRegExp[0], 'd="([^"]+)', 3)
Local $aSplit = StringSplit($aRegExp[0], " ")
Local $tPath = DllStructCreate("int Cnt; float Pnt[" & $aSplit[0] * 2 & "];")
Local $iCnt = 0, $fX = 0, $fY = 0
For $i = 1 To $aSplit[0]
$aRegExp = StringRegExp($aSplit[$i], "[\d.-]+", 3)
If UBound($aRegExp) <> 2 Then ContinueLoop
$iCnt += 1
If $iCnt = 1 Then
$aRegExp[0] = 0
$aRegExp[1] = 0
EndIf
DllStructSetData($tPath, "Pnt", $fX + $aRegExp[0], ($iCnt - 1) * 2 + 1)
DllStructSetData($tPath, "Pnt", $fY + $aRegExp[1], ($iCnt - 1) * 2 + 2)
$fX += $aRegExp[0]
$fY += $aRegExp[1]
Next

[/autoit] [autoit][/autoit] [autoit]

If $fScale <> 1 Then
Local $hMatrix = _GDIPlus_MatrixCreate()
_GDIPlus_MatrixScale($hMatrix, $fScale, $fScale)
DllCall($ghGDIPDll, "uint", "GdipTransformMatrixPoints", "hwnd", $hMatrix, "ptr", DllStructGetPtr($tPath, "Pnt"), "int", $iCnt)
_GDIPlus_MatrixDispose($hMatrix)
EndIf

[/autoit] [autoit][/autoit] [autoit]

DllStructSetData($tPath, "Cnt", $iCnt)
Return $tPath
EndFunc ;==>_Load

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func WM_PAINT($hWnd, $uMsgm, $wParam, $lParam)
_GDIPlus_GraphicsDrawImage($hGraphics, $hBmpBuffer, 0, 0)
Return $GUI_RUNDEFMSG
EndFunc ;==>WM_PAINT

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Exit()
_GDIPlus_PenDispose($hPen)
_GDIPlus_PenDispose($hPen2)
_GDIPlus_PenDispose($hPen3)
_GDIPlus_GraphicsDispose($hGfxBuffer)
_GDIPlus_BitmapDispose($hBmpBuffer)
_GDIPlus_GraphicsDispose($hGraphics)
_GDIPlus_Shutdown()
Exit
EndFunc ;==>_Exit

[/autoit] [autoit][/autoit] [autoit]

Func _MathEx_Atan2($fY, $fX)
Local $aResult = DllCall($_ME_hMSVCRT, "double:cdecl", "atan2", "double", $fY, "double", $fX)
If @error Then Return SetError(1, 1, False)
Return $aResult[0]
EndFunc ;==>_MathEx_Atan2

[/autoit] [autoit][/autoit] [autoit]

Func _GDIPlus_GraphicsDrawString_C($hGraphics, $sString, $nX, $nY, $sFont = "Arial", $nSize = 10, $iFormat = 0, $iColor = 0xFF000000)
Local $hBrush = _GDIPlus_BrushCreateSolid($iColor)
Local $hFormat = _GDIPlus_StringFormatCreate($iFormat)
Local $hFamily = _GDIPlus_FontFamilyCreate($sFont)
Local $hFont = _GDIPlus_FontCreate($hFamily, $nSize)
Local $tLayout = _GDIPlus_RectFCreate($nX, $nY, 0, 0)
Local $aInfo = _GDIPlus_GraphicsMeasureString($hGraphics, $sString, $hFont, $tLayout, $hFormat)
Local $aResult = _GDIPlus_GraphicsDrawStringEx($hGraphics, $sString, $hFont, $aInfo[0], $hFormat, $hBrush)
Local $iError = @error
_GDIPlus_FontDispose($hFont)
_GDIPlus_FontFamilyDispose($hFamily)
_GDIPlus_StringFormatDispose($hFormat)
_GDIPlus_BrushDispose($hBrush)
Return SetError($iError, 0, $aResult)
EndFunc ;==>_GDIPlus_GraphicsDrawString_C

[/autoit]

Bogen2.svg:

Spoiler anzeigen

XML

<?xml version="1.0" encoding="UTF-8" standalone="no"?>
<!-- Created with Inkscape (http://www.inkscape.org/) -->


<svg
   xmlns:dc="http://purl.org/dc/elements/1.1/"
   xmlns:cc="http://creativecommons.org/ns#"
   xmlns:rdf="http://www.w3.org/1999/02/22-rdf-syntax-ns#"
   xmlns:svg="http://www.w3.org/2000/svg"
   xmlns="http://www.w3.org/2000/svg"
   xmlns:sodipodi="http://sodipodi.sourceforge.net/DTD/sodipodi-0.dtd"
   xmlns:inkscape="http://www.inkscape.org/namespaces/inkscape"
   width="210mm"
   height="297mm"
   id="svg3078"
   version="1.1"
   inkscape:version="0.48.1 "
   sodipodi:docname="Bogen2.svg">
  <defs
     id="defs3080" />
  <sodipodi:namedview
     id="base"
     pagecolor="#ffffff"
     bordercolor="#666666"
     borderopacity="1.0"
     inkscape:pageopacity="0.0"
     inkscape:pageshadow="2"
     inkscape:zoom="0.35"
     inkscape:cx="350"
     inkscape:cy="520"
     inkscape:document-units="px"
     inkscape:current-layer="layer1"
     showgrid="false"
     inkscape:window-width="1366"
     inkscape:window-height="719"
     inkscape:window-x="-4"
     inkscape:window-y="-4"
     inkscape:window-maximized="1" />
  <metadata
     id="metadata3083">
    <rdf:RDF>
      <cc:Work
         rdf:about="">
        <dc:format>image/svg+xml</dc:format>
        <dc:type
           rdf:resource="http://purl.org/dc/dcmitype/StillImage" />
        <dc:title />
      </cc:Work>
    </rdf:RDF>
  </metadata>
  <g
     inkscape:label="Ebene 1"
     inkscape:groupmode="layer"
     id="layer1">
    <path
       style="fill:none;stroke:#000000;stroke-width:0.38037771;stroke-linejoin:bevel"
       d="m 12.623162,1036.7734 0.988621,-4.7591 0.496297,-2.3766 0.50441,-2.3889 0.504491,-2.3949 0.512604,-2.395 0.512603,-2.401 0.52477,-2.4011 0.528827,-2.4011 0.53702,-2.4071 0.545133,-2.4013 0.553327,-2.4132 0.565411,-2.4071 0.573689,-2.4011 0.585773,-2.4011 0.593968,-2.39494 0.602079,-2.38876 0.610274,-2.38274 0.622358,-2.37658 0.630635,-2.37657 0.638664,-2.3644 0.646859,-2.36424 0.659026,-2.35823 0.66722,-2.35206 0.675332,-2.3459 0.687499,-2.33987 0.691555,-2.3337 0.703805,-2.32142 0.711917,-2.32146 0.724167,-2.32145 0.728223,-2.30305 0.74039,-2.3092 0.744529,-2.29694 0.756613,-2.28471 0.768946,-2.28469 0.772919,-2.27855 0.781115,-2.27246 0.79328,-2.26019 0.801476,-2.2602 0.809505,-2.25408 0.817698,-2.2467 0.825893,-2.23936 0.83806,-2.23264 0.846172,-2.22587 0.858341,-2.21915 0.866532,-2.21243 0.874646,-2.20446 0.886896,-2.19709 0.895007,-2.18916 0.907174,-2.18056 0.915369,-2.17199 0.927536,-2.1628 0.939787,-2.15423 0.947899,-2.14443 0.960065,-2.134 0.972316,-2.12421 0.980426,-2.11442 0.992596,-2.10339 1.004844,-2.09174 1.017095,-2.08135 1.029262,-2.06909 1.04143,-2.05744 1.049625,-2.04581 1.065847,-2.03232 1.078015,-2.02008 1.086209,-2.00723 1.102514,-1.99315 1.114683,-1.97844 1.122794,-1.96251 1.135044,-1.94779 1.147212,-1.9325 1.159461,-1.91657 1.167574,-1.90187 1.179741,-1.88592 1.191991,-1.87126 1.200102,-1.85532 1.212353,-1.83941 1.224521,-1.82406 1.232631,-1.80816 1.244882,-1.79283 1.252993,-1.77633 1.261188,-1.75976 1.273356,-1.74444 1.285522,-1.72791 1.289575,-1.7114 1.305885,-1.69543 1.310023,-1.6789 1.322107,-1.66237 1.326246,-1.64524 1.342469,-1.6293 1.346608,-1.61214 1.35472,-1.59561 1.366887,-1.57846 1.375081,-1.56192 1.383193,-1.54539 1.391302,-1.52825 1.40347,-1.51107 1.40761,-1.49332 1.41978,-1.47555 1.42798,-1.45717 1.43608,-1.4388 1.44419,-1.42044 1.45231,-1.40145 1.46455,-1.38184 1.46863,-1.36226 1.48086,-1.34201 1.48897,-1.32243 1.49303,-1.30159 1.5052,-1.28079 1.51339,-1.25932 1.51745,-1.23852 1.52961,-1.21708 1.53368,-1.19441 1.54592,-1.17236 1.54997,-1.14969 1.56223,-1.12643 1.5662,-1.10376 1.5744,-1.08049 1.58664,-1.05659 1.59062,-1.0327 1.59476,-1.00696 1.60286,-0.9825 1.60693,-0.95735 1.61098,-0.9335 1.61917,-0.90958 1.62315,-0.88631 1.62729,-0.86242 1.63134,-0.84037 1.63548,-0.81708 1.63539,-0.79508 1.64351,-0.77359 1.64765,-0.75156 1.64756,-0.73075 1.65577,-0.70929 1.65576,-0.68969 1.65575,-0.6689 1.66387,-0.64925 1.6599,-0.62967 1.66793,-0.61066 1.66792,-0.59172 1.66801,-0.57271 1.67198,-0.55554 1.67207,-0.53657 1.67198,-0.52003 1.67612,-0.50226 1.67612,-0.48512 1.67604,-0.46918 1.68018,-0.45264 1.68018,-0.43552 1.68017,-0.42018 1.68424,-0.40304 1.68423,-0.38773 1.68423,-0.37117 1.68423,-0.35526 1.68829,-0.33997 1.68829,-0.32341 1.68828,-0.3087 1.69235,-0.29277 1.68829,-0.27747 1.69243,-0.26202 1.69234,-0.24692 1.69234,-0.23153 1.69235,-0.2167 1.69648,-0.20215 1.69235,-0.18732 1.69648,-0.1722 1.69235,-0.15796 1.69639,-0.14335 1.69358,-0.12939 1.69483,-0.1151 1.69524,-0.1005 1.69475,-0.087 1.69442,-0.0727 1.69482,-0.0612 1.69441,-0.0429 1.69401,-0.0305 1.69317,-0.0192 1.69276,-0.005 1.69201,0.005 1.69069,0.0192 1.68994,0.0368 1.6887,0.0429 1.68746,0.0612 1.68671,0.0692 1.6854,0.0807 1.68423,0.0917 1.68341,0.10292 1.68224,0.11267 1.68101,0.12306 1.67975,0.13296 1.67895,0.14287 1.67769,0.15179 1.67645,0.1604 1.67529,0.16973 1.67406,0.17772 1.67288,0.18621 1.67158,0.19363 1.6704,0.20158 1.66925,0.20821 1.66793,0.21504 1.6671,0.22248 1.66635,0.2285 1.66471,0.23456 1.66304,0.24061 1.66271,0.24636 1.66263,0.2524 1.66188,0.25845 1.66188,0.2645 1.66106,0.27081 1.66056,0.27624 1.66023,0.28237 1.65948,0.2879 1.6594,0.29401 1.65816,0.30011 1.65824,0.30567 1.65734,0.31177 1.657,0.31727 1.65617,0.32341 1.65576,0.32892 1.65493,0.33505 1.65493,0.34057 1.6537,0.34667 1.65335,0.35158 1.65287,0.35834 1.65211,0.36324 1.65171,0.36933 1.65087,0.37487 1.65046,0.38036 1.64964,0.3865 1.64922,0.39202 1.64847,0.39753 1.64757,0.40302 1.64723,0.40856 1.64641,0.41467 1.64558,0.41959 1.64434,0.42447 1.64392,0.43059 1.64276,0.43491 1.64235,0.44101 1.64111,0.4453 1.64069,0.45018 1.63945,0.45574 1.63871,0.45999 1.63821,0.46491 1.63706,0.46979 1.63663,0.4747 1.63582,0.47837 1.63507,0.48328 1.63415,0.48756 1.63341,0.49246 1.6325,0.49614 1.63176,0.50042 1.63134,0.50413 1.6301,0.50898 1.62977,0.51206 1.62886,0.51635 1.62811,0.52065 1.62729,0.52371 1.62687,0.52739 1.62563,0.53104 1.62521,0.53471 1.62448,0.53842 1.62364,0.54147 1.62314,0.54454 1.622,0.54818 1.62124,0.55066 1.62116,0.55433 1.62033,0.55738 1.61992,0.56046 1.61959,0.56414 1.61876,0.56658 1.61868,0.57024 1.61793,0.57334 1.61793,0.57696 1.61711,0.57948 1.61627,0.58311 1.61628,0.58616 1.61553,0.58985 1.61504,0.59232 1.61421,0.59597 1.61387,0.59906 1.61347,0.60209 1.61305,0.60517 1.61221,0.60886 1.61181,0.6119 1.61098,0.61558 1.61099,0.61804 1.61023,0.6217 1.60932,0.62475 1.609,0.62846 1.60857,0.63149 1.60817,0.63459 1.60733,0.63825 1.60694,0.64128 1.60608,0.64436 1.60578,0.64805 1.60526,0.65112 1.60453,0.65417 1.60369,0.65786 1.60328,0.66026 1.60205,0.66398 1.60162,0.66643 1.60081,0.67009 1.60005,0.67255 1.59963,0.67559 1.59882,0.67807 1.59799,0.68112 1.59756,0.68358 1.59675,0.68664 1.59591,0.68908 1.59558,0.69151 1.59468,0.69401 1.59434,0.69705 1.59352,0.69888 1.60129,0.705 1.59228,0.70379 1.59144,0.7056 1.59111,0.70808 1.59022,0.71051 1.58987,0.71237 1.58945,0.71419 1.58864,0.71604 1.58779,0.71848 1.58781,0.72034 1.58697,0.72153 1.58615,0.724 1.58623,0.72583 1.58541,0.72706 1.58491,0.7289 1.58458,0.73012 1.58374,0.73195 1.58375,0.73382 1.58292,0.7344 1.58259,0.73624 1.58168,0.73747 1.58168,0.7387 1.58093,0.73992 1.58085,0.74116 1.5801,0.74236 1.58012,0.74299 1.57927,0.74421 1.57928,0.7448 1.57844,0.74608 1.57846,0.74664 1.57804,0.74728 1.57762,0.74789 1.57729,0.74908 1.57721,0.74913 1.57688,0.74973 1.57638,0.75032 1.57606,0.75097 1.57596,0.75092 1.57563,0.75157 1.57564,0.75156 1.57514,0.75156 1.57523,0.75216 1.5748,0.75218 1.5744,0.75157 1.57919,0.76015 1.57928,0.76013 1.5744,0.75156 1.57472,0.75218 1.57523,0.75217 1.57521,0.75156 1.57565,0.75156 1.57555,0.75156 1.57604,0.75095 1.57605,0.75094 1.57639,0.75033 1.5768,0.74973 1.57729,0.74913 1.5772,0.74908 1.57763,0.74789 1.57804,0.74728 1.57853,0.74664 1.57844,0.74606 1.57928,0.74482 1.5792,0.74419 1.5801,0.74301 1.58012,0.74236 1.58084,0.74115 1.58094,0.73993 1.58168,0.7387 1.58176,0.73747 1.58251,0.73624 1.58292,0.7344 1.58374,0.73382 1.58375,0.73195 1.58458,0.73012 1.58499,0.7289 1.58531,0.72706 1.58624,0.72583 1.58614,0.724 1.58707,0.72154 1.5878,0.72033 1.5878,0.71848 1.58863,0.71604 1.58947,0.71419 1.58978,0.71237 1.59029,0.7105 1.59104,0.70809 1.59152,0.7056 1.59228,0.70377 1.60121,0.70502 1.59352,0.6989 1.59434,0.69703 1.59476,0.69399 1.5955,0.69153 1.59599,0.68907 1.59674,0.68664 1.59757,0.68359 1.59799,0.68111 1.59882,0.67806 1.59963,0.67561 1.59997,0.67254 1.6008,0.6701 1.60163,0.66643 1.60212,0.66398 1.60328,0.66026 1.60362,0.65785 1.60452,0.65417 1.60527,0.65112 1.60576,0.64805 1.6061,0.64437 1.60692,0.64128 1.60734,0.63825 1.60817,0.63459 1.60858,0.63147 1.609,0.62848 1.6094,0.62475 1.61015,0.6217 1.61098,0.61804 1.61098,0.61558 1.6119,0.61189 1.61221,0.60886 1.61305,0.60518 1.61339,0.60209 1.61387,0.59906 1.61421,0.59597 1.61511,0.59231 1.61546,0.58985 1.61627,0.58617 1.61636,0.58311 1.61711,0.57948 1.61784,0.57696 1.61794,0.57334 1.61876,0.57023 1.61876,0.56659 1.6195,0.56414 1.61992,0.56046 1.62042,0.55738 1.62116,0.55433 1.62116,0.55066 1.62199,0.54818 1.62323,0.54454 1.62356,0.54147 1.62447,0.5384 1.62522,0.53473 1.62563,0.53105 1.62687,0.52738 1.62729,0.52371 1.62811,0.52064 1.62894,0.51634 1.62969,0.51207 1.6301,0.50899 1.63134,0.50413 1.63176,0.50041 1.63258,0.49615 1.63341,0.49246 1.63415,0.48755 1.63498,0.48329 1.63581,0.47837 1.63664,0.47471 1.63705,0.4698 1.63831,0.46491 1.63862,0.45999 1.63953,0.45572 1.64062,0.45018 1.64111,0.4453 1.64234,0.44103 1.64277,0.4349 1.64392,0.43058 1.64438,0.42448 1.64559,0.41958 1.64642,0.41468 1.6472,0.40854 1.64761,0.40303 1.64841,0.39753 1.64926,0.39202 1.64966,0.38649 1.65047,0.38038 1.65086,0.37487 1.65169,0.36934 1.6521,0.36323 1.6529,0.35834 1.65329,0.35158 1.65372,0.34667 1.65495,0.34057 1.65495,0.33505 1.65573,0.32893 1.65619,0.32341 1.65696,0.31727 1.65738,0.31177 1.65821,0.30566 1.65819,0.30011 1.6594,0.29401 1.6594,0.2879 1.66023,0.28237 1.66064,0.27625 1.66105,0.27081 1.66186,0.26449 1.66184,0.25845 1.66268,0.2524 1.66267,0.24636 1.66306,0.2406 1.66472,0.23456 1.66632,0.22851 1.66715,0.22247 1.66793,0.21505 1.66921,0.2082 1.6704,0.2016 1.67163,0.19363 1.67281,0.18621 1.67407,0.1777 1.6753,0.16973 1.67647,0.1604 1.67774,0.15195 1.67893,0.14287 1.67976,0.13296 1.68096,0.12306 1.68222,0.11267 1.6834,0.10292 1.68423,0.0917 1.68546,0.0807 1.68667,0.0692 1.68748,0.0612 1.6887,0.0429 1.68993,0.0369 1.69073,0.0192 1.69199,0.005 1.69274,-0.005 1.6932,-0.0192 1.694,-0.0305 1.69439,-0.0429 1.69481,-0.0612 1.69439,-0.0727 1.69483,-0.087 1.69524,-0.1005 1.69475,-0.1151 1.69358,-0.12939 1.69649,-0.14335 1.69234,-0.15796 1.6964,-0.17222 1.69243,-0.1873 1.6964,-0.20215 1.69234,-0.21671 1.69243,-0.23152 1.69234,-0.24692 1.69235,-0.26202 1.68828,-0.27747 1.69235,-0.29277 1.68829,-0.3087 1.68837,-0.32342 1.68828,-0.33996 1.68424,-0.35526 1.68423,-0.37118 1.68423,-0.38772 1.68424,-0.40304 1.68017,-0.42018 1.68018,-0.43552 1.68018,-0.45264 1.67603,-0.46918 1.67605,-0.48513 1.67612,-0.50225 1.67206,-0.52003 1.67198,-0.53657 1.67206,-0.55554 1.66793,-0.57271 1.66802,-0.59172 1.66792,-0.61067 1.65981,-0.62968 1.66387,-0.64925 1.65576,-0.6689 1.65576,-0.68967 1.65576,-0.70929 1.64765,-0.73075 1.64756,-0.75158 1.6436,-0.77357 1.63539,-0.79508 1.6354,-0.8171 1.63134,-0.84036 1.62729,-0.86243 1.62322,-0.88631 1.6191,-0.90957 1.61106,-0.93349 1.60693,-0.95737 1.60287,-0.9825 1.59475,-1.00696 1.59061,-1.0327 1.58657,-1.05659 1.57439,-1.08049 1.56629,-1.10375 1.56214,-1.12646 1.54998,-1.14966 1.54592,-1.17236 1.53375,-1.19441 1.52962,-1.21709 1.51745,-1.23852 1.51331,-1.25931 1.50528,-1.28079 1.49303,-1.30159 1.48898,-1.32244 1.48077,-1.34201 1.46862,-1.36226 1.46455,-1.38183 1.4524,-1.40145 1.44419,-1.42044 1.43608,-1.43881 1.42789,-1.45716 1.41987,-1.47556 1.40752,-1.49332 1.40356,-1.51106 1.3913,-1.52826 1.38319,-1.54538 1.375,-1.56193 1.36697,-1.57847 1.35472,-1.59559 1.34653,-1.61214 1.34246,-1.6293 1.32625,-1.64525 1.3222,-1.66236 1.30993,-1.6789 1.30589,-1.69546 1.28966,-1.71139 1.28552,-1.7279 1.27336,-1.74443 1.26111,-1.75976 1.25298,-1.77634 1.24488,-1.79283 1.23273,-1.80815 1.22451,-1.82407 1.21227,-1.83941 1.20011,-1.85531 1.19198,-1.87125 1.17983,-1.88595 1.16749,-1.90186 1.15946,-1.91657 1.14721,-1.9325 1.13504,-1.94779 1.12288,-1.96251 1.11468,-1.97844 1.10243,-1.99313 1.08622,-2.00724 1.07809,-2.02008 1.06585,-2.03233 1.04963,-2.04581 1.04142,-2.05744 1.02927,-2.06909 1.01701,-2.08135 1.00485,-2.09174 0.9927,-2.10338 0.9804,-2.11442 0.9722,-2.1242 0.9602,-2.13401 0.9479,-2.14444 0.9397,-2.15423 0.9276,-2.1628 0.9153,-2.17199 0.9072,-2.18056 0.895,-2.18916 0.8869,-2.19709 0.8746,-2.20445 0.8665,-2.21243 0.8585,-2.21915 0.8461,-2.22587 0.8381,-2.23264 0.8258,-2.23937 0.8177,-2.24669 0.8096,-2.25409 0.8014,-2.26018 0.7933,-2.26019 0.7812,-2.27246 0.7729,-2.27855 0.7688,-2.28469 0.7567,-2.2847 0.7446,-2.29695 0.7404,-2.3092 0.7282,-2.30307 0.7241,-2.32143 0.7119,-2.32146 0.7038,-2.32142 0.6916,-2.33372 0.6875,-2.33981 0.6754,-2.34595 0.6671,-2.35206 0.6591,-2.3582 0.6468,-2.36431 0.6387,-2.36433 0.6306,-2.37656 0.6224,-2.37658 0.6102,-2.38271 0.6021,-2.3888 0.594,-2.39495 0.5858,-2.40106 0.5736,-2.40108 0.5655,-2.40721 0.5533,-2.4133 0.5451,-2.40109 0.537,-2.40721 0.5288,-2.40105 0.5249,-2.40108 0.5126,-2.40109 0.5126,-2.39492 0.5044,-2.39495 0.5045,-2.3888 0.4963,-2.3766 0.9885,-4.75925"
       id="polygon3007"
       inkscape:connector-curvature="0"
       sodipodi:nodetypes="ccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccc" />
  </g>
</svg>

Alles anzeigen

Die fertigen EMF´s hab ich in einem Grafikprogramm zerschnitten und Kante an Kante zusammengebaut - Das Ergebnis reicht fast an die original-Kurve heran:
Der Inhalt kann nicht angezeigt werden, da er nicht mehr verfügbar ist.

Das Ergebnis dann noch in MPR umzuwandeln, sollte das geringste Problem sein...

Wie gedenkst du denn eigentlich die Verzahnung zu fräsen?
Kann deine CNC den Fräskopf bzw. Sägeblatt neigen?

Ach ja: In Zeile 46 kannst mit den Parametern Breite, Höhe und Steigungswinkel einstellen!

E

**eukalyptus**

Ich hab da schon mal eine Idee.
Wird aber noch dauern, bis ich das ausprobieren kann...

**eukalyptus**

Sind die grünen Einzelfelder nur durch die 4 Eckpunkte definiert, oder sind die Kanten tatsächlich geschwungen und das soll auch mitberechnet werden?

**eukalyptus**

Vielleicht erkennst du selber deinen Fehler anhand dieses Scriptes:

[autoit]

$Text1 = "Dies ist ein 21 Test"
$Text2 = "Dies ist ein 2 Test"

[/autoit][autoit][/autoit][autoit]

MsgBox(64, "Test", StringReplace($Text1, $Text2, ""))

[/autoit]

**eukalyptus**

Die "saubere" Lösung wäre WM_KEYUP:

Spoiler anzeigen

[autoit]

#include <GUIConstantsEx.au3>
#include <WindowsConstants.au3>

[/autoit] [autoit][/autoit] [autoit]

Global Const $VK_ADD = 0x6B
Global Const $VK_SUBTRACT = 0x6D

[/autoit] [autoit][/autoit] [autoit]

Global $iStart = 0

[/autoit] [autoit][/autoit] [autoit]

Global $hGui = GUICreate("Test")
GUIRegisterMsg($WM_KEYDOWN, "WM_KEYDOWN")
GUIRegisterMsg($WM_KEYUP, "WM_KEYUP")
GUISetState(@SW_SHOW, $hGui)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

While GUIGetMsg() <> $GUI_EVENT_CLOSE
WEnd

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func WM_KEYDOWN($hWnd, $msg, $wParam, $lParam)
Switch $wParam
Case $VK_ADD
$iStart += 1
ToolTip("Add: " & $iStart)
Case $VK_SUBTRACT
$iStart -= 1
ToolTip("Sub: " & $iStart)
EndSwitch
Return 'GUI_RUNDEFMSG'
EndFunc ;==>WM_KEYDOWN

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func WM_KEYUP($hWnd, $msg, $wParam, $lParam)
Switch $wParam
Case $VK_ADD, $VK_SUBTRACT
MsgBox(0, "", "es wurde bei: " & $iStart & " losgelassen")
EndSwitch
Return 'GUI_RUNDEFMSG'
EndFunc ;==>WM_KEYUP

[/autoit]

Allerdings setzt diese Variante ein GUI voraus...

E

**eukalyptus**

Ich zeichne einen Punkt auf einen Pfad, verzerre diesen als Wand bzw. Boden und lese die neuen Koordinaten wieder aus.

Das hast du wahrscheinlich nicht verstanden, deshalb probier mal dieses Script:

Spoiler anzeigen

[autoit]

#include <GDIPlus.au3>
#include <GUIConstantsEx.au3>
#include <WindowsConstants.au3>

[/autoit] [autoit][/autoit] [autoit]

Opt("MustDeclareVars", 1)
Opt("GUIOnEventMode", 1)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_Startup()

[/autoit] [autoit][/autoit] [autoit]

Global $iWidth = 500
Global $iHeight = 500

[/autoit] [autoit][/autoit] [autoit]

Global $fPersp = 0.2

[/autoit] [autoit][/autoit] [autoit]

Global $tWarp_V = DllStructCreate("float[8];")
Global $pWarp_V = DllStructGetPtr($tWarp_V)
DllStructSetData($tWarp_V, 1, ($iWidth / 2) - ($iWidth * $fPersp), 1)
DllStructSetData($tWarp_V, 1, ($iWidth / 2) - ($iWidth * $fPersp), 2)
DllStructSetData($tWarp_V, 1, ($iWidth / 2) - ($iWidth * $fPersp), 3)
DllStructSetData($tWarp_V, 1, ($iWidth / 2) + ($iWidth * $fPersp), 4)
DllStructSetData($tWarp_V, 1, 0, 5)
DllStructSetData($tWarp_V, 1, 0, 6)
DllStructSetData($tWarp_V, 1, 0, 7)
DllStructSetData($tWarp_V, 1, $iHeight,

[/autoit] [autoit][/autoit] [autoit]

Global $tWarp_H = DllStructCreate("float[8];")
Global $pWarp_H = DllStructGetPtr($tWarp_H)
DllStructSetData($tWarp_H, 1, ($iWidth / 2) - ($iWidth * $fPersp), 1)
DllStructSetData($tWarp_H, 1, ($iHeight / 2) + ($iHeight * $fPersp), 2)
DllStructSetData($tWarp_H, 1, ($iWidth / 2) + ($iWidth * $fPersp), 3)
DllStructSetData($tWarp_H, 1, ($iHeight / 2) + ($iHeight * $fPersp), 4)
DllStructSetData($tWarp_H, 1, 0, 5)
DllStructSetData($tWarp_H, 1, $iHeight, 6)
DllStructSetData($tWarp_H, 1, $iWidth, 7)
DllStructSetData($tWarp_H, 1, $iHeight,

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Global $hGui = GUICreate("GDI+ Script by Eukalyptus", $iWidth + 200, $iHeight)
GUISetOnEvent($GUI_EVENT_CLOSE, "_Exit")
Global $hGraphics = _GDIPlus_GraphicsCreateFromHWND($hGui)
Global $hBmpBuffer = _GDIPlus_BitmapCreateFromGraphics($iWidth + 200, $iHeight, $hGraphics)
Global $hGfxBuffer = _GDIPlus_ImageGetGraphicsContext($hBmpBuffer)
_GDIPlus_GraphicsSetSmoothingMode($hGfxBuffer, 2)
_GDIPlus_GraphicsClear($hGfxBuffer, 0xFF000000)

[/autoit] [autoit][/autoit] [autoit]

Global $hPen = _GDIPlus_PenCreate(0xFF00FF00, 1)
Global $hPen2 = _GDIPlus_PenCreate(0xFFFF0000, 1)

[/autoit] [autoit][/autoit] [autoit]

GUIRegisterMsg($WM_PAINT, "WM_PAINT")
GUIRegisterMsg($WM_ERASEBKGND, "WM_PAINT")

[/autoit] [autoit][/autoit] [autoit]

GUISetState()

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

While 1
_Draw()
Sleep(10)
WEnd

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Draw()
Local Static $fRect_W = Random(5, 10), $fRect_H = Random(5, 10), $fRect_T = Random(5, 10)
Local Static $fRect_X = Random(0, 100 - $fRect_W), $fRect_Y = Random(0, 100 - $fRect_H), $iRect_Z = Int(-$fRect_T)
$iRect_Z += 1

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_GraphicsClear($hGfxBuffer, 0xFF000000)

[/autoit] [autoit][/autoit] [autoit]

If $iRect_Z > 100 Then
$fRect_W = Random(5, 10) ; Neue Breite
$fRect_H = Random(5, 10) ; Neue Höhe
$fRect_T = Random(5, 10) ; Neue Tiefe
$iRect_Z = Int(-$fRect_T)
$fRect_X = Random(0, 100 - $fRect_W) ; Neue Position X (0..100% von $iWidth) Range kann beliebig gewählt werden, aber derselbe Wert muss später auch bei Warp verwendet werden
$fRect_Y = Random(0, 100 - $fRect_H) ; Neue Position Y
EndIf

[/autoit] [autoit][/autoit] [autoit]

Local $aResult = DllCall($ghGDIPDll, "uint", "GdipCreatePath", "int", 0, "int*", 0) ;neuen Pfad erstellen
Local $hPath_H = $aResult[2]
$aResult = DllCall($ghGDIPDll, "uint", "GdipCreatePath", "int", 0, "int*", 0) ;neuen Pfad erstellen
Local $hPath_V = $aResult[2]

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipAddPathRectangle", "hwnd", $hPath_H, "float", $fRect_X, "float", $iRect_Z, "float", $fRect_W, "float", $fRect_T) ; Rechteck in Pfad einfügen
DllCall($ghGDIPDll, "uint", "GdipAddPathRectangle", "hwnd", $hPath_V, "float", $fRect_Y, "float", $iRect_Z, "float", $fRect_H, "float", $fRect_T)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

;#####################################################################
; nur um zu demonstrieren, wie der Pfad verzerrt bzw. verwendet wird
$aResult = DllCall($ghGDIPDll, "uint", "GdipClonePath", "hwnd", $hPath_H, "int*", 0)
Local $hPath_H_Clone = $aResult[2]
$aResult = DllCall($ghGDIPDll, "uint", "GdipClonePath", "hwnd", $hPath_V, "int*", 0)
Local $hPath_V_Clone = $aResult[2]
DllCall($ghGDIPDll, "uint", "GdipAddPathRectangle", "hwnd", $hPath_H_Clone, "float", 0, "float", 0, "float", 100, "float", 100)
DllCall($ghGDIPDll, "uint", "GdipAddPathRectangle", "hwnd", $hPath_V_Clone, "float", 0, "float", 0, "float", 100, "float", 100)

[/autoit] [autoit][/autoit] [autoit]

$aResult = DllCall($ghGDIPDll, "uint", "GdipClonePath", "hwnd", $hPath_H_Clone, "int*", 0)
Local $hPath_H_Clone2 = $aResult[2]
$aResult = DllCall($ghGDIPDll, "uint", "GdipClonePath", "hwnd", $hPath_V_Clone, "int*", 0)
Local $hPath_V_Clone2 = $aResult[2]

[/autoit] [autoit][/autoit] [autoit]

Local $hMatrix = _GDIPlus_MatrixCreate()
_GDIPlus_MatrixTranslate($hMatrix, $iWidth, 0)
DllCall($ghGDIPDll, "uint", "GdipTransformPath", "hwnd", $hPath_H_Clone, "hwnd", $hMatrix)
_GDIPlus_MatrixTranslate($hMatrix, 100, 0)
DllCall($ghGDIPDll, "uint", "GdipTransformPath", "hwnd", $hPath_V_Clone, "hwnd", $hMatrix)
_GDIPlus_MatrixDispose($hMatrix)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipDrawPath", "hwnd", $hGfxBuffer, "hwnd", $hPen2, "hwnd", $hPath_H_Clone)
DllCall($ghGDIPDll, "uint", "GdipDrawPath", "hwnd", $hGfxBuffer, "hwnd", $hPen2, "hwnd", $hPath_V_Clone)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipWarpPath", "hwnd", $hPath_H_Clone2, "hwnd", 0, "ptr", $pWarp_H, "int", 4, "float", 0, "float", 0, "float", 100, "float", 100, "int", 0, "float", 0)
DllCall($ghGDIPDll, "uint", "GdipWarpPath", "hwnd", $hPath_V_Clone2, "hwnd", 0, "ptr", $pWarp_V, "int", 4, "float", 0, "float", 0, "float", 100, "float", 100, "int", 0, "float", 0)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipDrawPath", "hwnd", $hGfxBuffer, "hwnd", $hPen2, "hwnd", $hPath_H_Clone2)
DllCall($ghGDIPDll, "uint", "GdipDrawPath", "hwnd", $hGfxBuffer, "hwnd", $hPen2, "hwnd", $hPath_V_Clone2)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath_V_Clone)
DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath_H_Clone)
DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath_V_Clone2)
DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath_H_Clone2)
;#####################################################################

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipWarpPath", "hwnd", $hPath_H, "hwnd", 0, "ptr", $pWarp_H, "int", 4, "float", 0, "float", 0, "float", 100, "float", 100, "int", 0, "float", 0) ; Parameter 7 und 8 sollten den gleichen Wert haben, wie $iRect_X bzw. $iRect_Z
DllCall($ghGDIPDll, "uint", "GdipWarpPath", "hwnd", $hPath_V, "hwnd", 0, "ptr", $pWarp_V, "int", 4, "float", 0, "float", 0, "float", 100, "float", 100, "int", 0, "float", 0) ; Parameter 7 und 8 sollten den gleichen Wert haben, wie $iRect_Y bzw. $iRect_Z

[/autoit] [autoit][/autoit] [autoit]

Local $tPoints_H = DllStructCreate("float[8];")
Local $tPoints_V = DllStructCreate("float[8];")

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipGetPathPoints", "hwnd", $hPath_H, "ptr", DllStructGetPtr($tPoints_H), "int", 4) ; Die 4 Expunkte des Rechtecks(Horizontal) in die Struct lesen
DllCall($ghGDIPDll, "uint", "GdipGetPathPoints", "hwnd", $hPath_V, "ptr", DllStructGetPtr($tPoints_V), "int", 4) ; Die 4 Expunkte des Rechtecks(Vertikal) in die Struct lesen

[/autoit] [autoit][/autoit] [autoit]

Local $aP_H[8][2], $aP_V[8][2] ;Zum leichteren Verständniss wandle ich die Struct in ein Array
For $i = 0 To 7
For $j = 0 To 1
$aP_H[$i][$j] = DllStructGetData($tPoints_H, 1, $i * 2 + $j + 1)
Next
Next
For $i = 0 To 7
For $j = 0 To 1
$aP_V[$i][$j] = DllStructGetData($tPoints_V, 1, $i * 2 + $j + 1)
Next
Next

[/autoit] [autoit][/autoit] [autoit]

;Punkte Horizontal
; 0---1
; / \
;3------2

[/autoit] [autoit][/autoit] [autoit]

;Punkte Vertikal
;3--__
;| --0
;| |
;| __--1
;2--

[/autoit] [autoit][/autoit] [autoit]

;Punkte 3D
;0----1
;|\ |\
;| 4----5
;3----2 |
; \| \|
; 7----6

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $aP_H[0][0], "float", $aP_V[0][1], "float", $aP_H[1][0], "float", $aP_V[0][1]);0-1
DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $aP_H[3][0], "float", $aP_V[3][1], "float", $aP_H[2][0], "float", $aP_V[3][1]);3-2

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $aP_H[0][0], "float", $aP_V[1][1], "float", $aP_H[1][0], "float", $aP_V[1][1]);4-5
DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $aP_H[3][0], "float", $aP_V[2][1], "float", $aP_H[2][0], "float", $aP_V[2][1]);7-6

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $aP_H[0][0], "float", $aP_V[0][1], "float", $aP_H[3][0], "float", $aP_V[3][1]);0-3
DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $aP_H[1][0], "float", $aP_V[0][1], "float", $aP_H[2][0], "float", $aP_V[3][1]);1-2

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $aP_H[0][0], "float", $aP_V[1][1], "float", $aP_H[3][0], "float", $aP_V[2][1]);4-7
DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $aP_H[1][0], "float", $aP_V[1][1], "float", $aP_H[2][0], "float", $aP_V[2][1]);5-6

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $aP_H[0][0], "float", $aP_V[0][1], "float", $aP_H[0][0], "float", $aP_V[1][1]);0-4
DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $aP_H[1][0], "float", $aP_V[0][1], "float", $aP_H[1][0], "float", $aP_V[1][1]);1-5

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $aP_H[3][0], "float", $aP_V[3][1], "float", $aP_H[3][0], "float", $aP_V[2][1]);3-7
DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $aP_H[2][0], "float", $aP_V[3][1], "float", $aP_H[2][0], "float", $aP_V[2][1]);2-6

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath_V) ;Pfad löschen
DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath_H) ;Pfad löschen
_GDIPlus_GraphicsDrawImage($hGraphics, $hBmpBuffer, 0, 0)
EndFunc ;==>_Draw

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func WM_PAINT($hWnd, $uMsgm, $wParam, $lParam)
_GDIPlus_GraphicsDrawImage($hGraphics, $hBmpBuffer, 0, 0)
Return $GUI_RUNDEFMSG
EndFunc ;==>WM_PAINT

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Exit()
_GDIPlus_PenDispose($hPen)
_GDIPlus_PenDispose($hPen2)
_GDIPlus_GraphicsDispose($hGfxBuffer)
_GDIPlus_BitmapDispose($hBmpBuffer)
_GDIPlus_GraphicsDispose($hGraphics)
_GDIPlus_Shutdown()
Exit
EndFunc ;==>_Exit

[/autoit]

Rechts siehst du die unverzerrten Pfade "Horizontal" und "Vertikal"
Im linken Bildauschnitt sind in Rot gezeichnet die verzerrten Pfade und in Grün die Linien, die ich aus den verzerrten Koordinaten auslese!

Diese Methode stimmt nicht wirklich, denn eigenlich müsste man für jede Ebene des Quaders einen eigenen Pfad ertellen und verzerren.
(Das hab ich bei meinem BlockOut-Versuch gemacht: Blockout 3D Tetris)
Das ist mir meistens zu Aufwändig, aber auch so ist das Ergebnis ganz OK.

E

**eukalyptus**

Verwendest du AutoIt 3.3.8.1?

Bei diesem DllCall wird eine Struct via "struct*" übergeben und das geht erst ab 3.3.8.0
Kann aber ohne weiteres auf "ptr", DllStructGetPtr($tData_P) geändert werden... (natürlich überall im Script)

Einige der DllCalls sind die GDIPlus Funktionen, welche nicht in der Standard UDF enthalten sind.
Das Arbeiten mit Structs bringt in diesem Fall einen Geschwindigkeitsvorteil, da nicht jedesmal zwischen Structs und AutoIt-Arrays gewandelt werden muss.

z.B.: $tWarp_V in Zeile 24: ich erstelle diese Struct nur einmal selber. Würde ich die Funktion _GDIPlus_PathWarp aus der GDIp.au3 verwenden, dann würde diese Struct bei jedem Aufruf erneut ertellt und befüllt werden - und das kostet Zeit!

E

**eukalyptus**

Nach langer Pause hab ich mich mal wieder mit GDI+ gespielt.

viel Vergnügen!

Der Inhalt kann nicht angezeigt werden, da er nicht mehr verfügbar ist.

Spoiler anzeigen

[autoit]

#include <GDIPlus.au3>
#include <GUIConstantsEx.au3>
#include <Misc.au3>
#include <WinAPI.au3>
#include <WindowsConstants.au3>

[/autoit] [autoit][/autoit] [autoit]

Opt("MustDeclareVars", 1)
Opt("GUIOnEventMode", 1)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_Startup()

[/autoit] [autoit][/autoit] [autoit]

Global $iWidth = 500
Global $iHeight = 400
Global $iStyle = $GUI_SS_DEFAULT_GUI, $iExStyle = 0, $iX = -1, $iY = -1

[/autoit] [autoit][/autoit] [autoit]

If MsgBox(4, "Fullscreen?", "Fullscreen?") = 6 Then
$iWidth = @DesktopWidth
$iHeight = @DesktopHeight
$iStyle = $WS_POPUP
$iExStyle = $WS_EX_TOPMOST
$iX = 0
$iY = 0
_WinAPI_ShowCursor(False)
EndIf

[/autoit] [autoit][/autoit] [autoit]

Global $iPlanes = 16
Global $iLines = 32
Global $iCount = $iPlanes * $iLines
Global $fPersp = 0.04
Global $fSpeed = 0.2

[/autoit] [autoit][/autoit] [autoit]

Global $hMatrix_Speed = _GDIPlus_MatrixCreate()
_GDIPlus_MatrixTranslate($hMatrix_Speed, 0, $fSpeed)

[/autoit] [autoit][/autoit] [autoit]

Global $tWarp_V = DllStructCreate("float[8];")
Global $pWarp_V = DllStructGetPtr($tWarp_V)
DllStructSetData($tWarp_V, 1, 0, 1)
DllStructSetData($tWarp_V, 1, $iHeight, 2)
DllStructSetData($tWarp_V, 1, 0, 3)
DllStructSetData($tWarp_V, 1, 0, 4)
DllStructSetData($tWarp_V, 1, ($iWidth / 2) - ($iWidth * $fPersp), 5)
DllStructSetData($tWarp_V, 1, ($iHeight / 2) + ($iHeight * $fPersp), 6)
DllStructSetData($tWarp_V, 1, ($iWidth / 2) - ($iWidth * $fPersp), 7)
DllStructSetData($tWarp_V, 1, ($iHeight / 2) - ($iHeight * $fPersp),

[/autoit] [autoit][/autoit] [autoit]

Global $tWarp_H = DllStructCreate("float[8];")
Global $pWarp_H = DllStructGetPtr($tWarp_H)
DllStructSetData($tWarp_H, 1, $iWidth, 1)
DllStructSetData($tWarp_H, 1, $iHeight, 2)
DllStructSetData($tWarp_H, 1, 0, 3)
DllStructSetData($tWarp_H, 1, $iHeight, 4)
DllStructSetData($tWarp_H, 1, ($iWidth / 2) + ($iWidth * $fPersp), 5)
DllStructSetData($tWarp_H, 1, ($iHeight / 2) + ($iHeight * $fPersp), 6)
DllStructSetData($tWarp_H, 1, ($iWidth / 2) - ($iWidth * $fPersp), 7)
DllStructSetData($tWarp_H, 1, ($iHeight / 2) + ($iHeight * $fPersp),

[/autoit] [autoit][/autoit] [autoit]

Global $tData = DllStructCreate("int Count; ptr Points; ptr Types;")
Global $pData = DllStructGetPtr($tData)
Global $tData_P = DllStructCreate("float[" & $iCount * 2 & "]")
Global $pData_P = DllStructGetPtr($tData_P)
Global $tData_T = DllStructCreate("ubyte[" & $iCount & "]")
Global $pData_T = DllStructGetPtr($tData_T)
DllStructSetData($tData, "Count", $iCount)
DllStructSetData($tData, "Points", $pData_P)
DllStructSetData($tData, "Types", $pData_T)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Global $tPoints_V = DllStructCreate("float[" & $iCount * 2 & "];")
Global $pPoints_V = DllStructGetPtr($tPoints_V)
For $j = 0 To $iLines - 1
DllStructSetData($tPoints_V, 1, Random(-300, 300), $j * 2 + 1)
DllStructSetData($tPoints_V, 1, 0, $j * 2 + 2)
Next
For $i = 1 To $iPlanes - 1
For $j = 0 To $iLines - 1
DllStructSetData($tPoints_V, 1, _CalcNewPoint(DllStructGetData($tPoints_V, 1, (($i - 1) * $iLines + $j) * 2 + 1)), ($i * $iLines + $j) * 2 + 1)
DllStructSetData($tPoints_V, 1, $i, ($i * $iLines + $j) * 2 + 2)
Next
Next

[/autoit] [autoit][/autoit] [autoit]

Global $tPoints_H = DllStructCreate("float[" & $iCount * 2 & "];")
Global $pPoints_H = DllStructGetPtr($tPoints_H)
For $j = 0 To $iLines - 1
DllStructSetData($tPoints_H, 1, Random(-300, 300), $j * 2 + 1)
DllStructSetData($tPoints_H, 1, 0, $j * 2 + 2)
Next
For $i = 1 To $iPlanes - 1
For $j = 0 To $iLines - 1
DllStructSetData($tPoints_H, 1, _CalcNewPoint(DllStructGetData($tPoints_H, 1, (($i - 1) * $iLines + $j) * 2 + 1)), ($i * $iLines + $j) * 2 + 1)
DllStructSetData($tPoints_H, 1, $i, ($i * $iLines + $j) * 2 + 2)
Next
Next

[/autoit] [autoit][/autoit] [autoit]

Global $tWarped_H = DllStructCreate("float[" & $iCount * 2 & "];")
Global $pWarped_H = DllStructGetPtr($tWarped_H)
Global $tWarped_V = DllStructCreate("float[" & $iCount * 2 & "];")
Global $pWarped_V = DllStructGetPtr($tWarped_V)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Global $hGui = GUICreate("GDI+ Script by Eukalyptus", $iWidth, $iHeight, $iX, $iY, $iStyle, $iExStyle)
GUISetOnEvent($GUI_EVENT_CLOSE, "_Exit")
Global $hDC = _WinAPI_GetDC($hGui)
Global $hBMP = _WinAPI_CreateCompatibleBitmap($hDC, $iWidth, $iHeight)
Global $hBmpTmp = _GDIPlus_BitmapCreateFromHBITMAP($hBMP)
_WinAPI_DeleteObject($hBMP)
$hBMP = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hBmpTmp)
_GDIPlus_BitmapDispose($hBmpTmp)
Global $hCDC = _WinAPI_CreateCompatibleDC($hDC)
Global $hOBJ = _WinAPI_SelectObject($hCDC, $hBMP)
Global $hGfxBuffer = _GDIPlus_GraphicsCreateFromHDC($hCDC)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_GraphicsSetSmoothingMode($hGfxBuffer, 2)
_GDIPlus_GraphicsClear($hGfxBuffer, 0xFF000000)

[/autoit] [autoit][/autoit] [autoit]

Global $hPen = _GDIPlus_PenCreate(0xFF005500, 1)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

GUIRegisterMsg($WM_PAINT, "WM_PAINT")
GUIRegisterMsg($WM_ERASEBKGND, "WM_PAINT")

[/autoit] [autoit][/autoit] [autoit]

GUISetState()

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

While 1
Select
Case _IsPressed("25")
_Move_H(0.5)
Case _IsPressed("27")
_Move_H(-0.5)
Case _IsPressed("26")
_Move_V(0.5)
Case _IsPressed("28")
_Move_V(-0.5)
EndSelect
_Draw()
Sleep(10)
WEnd

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Move_H($fMove)
Local $hMatrix = _GDIPlus_MatrixCreate()
DllCall($ghGDIPDll, "uint", "GdipShearMatrix", "hwnd", $hMatrix, "float", $fMove, "float", 0, "int", 0)
DllCall($ghGDIPDll, "uint", "GdipTransformMatrixPoints", "hwnd", $hMatrix, "ptr", $pPoints_H, "int", $iCount)
_GDIPlus_MatrixDispose($hMatrix)
EndFunc ;==>_Move_H

[/autoit] [autoit][/autoit] [autoit]

Func _Move_V($fMove)
Local $hMatrix = _GDIPlus_MatrixCreate()
DllCall($ghGDIPDll, "uint", "GdipShearMatrix", "hwnd", $hMatrix, "float", $fMove, "float", 0, "int", 0)
DllCall($ghGDIPDll, "uint", "GdipTransformMatrixPoints", "hwnd", $hMatrix, "ptr", $pPoints_V, "int", $iCount)
_GDIPlus_MatrixDispose($hMatrix)
EndFunc ;==>_Move_V

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _CalcNewPoint($fOld)
Local $fTmp
Do
$fTmp = Random(-30, 30)
Until Abs($fOld + $fTmp) < 300; And Abs($fX + $fTmp) > 10
Return $fOld + $fTmp
EndFunc ;==>_CalcNewPoint

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Draw()
DllCall($ghGDIPDll, "uint", "GdipTransformMatrixPoints", "hwnd", $hMatrix_Speed, "ptr", $pPoints_H, "int", $iCount)
DllCall($ghGDIPDll, "uint", "GdipTransformMatrixPoints", "hwnd", $hMatrix_Speed, "ptr", $pPoints_V, "int", $iCount)

[/autoit] [autoit][/autoit] [autoit]

If DllStructGetData($tPoints_H, 1, 2) >= 1 Then
Local $fX, $fTmp
DllCall("kernel32.dll", "none", "RtlMoveMemory", "ptr", $pPoints_H + ($iLines * 8), "ptr", $pPoints_H, "ulong_ptr", DllStructGetSize($tPoints_H) - ($iLines * 8))
For $i = 1 To $iLines
DllStructSetData($tPoints_H, 1, _CalcNewPoint(DllStructGetData($tPoints_H, 1, ($i - 1) * 2 + 1)), ($i - 1) * 2 + 1)
DllStructSetData($tPoints_H, 1, 0, ($i - 1) * 2 + 2)
Next

[/autoit] [autoit][/autoit] [autoit]

DllCall("kernel32.dll", "none", "RtlMoveMemory", "ptr", $pPoints_V + ($iLines * 8), "ptr", $pPoints_V, "ulong_ptr", DllStructGetSize($tPoints_V) - ($iLines * 8))
For $i = 1 To $iLines
DllStructSetData($tPoints_V, 1, _CalcNewPoint(DllStructGetData($tPoints_V, 1, ($i - 1) * 2 + 1)), ($i - 1) * 2 + 1)
DllStructSetData($tPoints_V, 1, 0, ($i - 1) * 2 + 2)
Next
EndIf

[/autoit] [autoit][/autoit] [autoit]

Local $aResult = DllCall($ghGDIPDll, "uint", "GdipCreatePath", "int", 0, "int*", 0)
Local $hPath_Temp = $aResult[2]
DllCall($ghGDIPDll, "uint", "GdipAddPathLine2", "hwnd", $hPath_Temp, "ptr", $pPoints_V, "int", $iCount)

[/autoit] [autoit][/autoit] [autoit]

Local $fOff = DllStructGetData($tPoints_H, 1, 2)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipGetPathData", "hwnd", $hPath_Temp, "ptr", $pData)

[/autoit] [autoit][/autoit] [autoit]

Local $fX1, $fY1, $fX2, $fY2
For $i = 1 To $iLines
$fX1 = DllStructGetData($tData_P, 1, ($iLines + $i - 1) * 2 + 1)
$fY1 = DllStructGetData($tData_P, 1, ($iLines + $i - 1) * 2 + 2)
$fX2 = DllStructGetData($tData_P, 1, ($i - 1) * 2 + 1)
$fY2 = DllStructGetData($tData_P, 1, ($i - 1) * 2 + 2)
DllStructSetData($tData_P, 1, $fX1 + ($fX2 - $fX1) * $fOff, ($i - 1) * 2 + 1)
DllStructSetData($tData_P, 1, $fY1 + ($fY2 - $fY1) * $fOff, ($i - 1) * 2 + 2)
Next

[/autoit] [autoit][/autoit] [autoit]

$aResult = DllCall($ghGDIPDll, "uint", "GdipCreatePath2", "ptr", $pData_P, "ptr", $pData_T, "int", $iCount, "int", 0, "int*", 0)
Local $hPath_V = $aResult[5]

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipWarpPath", "hwnd", $hPath_V, "hwnd", 0, "ptr", $pWarp_V, "int", 4, "float", -50, "float", 2, "float", 100, "float", $iPlanes, "int", 0, "float", 0)

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipResetPath", "hwnd", $hPath_Temp)
DllCall($ghGDIPDll, "uint", "GdipAddPathLine2", "hwnd", $hPath_Temp, "ptr", $pPoints_H, "int", $iCount)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipGetPathData", "hwnd", $hPath_Temp, "ptr", $pData)

[/autoit] [autoit][/autoit] [autoit]

For $i = 1 To $iLines
$fX1 = DllStructGetData($tData_P, 1, ($iLines + $i - 1) * 2 + 1)
$fY1 = DllStructGetData($tData_P, 1, ($iLines + $i - 1) * 2 + 2)
$fX2 = DllStructGetData($tData_P, 1, ($i - 1) * 2 + 1)
$fY2 = DllStructGetData($tData_P, 1, ($i - 1) * 2 + 2)
DllStructSetData($tData_P, 1, $fX1 + ($fX2 - $fX1) * $fOff, ($i - 1) * 2 + 1)
DllStructSetData($tData_P, 1, $fY1 + ($fY2 - $fY1) * $fOff, ($i - 1) * 2 + 2)
Next

[/autoit] [autoit][/autoit] [autoit]

$aResult = DllCall($ghGDIPDll, "uint", "GdipCreatePath2", "ptr", $pData_P, "ptr", $pData_T, "int", $iCount, "int", 0, "int*", 0)
Local $hPath_H = $aResult[5]

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipWarpPath", "hwnd", $hPath_H, "hwnd", 0, "ptr", $pWarp_H, "int", 4, "float", -50, "float", 2, "float", 100, "float", $iPlanes, "int", 0, "float", 0)

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipGetPathPoints", "hwnd", $hPath_H, "ptr", $pWarped_H, "int", $iCount)
DllCall($ghGDIPDll, "uint", "GdipGetPathPoints", "hwnd", $hPath_V, "ptr", $pWarped_V, "int", $iCount)

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_GraphicsClear($hGfxBuffer, 0xFF040008)
For $i = $iPlanes - 2 To 0 Step -1
_GDIPlus_PenSetWidth($hPen, _CalcPenW(DllStructGetData($tPoints_H, 1, ($i * $iLines) * 2 + 2), $iPlanes, 2))
_GDIPlus_PenSetColor($hPen, BitOR(BitShift(0xFF - ($i * 0xFF / $iPlanes), -24), BitShift(0xFF - ($i * 0xFF / $iPlanes), -16), ($i * 0xFF / $iPlanes)))
For $j = 0 To $iLines - 1
$fX1 = DllStructGetData($tWarped_H, 1, ($i * $iLines + $j) * 2 + 1)
$fY1 = DllStructGetData($tWarped_V, 1, ($i * $iLines + $j) * 2 + 2)
$fX2 = DllStructGetData($tWarped_H, 1, (($i + 1) * $iLines + $j) * 2 + 1)
$fY2 = DllStructGetData($tWarped_V, 1, (($i + 1) * $iLines + $j) * 2 + 2)
DllCall($ghGDIPDll, "int", "GdipDrawLine", "handle", $hGfxBuffer, "handle", $hPen, "float", $fX1, "float", $fY1, "float", $fX2, "float", $fY2)
Next
Next

[/autoit] [autoit][/autoit] [autoit]

DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath_V)
DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath_H)
DllCall($ghGDIPDll, "uint", "GdipDeletePath", "hwnd", $hPath_Temp)

[/autoit] [autoit][/autoit] [autoit]

_WinAPI_BitBlt($hDC, 0, 0, $iWidth, $iHeight, $hCDC, 0, 0, 0x00CC0020)
EndFunc ;==>_Draw

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _CalcPenW($fVal, $iRange, $iMax)
Local $fW = (Log($iRange * 2) - Log($fVal + 1)) * $iMax
Return $fW
EndFunc ;==>_CalcPenW

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func WM_PAINT($hWnd, $uMsgm, $wParam, $lParam)
_WinAPI_BitBlt($hDC, 0, 0, $iWidth, $iHeight, $hCDC, 0, 0, 0x00CC0020)
Return $GUI_RUNDEFMSG
EndFunc ;==>WM_PAINT

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Exit()
_GDIPlus_MatrixDispose($hMatrix_Speed)
_GDIPlus_PenDispose($hPen)
_GDIPlus_GraphicsDispose($hGfxBuffer)
_WinAPI_SelectObject($hCDC, $hOBJ)
_WinAPI_DeleteObject($hBMP)
_WinAPI_DeleteDC($hCDC)
_WinAPI_ReleaseDC($hGui, $hDC)
_GDIPlus_Shutdown()
Exit
EndFunc ;==>_Exit

[/autoit] [autoit][/autoit] [autoit][/autoit]

E

Edit.: sollte nun auch auf älteren AutoIt Versionen laufen...

**eukalyptus**

Ich hätte ein Testscript für NamedPipes.
Ist etwas umfangreicher als ein normales Beispiel.

Beide Scripte kompilieren und dann starten.
Die Scripte können beliebig beendet und wieder gestartet werden, die Verbindung sollte jedesmal wieder aufgebaut werden.

Sender.au3

Spoiler anzeigen

[autoit]

#include <EditConstants.au3>
#include <GUIConstantsEx.au3>
#include <GuiRichEdit.au3>
#include <Memory.au3>
#include <NamedPipes.au3>
#include <WinAPI.au3>
#include <WinAPIError.au3>
#include <WindowsConstants.au3>

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Opt("MustDeclareVars", 1)
Opt("GUIOnEventMode", 1)

[/autoit] [autoit][/autoit] [autoit]

Global $hGui = GUICreate("Sender", 400, 600, @DesktopWidth / 2 + 5)
GUISetOnEvent($GUI_EVENT_CLOSE, "_Exit")
Global $hREdit = _GUICtrlRichEdit_Create($hGui, "", 5, 5, 390, 590, BitOR($ES_MULTILINE, $WS_VSCROLL, $WS_HSCROLL, $ES_READONLY))
GUISetState()

[/autoit] [autoit][/autoit] [autoit]

Global Const $sPIPE_NAME = "\\.\pipe\AutoItPipe"

[/autoit] [autoit][/autoit] [autoit]

Global $hPipe

[/autoit] [autoit][/autoit] [autoit]

Global Const $iBufferSize = 256

[/autoit] [autoit][/autoit] [autoit]

Global $tBuffer = DllStructCreate("byte[" & $iBufferSize & "];")
Global $pBuffer = DllStructGetPtr($tBuffer)
Global $iBuffer = 0

[/autoit] [autoit][/autoit] [autoit]

Global $iWritten = 0
Global $iByte = 0
Global $iStatus

[/autoit] [autoit][/autoit] [autoit]

Global Const $ERROR_INVALID_HANDLE = 0x6
Global Const $ERROR_IO_PENDING = 0x3E5
Global Const $ERROR_PIPE_CONNECTED = 0x217
Global Const $ERROR_NO_DATA = 0xE8

[/autoit] [autoit][/autoit] [autoit]

While 1
Sleep(Random(500, 2000, 1))

[/autoit] [autoit][/autoit] [autoit]

_BufferAddData($iByte, 12)
$iByte += 1

[/autoit] [autoit][/autoit] [autoit]

If $iBuffer > 0 Then
If $iByte > 0xFF Then $iByte = 0

[/autoit] [autoit][/autoit] [autoit]

$iStatus = _WinAPI_WriteFile($hPipe, $pBuffer, $iBuffer, $iWritten, 0)
If $iStatus = 0 Then
_Log("! Write Error " & _WinAPI_GetLastError() & " " & _WinAPI_GetLastErrorMessage())
_NamedPipes_DisconnectNamedPipe($hPipe)
_Log("> Disconnect " & _WinAPI_GetLastError() & " " & _WinAPI_GetLastErrorMessage())
_WinAPI_CloseHandle($hPipe)
_Log("> Close " & _WinAPI_GetLastError() & " " & _WinAPI_GetLastErrorMessage())
$hPipe = _WinAPI_CreateFile($sPIPE_NAME, 2, 6)
If $hPipe = 0 Then
_Log("! Pipe creation failed " & _WinAPI_GetLastError() & " " & _WinAPI_GetLastErrorMessage())
Else
_Log("+ Pipe creation OK " & _WinAPI_GetLastError() & " " & _WinAPI_GetLastErrorMessage())
EndIf
Else
_Log("+ " & $iWritten & " Bytes written")
_BufferRemoveData($iWritten)
EndIf
EndIf
WEnd

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _BufferRemoveData($iLen)
If $iLen > $iBuffer Then $iLen = $iBuffer
Local $iMove = $iBuffer - $iLen
_MemMoveMemory($pBuffer + $iLen, $pBuffer, $iMove)
$iBuffer = $iMove
_Log("> " & $iLen & " Bytes removed, " & $iMove & " Bytes left")
EndFunc ;==>_BufferRemoveData

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _BufferAddData($iByte, $iLen = 14)
Local $iOver = ($iLen + $iBuffer) - $iBufferSize
If $iOver > 0 Then
_Log("- Buffer overflow: " & $iOver)
_BufferRemoveData($iOver)
EndIf
For $i = $iBuffer To $iBuffer + $iLen
DllStructSetData($tBuffer, 1, $iByte, $i + 1)
Next
$iBuffer += $iLen
_Log("> Bufferdata: " & $iBuffer & " " & BinaryMid(DllStructGetData($tBuffer, 1), 1, $iBuffer))
EndFunc ;==>_BufferAddData

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Exit()
MsgBox(0, "", "")
_GUICtrlRichEdit_Destroy($hREdit)
;_WinAPI_CloseHandle($hPipe)
Exit
EndFunc ;==>_Exit

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Log($sLog)
Local Static $iLogPos = 0
Local $aSel

[/autoit] [autoit][/autoit] [autoit]

$sLog = StringRegExpReplace($sLog, "[\r|\n]*", "")

[/autoit] [autoit][/autoit] [autoit]

_GUICtrlRichEdit_AppendText($hREdit, $sLog & @CRLF)
_GUICtrlRichEdit_SetSel($hREdit, $iLogPos, -1, True)
_GUICtrlRichEdit_SetFont($hREdit, 9, "Courier New")

[/autoit] [autoit][/autoit] [autoit]

Switch StringLeft($sLog, 1)
Case "!"
_GUICtrlRichEdit_SetCharColor($hREdit, 0x0000F7)
_GUICtrlRichEdit_SetCharAttributes($hREdit, "+bo")
Case ">"
_GUICtrlRichEdit_SetCharColor($hREdit, 0xFF0000)
_GUICtrlRichEdit_SetCharAttributes($hREdit, "-bo")
Case "-"
_GUICtrlRichEdit_SetCharColor($hREdit, 0x0088FF)
_GUICtrlRichEdit_SetCharAttributes($hREdit, "+bo")
Case "+"
_GUICtrlRichEdit_SetCharColor($hREdit, 0x007F00)
_GUICtrlRichEdit_SetCharAttributes($hREdit, "+bo")
Case Else
_GUICtrlRichEdit_SetCharColor($hREdit, 0)
_GUICtrlRichEdit_SetCharAttributes($hREdit, "-bo")
EndSwitch

[/autoit] [autoit][/autoit] [autoit]

$aSel = _GUICtrlRichEdit_GetSel($hREdit)
$iLogPos = $aSel[1] - 1
EndFunc ;==>_Log

[/autoit]

Empfänger.au3:

Spoiler anzeigen

[autoit]

#include <EditConstants.au3>
#include <GUIConstantsEx.au3>
#include <GuiRichEdit.au3>
#include <NamedPipes.au3>
#include <WinAPI.au3>
#include <WinAPIError.au3>
#include <WindowsConstants.au3>

[/autoit] [autoit][/autoit] [autoit]

Opt("MustDeclareVars", 1)
Opt("GUIOnEventMode", 1)

[/autoit] [autoit][/autoit] [autoit]

Global $hGui = GUICreate("Empänger", 400, 600, @DesktopWidth / 2 - 405)
GUISetOnEvent($GUI_EVENT_CLOSE, "_Exit")
Global $hREdit = _GUICtrlRichEdit_Create($hGui, "", 5, 5, 390, 590, BitOR($ES_MULTILINE, $WS_VSCROLL, $WS_HSCROLL, $ES_READONLY))
GUISetState()

[/autoit] [autoit][/autoit] [autoit]

Global Const $sPIPE_NAME = "\\.\pipe\AutoItPipe"

[/autoit] [autoit][/autoit] [autoit]

Global Const $iPipeBuffer = 512

[/autoit] [autoit][/autoit] [autoit]

Global $hPipe = _NamedPipes_CreateNamedPipe($sPIPE_NAME, 2, 3, 0, 0, 0, 0, 5, $iPipeBuffer, $iPipeBuffer)
_Log("> New Pipe " & $hPipe & " " & _WinAPI_GetLastError() & " " & _WinAPI_GetLastErrorMessage())
Global Const $iBufferSize = 256

[/autoit] [autoit][/autoit] [autoit]

Global $tBuffer = DllStructCreate("byte[" & $iBufferSize & "];")
Global $pBuffer = DllStructGetPtr($tBuffer)
Global $iBuffer = DllStructGetSize($tBuffer)

[/autoit] [autoit][/autoit] [autoit]

Global $iRead = 0
Global $iStatus

[/autoit] [autoit][/autoit] [autoit]

Global Const $ERROR_INVALID_HANDLE = 0x6
Global Const $ERROR_IO_PENDING = 0x3E5
Global Const $ERROR_PIPE_CONNECTED = 0x217
Global Const $ERROR_BROKEN_PIPE = 0x6D

[/autoit] [autoit][/autoit] [autoit]

_NamedPipes_ConnectNamedPipe($hPipe)
_Log("+ Client Connected")

[/autoit] [autoit][/autoit] [autoit]

While 1
$iStatus = _WinAPI_ReadFile($hPipe, $pBuffer, $iBuffer, $iRead, 0)
If $iStatus = 0 Then
If _WinAPI_GetLastError() = $ERROR_BROKEN_PIPE Then
_Log("! Broken Pipe " & _WinAPI_GetLastError() & " " & _WinAPI_GetLastErrorMessage())
_NamedPipes_DisconnectNamedPipe($hPipe)
_Log("> Disconnect " & _WinAPI_GetLastError() & " " & _WinAPI_GetLastErrorMessage())
_WinAPI_CloseHandle($hPipe)
_Log("> Close " & _WinAPI_GetLastError() & " " & _WinAPI_GetLastErrorMessage())
$hPipe = _NamedPipes_CreateNamedPipe($sPIPE_NAME, 2, 2, 0, 0, 0, 0, 1, 32, 32)
If $hPipe = 0 Then
_Log("! Pipe creation failed " & _WinAPI_GetLastError() & " " & _WinAPI_GetLastErrorMessage())
Else
_Log("+ Pipe creation OK " & _WinAPI_GetLastError() & " " & _WinAPI_GetLastErrorMessage())
_NamedPipes_ConnectNamedPipe($hPipe)
_Log("> Connect " & _WinAPI_GetLastError() & " " & _WinAPI_GetLastErrorMessage())
EndIf
EndIf
Else
_Log("+ " & $iRead & " Bytes read: " & BinaryMid(DllStructGetData($tBuffer, 1), 1, $iRead))
EndIf
Sleep(10)
WEnd

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Exit()
MsgBox(0, "", "")
_GUICtrlRichEdit_Destroy($hREdit)
Exit
EndFunc ;==>_Exit

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func _Log($sLog)
Local Static $iLogPos = 0
Local $aSel

[/autoit] [autoit][/autoit] [autoit]

$sLog = StringRegExpReplace($sLog, "[\r|\n]*", "")

[/autoit] [autoit][/autoit] [autoit]

_GUICtrlRichEdit_AppendText($hREdit, $sLog & @CRLF)
_GUICtrlRichEdit_SetSel($hREdit, $iLogPos, -1, True)
_GUICtrlRichEdit_SetFont($hREdit, 9, "Courier New")

[/autoit] [autoit][/autoit] [autoit]

Switch StringLeft($sLog, 1)
Case "!"
_GUICtrlRichEdit_SetCharColor($hREdit, 0x0000F7)
_GUICtrlRichEdit_SetCharAttributes($hREdit, "+bo")
Case ">"
_GUICtrlRichEdit_SetCharColor($hREdit, 0xFF0000)
_GUICtrlRichEdit_SetCharAttributes($hREdit, "-bo")
Case "-"
_GUICtrlRichEdit_SetCharColor($hREdit, 0x0088FF)
_GUICtrlRichEdit_SetCharAttributes($hREdit, "+bo")
Case "+"
_GUICtrlRichEdit_SetCharColor($hREdit, 0x007F00)
_GUICtrlRichEdit_SetCharAttributes($hREdit, "+bo")
Case Else
_GUICtrlRichEdit_SetCharColor($hREdit, 0)
_GUICtrlRichEdit_SetCharAttributes($hREdit, "-bo")
EndSwitch

[/autoit] [autoit][/autoit] [autoit]

$aSel = _GUICtrlRichEdit_GetSel($hREdit)
$iLogPos = $aSel[1] - 1
EndFunc ;==>_Log

[/autoit] [autoit][/autoit] [autoit][/autoit]

**eukalyptus**

zum Messen kannst du die Funktion _BASS_EXT_Level2dB verwenden.
Kennst du dich mit dB aus?

Kommt drauf an, was du messen willst. Bei der Lautstärke sind 6dB das doppelte. Bei Leistung 3dB das doppelte.
Den Unterschied zwischen Out und In beim Kalibrieren in dB messen und bei den Messergebnissen mit einrechnen.

z.B.: Kalibrieren: Out = -10 dB / In = -5 dB / Unterschied = 5dB
Messen: Out = -10 dB / In = -20 dB / Dämpfung = 15dB

Falls du wirklich den In und Out auf die gleiche Lautstärke bringen willst, dann kannst du das mit _BASS_RecordSetInput machen.

E

Beiträge von eukalyptus

Midi Udf

GDI+ 3D Object Viewer (Wavefront .obj Format)

GDIPlus gebürstetes Aluminium ;)

Parameter an laufenden Prozess übergeben

Midi Udf

Fokus von Child-GUI an Parent binden

Zwei Fragen: 1.) Kollision Ellipse(Kugel) mit Rechteck, 2.) FPS

Juhu!

MP3 schneiden

Gebogenes Objekt auf gerade Linie abrollen ( Oder "Mathe für Runaways" )

Gebogenes Objekt auf gerade Linie abrollen ( Oder "Mathe für Runaways" )

Gebogenes Objekt auf gerade Linie abrollen ( Oder "Mathe für Runaways" )

Gebogenes Objekt auf gerade Linie abrollen ( Oder "Mathe für Runaways" )

StringReplace zu viel für Autoit?

Taste loslassen abfragen

GDI+ Spielerei 3D-Linien

GDI+ Spielerei 3D-Linien

GDI+ Spielerei 3D-Linien

Deutsche Hilfe - Funktionen ohne Beispiel

Bass.dll UDF Version_10 Download
