Beiträge von UEZ

**UEZ**

Wie gesagt, ist die Version nur ein "Proof-of-Concept" Version und ich würde dem Status höchstens ein "Alpha" geben, da vieles nicht richtig funktioniert bzw. nicht implementiert ist.

Ich weiß nicht, wie aufwändig es ist, aus dem Windows Screenshooter den Image Editor zu extrahieren.

Ich habe auch keine Ambitionen diesen Image Editor weiterzuentwickeln - sorry.

**UEZ**

Zitat von gmmg

Außerdem wäre die Frage, wie ich es hinbekomme, dass er beim start keinen Screenshot macht, sondern ich eine BMP Datei übergeben kann.

In Zeile 26 wird ein Bildschirm Foto erstellt und benutzt. Einfach den Bereich durch folgenden Code ersetzen:

AutoIt

Opt("MustDeclareVars", 1)

Global $sFile = FileOpenDialog("Select an image", "", "Images (*.jpg;*.bmp;*.png;*.gif)")
If @error Then Exit MsgBox(16, "Error", "No image has been selected")
Global Const $dll = DllOpen("user32.dll")
_GDIPlus_Startup()
Global $ghGDIPDll = $__g_hGDIPDll
Global $aDPI = _GDIPlus_GraphicsGetDPIRatio()
;~ Global $hBMP_Screen = _ScreenCapture_Capture("", 0, 0, 1920, 1080)
;~ Global $hBmp = _GDIPlus_BitmapCreateFromHBITMAP($hBMP_Screen)
;~ _WinAPI_DeleteObject($hBMP_Screen)
Global $hBmp = _GDIPlus_ImageLoadFromFile($sFile)
Global $bW = _GDIPlus_ImageGetWidth($hBmp)
Global $bH = _GDIPlus_ImageGetHeight($hBmp)

Alles anzeigen

Zitat von gmmg

AutoIt Windows Screenshooter v1.84 Build 2019-08-18\AutoIt Windows Screenshooter\_Source\Windows Screenshooter.au3"(122,107) : error: $GDIP_WrapModeTileFlipXY previously declared as a 'Const'.
Global Enum $GDIP_WrapModeTile, $GDIP_WrapModeTileFlipX, $GDIP_WrapModeTileFlipY, $GDIP_WrapModeTileFlipXY,

Einfach die Zeile auskommentieren, da die Variablen bereits deklariert sind. Zu der damaligen Zeit war dies nicht der Fall.

Die Funktion

AutoIt

Func Save_Bitmap()
    Return 1
EndFunc

kannst du versuchen mit "Leben" zu füllen, um das Resultat in eine Bilddatei zu speichern.

**UEZ**

Der Editor war nie als eigenständiges Tool gedacht, sondern nur als "Proof-of-Concept" Version. Die stabilere Version ist im Windows Screenshooter Tool integriert.

Diese ältere Version scheint einigermaßen zu funktionieren: Basic Image Editor.au3

**UEZ**

funkey : Prima, werde es testen und mich melden, falls ich was finde...

**UEZ**

Zitat von funkey

Hallo,

hab das mal in meine HookDlgBox-UDF eingebaut.

HookDlgBox.au3

AutoIt

#include-once
#include <WinAPI.au3>
#include <Timers.au3>

Global Const $tagCBT_CREATEWND = "ptr lpcs;HWND tagCBT_CREATEWND"
Global Const $tagCREATESTRUCT = "ptr lpCreateParams;handle hInstance;HWND hMenu;HWND hwndParent;int cy;int cx;int y;int x;LONG style;ptr lpszName;ptr lpszClass;DWORD dwExStyle"

Global $g__hProcDlgBox = DllCallbackRegister("__DlgBox_CbtHookProc", "LRESULT", "int;WPARAM;LPARAM")
Global $g__TIdDlgBox = _WinAPI_GetCurrentThreadId()
Global $g__hHookDlgBox = _WinAPI_SetWindowsHookEx($WH_CBT, DllCallbackGetPtr($g__hProcDlgBox), 0, $g__TIdDlgBox)

Global Const $g__MaxDlgBtns = 5 ; maximum of 5 buttons to rename text
Global Const $g__MaxDlgItemId = 11 ; maximun ID of buttons to search is 11 as this is the maximun used in Messagebox

Global $g__DlgBoxPosX, $g__DlgBoxPosY, $g__DlgBoxWidth, $g__DlgBoxHeight
Global $g__aDlgBoxBtnText[$g__MaxDlgBtns]

Global $g__DlgBtnCount = 0
Global $g_DlgBoxTimeout = 0
Global $g_DlgBoxTimeCtrlNum, $g_DlgBoxTimeCtrlId
Global $g_DlgBoxTimerId

_DlgBox_SetDefaults()

OnAutoItExitRegister("__DlgBox_UnregisterHook")


Func _DlgBox_SetButtonNames($TxtBtn1 = Default, $TxtBtn2 = Default, $TxtBtn3 = Default, $TxtBtn4 = Default, $TxtBtn5 = Default)
    $g__aDlgBoxBtnText[0] = $TxtBtn1
    $g__aDlgBoxBtnText[1] = $TxtBtn2
    $g__aDlgBoxBtnText[2] = $TxtBtn3
    $g__aDlgBoxBtnText[3] = $TxtBtn4
    $g__aDlgBoxBtnText[4] = $TxtBtn5

    $g__DlgBtnCount = @NumParams
EndFunc   ;==>_DlgBox_SetButtonNames

Func _DlgBox_SetPosition($x = Default, $y = Default) ;only for MsgBox, not working and not needed for InputBox
    $g__DlgBoxPosX = $x
    $g__DlgBoxPosY = $y
EndFunc   ;==>_DlgBox_SetPosition

Func _DlgBox_SetSize($w = Default, $h = Default)
    $g__DlgBoxWidth = $w
    $g__DlgBoxHeight = $h
EndFunc   ;==>_DlgBox_SetSize

Func _DlgBox_SetDefaults()
    $g__DlgBoxPosX = Default
    $g__DlgBoxPosY = Default
    $g__DlgBoxWidth = Default
    $g__DlgBoxHeight = Default
    For $i = 0 To UBound($g__aDlgBoxBtnText) - 1
        $g__aDlgBoxBtnText[$i] = Default
    Next
    $g_DlgBoxTimeout = 0
EndFunc   ;==>_DlgBox_SetDefaults

Func _DlgBox_SetTimeOut($iTimeout = 0, $CtrlId = 1)
    $g_DlgBoxTimeout = $iTimeout
    $g_DlgBoxTimeCtrlNum = $CtrlId
EndFunc

Func __DlgBox_CbtHookProc($nCode, $wParam, $lParam)
    Local $tcw, $tcs
    Local $iSearch = 0
    Local $ahBtn[$g__DlgBtnCount]
    If $nCode < 0 Then
        Return _WinAPI_CallNextHookEx($g__hHookDlgBox, $nCode, $wParam, $lParam)
    EndIf

    Switch $nCode
        Case 3 ;5=HCBT_CREATEWND
            If _WinAPI_GetClassName(HWnd($wParam)) = "#32770" Then ;Dialog window class
                $tcw = DllStructCreate($tagCBT_CREATEWND, $lParam)
                $tcs = DllStructCreate($tagCREATESTRUCT, DllStructGetData($tcw, "lpcs"))

                If $g__DlgBoxPosX <> Default Then DllStructSetData($tcs, "x", $g__DlgBoxPosX)
                If $g__DlgBoxPosY <> Default Then DllStructSetData($tcs, "y", $g__DlgBoxPosY)
                If $g__DlgBoxWidth <> Default Then DllStructSetData($tcs, "cx", $g__DlgBoxWidth)
                If $g__DlgBoxHeight <> Default Then DllStructSetData($tcs, "cy", $g__DlgBoxHeight)

                If $g_DlgBoxTimeout <> 0 Then
                    $g_DlgBoxTimerId = _Timer_SetTimer(HWnd($wParam), 1000, "_UpdateTime")
                EndIf
            EndIf
        Case 5 ;5=HCBT_ACTIVATE
            If _WinAPI_GetClassName(HWnd($wParam)) = "#32770" Then ;Dialog window class
                For $i = 1 To $g__MaxDlgItemId
                    If IsHWnd(_WinAPI_GetDlgItem($wParam, $i)) Then
                        If $g_DlgBoxTimeout > 0 Then
                            If $iSearch == $g_DlgBoxTimeCtrlNum - 1 Then
                                $g_DlgBoxTimeCtrlId = $i
                                If $g__aDlgBoxBtnText[$iSearch] <> Default Then _WinAPI_SetDlgItemText($wParam, $i, $g__aDlgBoxBtnText[$iSearch] & " [" & $g_DlgBoxTimeout & "]")
                            Else
                                If $g__aDlgBoxBtnText[$iSearch] <> Default Then _WinAPI_SetDlgItemText($wParam, $i, $g__aDlgBoxBtnText[$iSearch])
                            EndIf
                        Else
                            If $g__aDlgBoxBtnText[$iSearch] <> Default Then _WinAPI_SetDlgItemText($wParam, $i, $g__aDlgBoxBtnText[$iSearch])
                        EndIf

                        $iSearch += 1
                        If $iSearch >= UBound($ahBtn) Then ExitLoop
                    EndIf
                Next
            EndIf
        Case 4 ;4=HCBT_DESTROYWND
            If _WinAPI_GetClassName(HWnd($wParam)) = "#32770" Then ;Dialog window class
                _Timer_KillTimer(HWnd($wParam), $g_DlgBoxTimerId)
                $g_DlgBoxTimeout = 0
            EndIf
    EndSwitch
    Return _WinAPI_CallNextHookEx($g__hHookDlgBox, $nCode, $wParam, $lParam)
EndFunc   ;==>__DlgBox_CbtHookProc

Func _UpdateTime($hWnd, $iMsg, $iIDTimer, $iTime)
    #forceref $hWnd, $iMsg, $iIDTimer, $iTime
;~     ConsoleWrite($hWnd&" - "&$iMsg&" - "&$iIDTimer&" - "&$iTime & @CRLF)

    $g_DlgBoxTimeout -= 1
    _WinAPI_SetDlgItemText($hWnd, $g_DlgBoxTimeCtrlId, $g__aDlgBoxBtnText[$g_DlgBoxTimeCtrlNum - 1] & " [" & $g_DlgBoxTimeout & "]")
    If $g_DlgBoxTimeout <= 0 Then
        WinClose($hWnd)
    EndIf
EndFunc   ;==>_UpdateTime


Func __DlgBox_UnregisterHook()
    _WinAPI_UnhookWindowsHookEx($g__hHookDlgBox)
    DllCallbackFree($g__hProcDlgBox)
EndFunc   ;==>__DlgBox_UnregisterHook

Func _WinAPI_SetDlgItemText($hDlg, $nIDDlgItem, $lpString)
    Local $aRet = DllCall('user32.dll', "int", "SetDlgItemText", _
            "hwnd", $hDlg, _
            "int", $nIDDlgItem, _
            "str", $lpString)
    Return $aRet[0]
EndFunc   ;==>_WinAPI_SetDlgItemText

Alles anzeigen

HookDlgBox Timeout Beispiel

AutoIt

#include "HookDlgBox.au3"

Global $Timeout = 5

_DlgBox_SetTimeOut($Timeout, 1)
_DlgBox_SetButtonNames("one", "two", "three")

Global $iRet1 = MsgBox(3, "Test 1", "Custom button texts", $Timeout)
ConsoleWrite($iRet1 & @CRLF)


Global $iRet2 = MsgBox(3, "Test 2", "Custom button texts", $Timeout)
ConsoleWrite($iRet2 & @CRLF)

_DlgBox_SetTimeOut($Timeout, 2)

Global $iRet3 = MsgBox(3, "Test 3", "Custom button texts")
ConsoleWrite($iRet3 & @CRLF)

_DlgBox_SetTimeOut($Timeout, 3)

Global $iRet4 = MsgBox(3, "Test 4", "Custom button texts")
ConsoleWrite($iRet4 & @CRLF)

Alles anzeigen

Dieses Beispiel funktioniert nicht:

AutoIt

#include <MsgBoxConstants.au3>
#include "HookDlgBox.au3"

Global $Timeout = 5

_DlgBox_SetTimeOut($Timeout, 1)
_DlgBox_SetButtonNames("Exit")
MsgBox(BitOR($MB_TOPMOST, $MB_ICONINFORMATION), "Information", "View has been refreshed!", $Timeout)

Anscheinend geht es nur mit $MB_YESNOCANCEL.

**UEZ**

Velted : stimmt, danke für den Hinweis.

**UEZ**

funkey

**UEZ**

Oscar danke für deine Alternative!

Das hier funktioniert jetzt:

AutoIt

;Coded by UEZ build 2023-04-27 beta

#include <Timers.au3>
#include <WinAPIConstants.au3>
#include <WinAPIGdi.au3>
#include <WinAPIProc.au3>
#include <WinAPISys.au3>
#include <WindowsConstants.au3>

Global $HCBT_ACTIVATE = 5, $g_hMsgBoxHook, $g_hMod, $g_hThreadID, $g_hSubMsgBox, $g_SubMsgBox, $g_lPrevWnd, $g_HWND, $g_idTImer, $g_
Global $g_Time = 5

Func _WinAPI_SetDlgItemText($hDlg, $nIDDlgItem, $lpString) ;https://learn.microsoft.com/en-us/windows/win32/api/winuser/nf-winuser-setdlgitemtextw
    Local $aRet = DllCall("user32.dll", "int", "SetDlgItemText", "hwnd", $hDlg, "int", $nIDDlgItem, "str", $lpString)
    If @error Then Return SetError(@error, @extended, 0)
    Return $aRet[0]
EndFunc   ;==>_WinAPI_SetDlgItemText

Func _SubMsgBoxProc($hwnd, $iMsg, $wParam, $lParam)
    Switch $iMsg
        Case $WM_SHOWWINDOW
        Case $WM_CTLCOLORDLG, $WM_CTLCOLORSTATIC
;~             Local $tLOGBRUSH = DllStructCreate("uint lbStyle;long lbColor;ulong_ptr lbHatch")
;~             _WinAPI_SetBkColor($wParam, 0xFEDCBA)
;~             $tLOGBRUSH.lbColor = 0xFEDCBA
;~             DllCall("gdi32.dll", "handle", "CreateBrushIndirect", "struct*", $tLOGBRUSH)
;~             Return 0
        Case $WM_TIMER
            Local $sText = "Exit [" & $g_Time & "]"
            $g_Time -= 1
;~             ControlSetText($g_HWND, "", "[CLASS:Button; INSTANCE:1]", $sText)
            _WinAPI_SetDlgItemText($hWnd, $IDOK + 1, $sText)
            ConsoleWrite($g_Time & @CRLF)

            If $g_Time < 0 Then
                _Timer_KillTimer($g_HWND, $g_idTImer)
                _WinAPI_SetWindowLong($hwnd, $GWL_WNDPROC, $g_lPrevWnd)
                GUIDelete($hwnd)
            EndIf
            Return 0
        Case $WM_DESTROY
            _Timer_KillTimer($g_HWND, $g_idTImer)
            _WinAPI_SetWindowLong($hwnd, $GWL_WNDPROC, $g_lPrevWnd)
    EndSwitch
    Return _WinAPI_CallWindowProc($g_lPrevWnd, $hWnd, $iMsg, $wParam, $lParam)
EndFunc   ;==>_SubMsgBoxProc

Func _CBTHookProc($nCode, $wParam, $lParam)
    If $nCode < 0 Then Return _WinAPI_CallNextHookEx($g_hMsgBoxHook, $nCode, $wParam, $lParam)
    Switch $nCode
        Case $HCBT_ACTIVATE
            $g_HWND = HWnd($wParam)
            If _WinAPI_GetClassName($g_HWND) = "#32770" Then
                $g_idTImer = _Timer_SetTimer($g_HWND, 1000)
                _WinAPI_SetDlgItemText($wParam, $IDOK, "Exit [" & $g_Time & "]")
                $g_lPrevWnd = _WinAPI_SetWindowLong($g_HWND, $GWL_WNDPROC, DllCallbackGetPtr($g_SubMsgBox))
            EndIf
    EndSwitch
    Return _WinAPI_CallNextHookEx($g_hMsgBoxHook, $nCode, $wParam, $lParam)
EndFunc   ;==>_CBTHookProc


$g_SubMsgBox = DllCallbackRegister("_SubMsgBoxProc", "long", "hwnd;uint;wparam;lparam")
$g_MsgProc = DllCallbackRegister("_CBTHookProc", "int", "uint;wparam;lparam")
$g_hMod = _WinAPI_GetModuleHandle(0)
$g_hThreadID = _WinAPI_GetCurrentThreadId()
$g_hMsgBoxHook = _WinAPI_SetWindowsHookEx($WH_CBT, DllCallbackGetPtr($g_MsgProc), Null, $g_hThreadID)
MsgBox(0, "Test", "This is a test message box with a counter!", $g_Time + 2)
_WinAPI_UnhookWindowsHookEx($g_hMsgBoxHook)
_WinAPI_UnhookWindowsHookEx($g_lPrevWnd)
DllCallbackFree($g_SubMsgBox)
DllCallbackFree($g_MsgProc)

Alles anzeigen

Kürzere Version angelehnt an funkey's Methode:

AutoIt

;Coded by UEZ build 2023-04-29 beta

#include <Timers.au3>
#include <WinAPIConstants.au3>
#include <WinAPIGdi.au3>
#include <WinAPIProc.au3>
#include <WinAPISys.au3>
#include <WindowsConstants.au3>

Const $HCBT_CREATEWND = 3, $HCBT_DESTROYWND = 4, $HCBT_ACTIVATE = 5, $g_iFlagDefault = BitOR($MB_TOPMOST, $MB_ICONINFORMATION)
Global $g_hMsgBoxHook, $g_hSubMsgBox, $g_idTImer, $g_sBtn1_Txt = "Close", $g_sBtn2_Txt, $g_sBtn3_Txt
Global $g_Timeout = 0

Func _WinAPI_SetDlgItemText($hDlg, $nIDDlgItem, $lpString) ;https://learn.microsoft.com/en-us/windows/win32/api/winuser/nf-winuser-setdlgitemtextw
    Local $aRet = DllCall("user32.dll", "int", "SetDlgItemText", "hwnd", $hDlg, "int", $nIDDlgItem, "str", $lpString)
    If @error Then Return SetError(@error, @extended, 0)
    Return $aRet[0]
EndFunc   ;==>_WinAPI_SetDlgItemText

Func _TimerProc($hwnd, $iMsg, $wParam, $lParam)
    If $g_Timeout <= 1 Then
        WinClose($hwnd)
    Else
        $g_Timeout -= 1
        _WinAPI_SetDlgItemText($hWnd, $IDOK + 1, $g_sBtn1_Txt & " [" & $g_Timeout & "]")
    EndIf
EndFunc   ;==>_TimerProc

Func _CBTHookProc($nCode, $wParam, $lParam)
    If $nCode < 0 Then Return _WinAPI_CallNextHookEx($g_hMsgBoxHook, $nCode, $wParam, $lParam)
    Local Const $hHWND = HWnd($wParam)
    Switch $nCode
        Case $HCBT_ACTIVATE
            If _WinAPI_GetClassName($hHWND) = "#32770" Then
                If $g_Timeout Then $g_idTImer = _Timer_SetTimer($hHWND, 1000, "_TimerProc")
                _WinAPI_SetDlgItemText($wParam, $IDOK, $g_Timeout ? $g_sBtn1_Txt & " [" & $g_Timeout & "]" : $g_sBtn1_Txt)
            EndIf
        Case $HCBT_DESTROYWND
            If _WinAPI_GetClassName($hHWND) = "#32770" Then _Timer_KillTimer($hHWND, $g_idTImer)
    EndSwitch
    Return _WinAPI_CallNextHookEx($g_hMsgBoxHook, $nCode, $wParam, $lParam)
EndFunc   ;==>_CBTHookProc

Func MsgBoxEx($sText, $sTitle = Default, $iTimeout = 0, $iFlag = Default, $sBtn_Txt = Default, $hParentHWND = "")
    If $sBtn_Txt <> Default Then $g_sBtn1_Txt = $sBtn_Txt
    If $iFlag = Default Then $iFlag = $g_iFlagDefault
    $g_Timeout = $iTimeout
    $g_MsgProc = DllCallbackRegister("_CBTHookProc", "int", "uint;wparam;lparam")
    Local Const $hThreadID = _WinAPI_GetCurrentThreadId()
    $g_hMsgBoxHook = _WinAPI_SetWindowsHookEx($WH_CBT, DllCallbackGetPtr($g_MsgProc), Null, $hThreadID)
    If $sTitle = Default Then $sTitle = "Information"
    Local Const $iReturn = MsgBox($iFlag, $sTitle, $sText, $iTimeout, $hParentHWND)
    _WinAPI_UnhookWindowsHookEx($g_hMsgBoxHook)
    DllCallbackFree($g_MsgProc)
    Return $iReturn
EndFunc   ;==>MsgBoxEx

ConsoleWrite(MsgBoxEx("This is a test", "Information", 5) & @CRLF)

Alles anzeigen

**UEZ**

Ich möchte gerne einen Countdown in das Ok Button hinzufügen, das die vorgebene Zeit herunter zählt. Man könnte dies natürlich mit einer eigen gebastelten GUI realisieren, aber will ich nicht.

Das habe ich soweit zusammen gebastelt, funktioniert leider nicht und meine Augen fallen gerade zu:

AutoIt

#include <WindowsConstants.au3>
#include <WinAPIConstants.au3>
#include <WinAPISys.au3>
#include <WinAPIProc.au3>
#include <Timers.au3>

Global $tagCWPSTRUCT = "long lParam;long wParam;uint message;hwnd hwnd"
Global $HCBT_ACTIVATE = 5, $g_hMsgBoxHook, $g_hMod, $g_hThreadID, $g_hSubMsgBox, $g_SubMsgBox, $g_lPrevWnd, $g_BtnID, $g_HWND, $g_idTImer
Global $g_Time = 5

Func _WinAPI_SetDlgItemText($hDlg, $nIDDlgItem, $lpString) ;https://learn.microsoft.com/en-us/windows/win32/api/winuser/nf-winuser-setdlgitemtextw
    Local $aRet = DllCall("user32.dll", "int", "SetDlgItemText", "hwnd", $hDlg, "int", $nIDDlgItem, "str", $lpString)
    If @error Then Return SetError(@error, @extended, 0)
    Return $aRet[0]
EndFunc   ;==>_WinAPI_SetDlgItemText

Func _SubMsgBoxProc($hwnd, $iMsg, $wParam, $lParam)
    Switch $iMsg
        Case $WM_SHOWWINDOW
        Case $WM_TIMER
            _WinAPI_SetDlgItemText($g_BtnID, $IDOK, "OK [" & $g_Time & "]")
            $g_Time -= 1
            If $g_Time < 0 Then
                _Timer_KillTimer($g_idTImer, $g_HWND)
                _WinAPI_SetWindowLong($hwnd, $GWL_WNDPROC, $g_lPrevWnd)
            EndIf
            Return 0
        Case $WM_DESTROY
            _Timer_KillTimer($g_idTImer, $g_HWND)
            ;_WinAPI_SetWindowLong($hwnd, $GWL_WNDPROC, $g_lPrevWnd)
    EndSwitch
    Return _WinAPI_CallWindowProc($g_lPrevWnd, $hWnd, $iMsg, $wParam, $lParam)
EndFunc

Func _CBTHookProc($nCode, $wParam, $lParam)
    If $nCode < 0 Then Return _WinAPI_CallNextHookEx($g_hMsgBoxHook, $nCode, $wParam, $lParam)
    Local $tCWP = DllStructCreate($tagCWPSTRUCT, $lParam)
    Switch $nCode
        Case $HCBT_ACTIVATE
            $g_HWND = HWnd($wParam)
            If _WinAPI_GetClassName($g_HWND) = "#32770" Then
                $g_idTImer = _Timer_SetTimer($g_HWND, 1000)
                $g_BtnID = HWnd($wParam) ;_WinAPI_GetDlgItem($wParam, 1)
                _WinAPI_SetDlgItemText($g_BtnID, $IDOK, "OK [" & $g_Time & "]")
                $g_lPrevWnd = _WinAPI_SetWindowLong($g_HWND, $GWL_WNDPROC, DllCallbackGetPtr($g_SubMsgBox))
            EndIf
    EndSwitch
    Return _WinAPI_CallNextHookEx($g_hMsgBoxHook, $nCode, $wParam, $lParam)
EndFunc


$g_SubMsgBox = DllCallbackRegister("_SubMsgBoxProc", "long", "hwnd;uint;wparam;lparam")
$g_MsgProc = DllCallbackRegister("_CBTHookProc", "int", "uint;wparam;lparam")
$g_hMod = _WinAPI_GetModuleHandle(0)
$g_hThreadID = _WinAPI_GetCurrentThreadId()
$g_hMsgBoxHook = _WinAPI_SetWindowsHookEx($WH_CBT, DllCallbackGetPtr($g_MsgProc), Null, $g_hThreadID)
MsgBox(0, "Test", "This is a test message box!")
_WinAPI_UnhookWindowsHookEx($g_hMsgBoxHook)
_WinAPI_UnhookWindowsHookEx($g_lPrevWnd)
DllCallbackFree($g_SubMsgBox)
DllCallbackFree($g_MsgProc)

Alles anzeigen

Könnt ihr den Fehler sehen?

**UEZ**

Vielen Dank fee

Ich werde mir das mal anschauen, ob ich eine Sortierung sehen kann. Momentan ist das Thema bei mir ein wenig eingeschlafen.

Falls interesse besteht, habe ich die Farbraumumwandelfunktionen nach Freebasic portiert: Color space / difference / distance converter

Die aktuelle Version: ColorSorterGrouper.au3


**UEZ**

Andy danke.

Anscheinend darf man kein https// vor die Adresse einfügen, da ansonsten die Forum Software nochmals ein https:// davor setzt. Der Link sollte jetzt funzen.

SOLVE-SMART Danke für den Hinweis.

**UEZ**

Ich hatte auch mal was in die Richtung gebastelt: _WinAPI_MarkScreenRegionAndCapture 0.92 build 2017-01-22

Vielleicht nützlich für dein Anliegen...

**UEZ**

eukalyptus das Resultat sieht echt gut aus!

Ich habe mal an CIEDE2000 versucht, läuft aber irgendwie nicht wirklich.

AutoIt

#include <Array.au3>

Const $pow25To7 = 6103515625.0, $16d116 = 16 / 116, $1d3 = 1 / 3
Const $PI = ACos(-1)
Const $deg360InRad = deg2Rad(360.0), $deg180InRad = deg2Rad(180.0)

Func Min($a, $b)
    Return ($a < $b) ? $a : $b
EndFunc

Func Max($a, $b)
    Return ($a > $b) ? $a : $b
EndFunc

Func ATan2($y, $x)
    Local $result = Atan($y / $x)
    If $x < 0 Then
        $result += $PI
    ElseIf $y < 0 Then
        $result += 2 * $PI
    EndIf
    Return $result
EndFunc

Func deg2Rad(Const $deg)
    Return ($deg * ($PI / 180.0))
EndFunc

Func rad2Deg(Const $rad)
    Return ((180.0 / $PI) * $rad)
EndFunc

Func Pow($a, $b)
    Return $a ^ $b
EndFunc

Func _ColorRGB($R, $G, $B)
    Return BitOR(0xFF000000, BitShift($R, -16), BitShift($G, -8), $b)
EndFunc

;--------------------------------------------------------------------------------------------
Func CIEDE2000($Lab1, $Lab2) ;http://en.wikipedia.org/wiki/Color_difference#CIEDE2000)
    Local $lab1l = $Lab1[0], $lab1a = $Lab1[1], $lab1b = $Lab1[2], _
          $lab2l = $Lab2[0], $lab2a = $Lab2[1], $lab2b = $Lab1[2], _
          $k_L = 1.0, $k_C = 1.0, $k_H = 1.0

    ;step1
    ;Equation 2
    Local $C1 = Sqrt(($lab1a * $lab1a) + ($lab1b * $lab1b))
    Local $C2 = Sqrt(($lab2a * $lab2a) + ($lab2b * $lab2b))
    ;Equation 3
    Local $barC = ($C1 + $C2) / 2.0
    ;Equation 4
    Local $G = 0.5 * (1 - Sqrt(Pow($barC, 7) / (Pow($barC, 7) + $pow25To7)))
    ;Equation 5
    Local $a1Prime = (1.0 + $G) * $lab1a
    Local $a2Prime = (1.0 + $G) * $lab2a
    ;Equation 6
    Local $CPrime1 = Sqrt(($a1Prime * $a1Prime) + ($lab1b * $lab1b))
    Local $CPrime2 = Sqrt(($a2Prime * $a2Prime) + ($lab2b * $lab2b))
    ;Equation 7
    Local $hPrime1
    If $lab1b = 0 And $a1Prime = 0 Then
        $hPrime1 = 0
    Else
        $hPrime1 = Atan2($lab1b, $a1Prime)
        ;This must be converted to a hue angle in degrees between 0
        ;and 360 by addition of 2pi to negative hue angles.
        If $hPrime1 < 0 Then $hPrime1 += $deg360InRad
    EndIf
    Local $hPrime2
    If $lab2b = 0 And $lab2b = 0 Then
        $hPrime2 = 0
    Else
        $hPrime2 = Atan2($lab2b, $a2Prime)
        ;This must be converted to a hue angle in degrees between 0
        ;and 360 by addition of 2pi to negative hue angles.
        If ($hPrime2 < 0) Then $hPrime2 += $deg360InRad
    EndIf

    ;step2
    ;Equation 8
    Local $deltaLPrime = $lab2l - $lab1l
    ;Equation 9
    Local $deltaCPrime = $CPrime2 - $CPrime1
    ;Equation 10
    Local $deltahPrime
    Local $CPrimeProduct = $CPrime1 * $CPrime2
    If $CPrimeProduct = 0 Then
        $deltahPrime = 0
    Else
        ;Avoid the fabs() call
        $deltahPrime = $hPrime2 - $hPrime1
        If ($deltahPrime < -$deg180InRad) Then
            $deltahPrime += $deg360InRad
        ElseIf $deltahPrime > $deg180InRad Then
            $deltahPrime -= $deg360InRad
        EndIf
    EndIf
    ;Equation 11
    Local $deltaHPrime2 = 2.0 * Sqrt($CPrimeProduct) * Sin($deltahPrime / 2.0)

    ;step3
    ;Equation 12
    Local $barLPrime = ($lab1l + $lab2l) / 2.0
    ;Equation 13
    Local $barCPrime = ($CPrime1 + $CPrime2) / 2.0
    ;Equation 14
    Local $barhPrime, $hPrimeSum = $hPrime1 + $hPrime2
    If ($CPrime1 * $CPrime2 = 0) Then
        $barhPrime = $hPrimeSum
    Else
        If (Abs($hPrime1 - $hPrime2) <= $deg180InRad) Then
            $barhPrime = $hPrimeSum / 2.0
        Else
            If ($hPrimeSum < $deg360InRad) Then
                $barhPrime = ($hPrimeSum + $deg360InRad) / 2.0
            Else
                $barhPrime = ($hPrimeSum - $deg360InRad) / 2.0
            EndIf
        EndIf
    EndIf
    ;Equation 15
    Local $T = 1.0 - (0.17 * Cos($barhPrime - deg2Rad(30.0))) + _
              (0.24 * Cos(2.0 * $barhPrime)) + _
              (0.32 * Cos((3.0 * $barhPrime) + deg2Rad(6.0))) -  _
              (0.20 * Cos((4.0 * $barhPrime) - deg2Rad(63.0)))
    ;Equation 16
    Local $deltaTheta = deg2Rad(30.0) * Exp(-Pow(($barhPrime - deg2Rad(275.0)) / deg2Rad(25.0), 2.0))
    ;Equation 17
    Local $R_C = 2.0 * Sqrt(Pow($barCPrime, 7.0) / (Pow($barCPrime, 7.0) + $pow25To7))
    ;Equation 18
    Local $S_L = 1 + ((0.015 * Pow($barLPrime - 50.0, 2.0)) / Sqrt(20 + Pow($barLPrime - 50.0, 2.0)))
    ;Equation 19
    Local $S_C = 1 + (0.045 * $barCPrime)
    ;Equation 20
    Local $S_H = 1 + (0.015 * $barCPrime * $T)
    ;Equation 21
    Local $R_T = (-Sin(2.0 * $deltaTheta)) * $R_C
    ;Equation 22
    Local $deltaE = Sqrt( _
                            Pow($deltaLPrime / ($k_L * $S_L), 2.0) + _
                            Pow($deltaCPrime / ($k_C * $S_C), 2.0) + _
                            Pow($deltaHPrime2 / ($k_H * $S_H), 2.0) + _
                            ($R_T * ($deltaCPrime / ($k_C * $S_C)) * ($deltaHPrime2 / ($k_H * $S_H))))
    Return $deltaE
EndFunc

Func _RGB2LAB($iRGB) ;by eukalyptus
    Local $aRGB[3], $i
    $aRGB[0] = BitAND(BitShift($iRGB, 16), 0xFF) / 255
    $aRGB[1] = BitAND(BitShift($iRGB, 8), 0xFF) / 255
    $aRGB[2] = BitAND($iRGB, 0xFF) / 255

    For $i = 0 To 2
        If $aRGB[$i] > 0.04045 Then
            $aRGB[$i] = (($aRGB[$i] + 0.055) / 1.055) ^ 2.4
        Else
            $aRGB[$i] = $aRGB[$i] / 12.92
        EndIf
        $aRGB[$i] *= 100
    Next

    Local $aXYZ[3]
    $aXYZ[0] = ($aRGB[0] * 0.4124 + $aRGB[1] * 0.3576 + $aRGB[2] * 0.1805) / 95.047
    $aXYZ[1] = ($aRGB[0] * 0.2126 + $aRGB[1] * 0.7152 + $aRGB[2] * 0.0722) / 100.0
    $aXYZ[2] = ($aRGB[0] * 0.0193 + $aRGB[1] * 0.1192 + $aRGB[2] * 0.9505) / 108.883

    For $i = 0 To 2
        If $aXYZ[$i] > 0.008856 Then
            $aXYZ[$i] = $aXYZ[$i] ^ 0.3333333333333333
        Else
            $aXYZ[$i] = (7.787 * $aXYZ[$i]) + (16 / 116)
        EndIf
    Next

    Local $aLAB[3]
    $aLAB[0] = (116 * $aXYZ[1]) - 16
    $aLAB[1] = 500 * ($aXYZ[0] - $aXYZ[1])
    $aLAB[2] = 200 * ($aXYZ[1] - $aXYZ[2])

    Return $aLAB
EndFunc


Func RGB2LAB($iRGB)
    Local $r = BitAND(BitShift($iRGB, 16), 0xFF) / 255, _
          $g = BitAND(BitShift($iRGB, 8), 0xFF) / 255, _
          $b = BitAND($iRGB, 0xFF) / 255

          $r = ($r > 0.04045) ? Pow(($r + 0.055) / 1.055, 2.4) : $r / 12.92
          $g = ($g > 0.04045) ? Pow(($g + 0.055) / 1.055, 2.4) : $g / 12.92
          $b = ($b > 0.04045) ? Pow(($b + 0.055) / 1.055, 2.4) : $b / 12.92

          $x = ($r * 0.4124 + $g * 0.3576 + $b * 0.1805) / 0.95047
          $y = ($r * 0.2126 + $g * 0.7152 + $b * 0.0722) / 1.00000
          $z = ($r * 0.0193 + $g * 0.1192 + $b * 0.9505) / 1.08883

          $x = ($x > 0.008856) ? Pow($x, $1d3) : (7.787 * $x) + $16d116
          $y = ($y > 0.008856) ? Pow($y, $1d3) : (7.787 * $y) + $16d116
          $z = ($z > 0.008856) ? Pow($z, $1d3) : (7.787 * $z) + $16d116

    Local $aLAB[3] = [(116 * $y) - 16, 500 * ($x - $y), 200 * ($y - $z)]
    Return $aLAB
EndFunc

Func LAB2RGB($lab)
    Local $y = ($lab[0] + 16) / 116, $x = $lab[1] / 500 + $y, $z = $y - $lab[2] / 200, $r, $g, $b
    $x = 0.95047 * (($x * $x * $x > 0.008856) ? $x * $x * $x : ($x - 16/116) / 7.787)
    $y = 1.00000 * (($y * $y * $y > 0.008856) ? $y * $y * $y : ($y - 16/116) / 7.787)
    $z = 1.08883 * (($z * $z * $z > 0.008856) ? $z * $z * $z : ($z - 16/116) / 7.787)

    $r = $x *  3.2406 + $y * -1.5372 + $z * -0.4986
    $g = $x * -0.9689 + $y *  1.8758 + $z *  0.0415
    $b = $x *  0.0557 + $y * -0.2040 + $z *  1.0570

    $r = ($r > 0.0031308) ? (1.055 * Pow($r, 1/2.4) - 0.055) : 12.92 * $r
    $g = ($g > 0.0031308) ? (1.055 * Pow($g, 1/2.4) - 0.055) : 12.92 * $g
    $b = ($b > 0.0031308) ? (1.055 * Pow($b, 1/2.4) - 0.055) : 12.92 * $b
    Return _ColorRGB(Max(0, Min(1, $r)) * 255, Max(0, Min(1, $g)) * 255, Max(0, Min(1, $b)) * 255)
EndFunc


; Calculate the color difference between two colors in L*a*b* space
Func ColorDifference($lab1, $lab2)
    Local $dE = 0
    ; calculate the differences in L*, a*, and b* components
    Local $dL = Abs(($lab1[0]) - ($lab2[0]))
    Local $da = Abs(($lab1[1]) - ($lab2[1]))
    Local $db = Abs(($lab1[2]) - ($lab2[2]))
    ; calculate the chroma and hue differences
    Local $dC = Sqrt($da^2 + $db^2)
    Local $dH = Sqrt($dL^2 + $dC^2)
    ; calculate the weighting factors
    Local $SL = $lab1[0] + $lab2[0]
    Local $SC = $dC + Sqrt($lab1[1]^2 + $lab1[2]^2) + Sqrt($lab2[1]^2 + $lab2[2]^2)
    Local $SH = Sqrt($lab1[1]^2 + $lab1[2]^2) + Sqrt($lab2[1]^2 + $lab2[2]^2) + $dC
    Local $fL = 1 - 0.5 * ($SL - 50)^2 / (50^2 + 0.000001)
    Local $fC = 0.5 * (1 + $SC / ($SC + 0.000001))
    Local $fH = 0.5 * (1 + $SH / ($SH + 0.000001))
    ; calculate the CIEDE2000 color difference
    If $dH <= 1 And $dC <= 1 Then
        $dE = Sqrt($dL^2 + $dC^2 + $dH^2)
    Else
        $dE = Sqrt($dL^2 + ($fC * $dC)^2 + ($fH * $dH)^2)
    EndIf
    Return $dE
EndFunc


Global $aColors[] = [0xFF0018, 0x0095FF, 0xEFEFEF, 0x000000, 0xFDEA00], $LABColors[UBound($aColors)]
Global $i, $temp, $differences[UBound($aColors)][UBound($aColors)], $sums[UBound($aColors)][2], $sortedColors[UBound($aColors)]

; convert the hex colors to L*a*b* colors
For $i = 0 To UBound($aColors) - 1
    $LABColors[$i] = RGB2LAB($aColors[$i])
Next

; calculate the color differences between each pair of colors
For $i = 0 To UBound($aColors) - 2
    For $j = $i + 1 To UBound($aColors) - 1
        $differences[$i][$j] = CIEDE2000($LABColors[$i], $LABColors[$j])
        $differences[$j][$i] = $differences[$i][$j]
    Next
Next

; sort the colors based on the sum of their color differences with the other colors
For $i = 0 To UBound($aColors) - 1
    $sums[$i][0] = 0
    $sums[$i][1] = $aColors[$i]
    For $j = 0 To UBound($aColors) - 1
        If $i <> $j Then
            $sums[$i][0] += $differences[$i][$j]
        EndIf
    Next
Next
_ArraySort($sums)

; reorder the colors based on the sorted sums
For $i = 0 To UBound($LABColors) - 1
    $sortedColors[$i] = $sums[$i][1]
Next

Global $aSoll[] = ["0xEFEFEF", "0xFDEA00", "0x0095FF", "0xFF0018", "0x000000"]

; display result
ConsoleWrite("Color" & @TAB & "Sort." & @TAB & "Soll" & @CRLF)

For $i = 0 To UBound($LABColors) - 1
    ConsoleWrite(Hex($aColors[$i], 6) & @TAB & Hex($sortedColors[$i], 6) & @TAB & $aSoll[$i] & @CRLF)
Next

Alles anzeigen

Vielleicht sieht jemand den Fehler...

RGB2LAB / LAB2RGB sind von einem JS portiert zwecks Test. Output von eukalyptus' RGB2LAB Version ist identisch

**UEZ**

fee danke für deinen Beitrag!

Das Resultat von SortByBrightColor ist besser als das von SortByLum, was ähnlich ist.

Die Seite von Elektrobild habe ich auch gesehen, aber ist kein Code veröffentlicht. Ich habe im Source Code geschaut, aber nicht den Code momentan noch nicht entdeckt.

Danke.

**UEZ**

Mars das Resultat gefällt mir

So siehts momentan mit zufälligen Farben aus:


So sieht es bei der Farbtabelle von Andy aus:


Der aktuelle Code dazu:

AutoIt

;Coded by UEZ build 2023-03-16
#include <Array.au3>
#include <GDIPlus.au3>
#include <GUIConstantsEx.au3>
#include <WindowsConstants.au3>
_GDIPlus_Startup()

Global $hGUI = GUICreate("GDI+ Color Sorting / Grouping Test", 800, 480)
GUISetState()
Global $hGraphic = _GDIPlus_GraphicsCreateFromHWND($hGUI)
Global $hPen = _GDIPlus_PenCreate(0)
_GDIPlus_GraphicsClear($hGraphic)


Global $aColortable[511], $i, $y = 0
For $i = 0 To UBound($aColortable) - 1
    $aColortable[$i] = Int(Random() * 0x1000000)
Next

;~ For $i = 0 To UBound($aColortable) - 1
;~     Do
;~         $iColor = Int(Random() * 0xFFFFFF)
;~         $a = RGB2HSV($iColor)
;~     Until $a[2] > 0.98 And $a[1] > 0.98
;~     $aColortable[$i] = $iColor
;~ Next

DrawColors($y, "Random")

_ArraySort($aColortable)
$y += 40
DrawColors($y, "Default Array Sort")

SortByCMYK($aColortable)
$y += 40
DrawColors($y, "CMYK")

SortByLum($aColortable)
$y += 40
DrawColors($y, "Luminosity")

SortByDistance($aColortable)
$y += 40
DrawColors($y, "Distance")

SortByHSL($aColortable)
$y += 40
DrawColors($y, "HSL by L")

SortByHSV($aColortable)
$y += 40
DrawColors($y, "HSV by V")

SortByHSL($aColortable, 1)
$y += 40
DrawColors($y, "HSL / HSV by H")

SortByHSL2($aColortable)
$y += 40
DrawColors($y, "HSV 2")

SortByGroupingHSL($aColortable)
$y += 40
DrawColors($y, "Grouping HSL by dist.")

SortByGroupingHSV($aColortable)
$y += 40
DrawColors($y, "Grouping HSV by LAB")

SortByLAB($aColortable)
$y += 40
DrawColors($y, "LAB")

While GUIGetMsg() <> $GUI_EVENT_CLOSE
    Sleep(10)
WEnd

_GDIPlus_PenDispose($hPen)
_GDIPlus_GraphicsDispose($hGraphic)
_GDIPlus_Shutdown()
GUIDelete()
Exit

Func DrawColors($y, $txt = 0, $array = $aColortable)
    If UBound($array, 2) Then
        For $i = 0 To UBound($array) - 1
            _GDIPlus_PenSetColor($hPen, BitOR(0xFF000000, $array[$i][0]))
            _GDIPlus_GraphicsDrawLine($hGraphic, $i, $y, $i, $y + 32, $hPen)
        Next
    Else
        For $i = 0 To UBound($array) - 1
            _GDIPlus_PenSetColor($hPen, BitOR(0xFF000000, $array[$i]))
            _GDIPlus_GraphicsDrawLine($hGraphic, $i, $y, $i, $y + 32, $hPen)
        Next
    EndIf
    If $txt Then _GDIPlus_GraphicsDrawString($hGraphic, $txt, $i + 8, $y + 4, "Arial", 16, Default, 0xFFFFFFFF)
EndFunc

Func SortByCMYK(ByRef $aColortable) ;http://www.easyrgb.com/en/math.php
    Local $aColortable2[UBound($aColortable)][6]
    Local $a, $i
    For $i = 0 To UBound($aColortable) - 1
        $a = RGA2CMYK($aColortable[$i])
        $aColortable2[$i][0] = $aColortable[$i]
        $aColortable2[$i][1] = $a[0] ;C
        $aColortable2[$i][2] = $a[1] ;M
        $aColortable2[$i][3] = $a[2] ;Y
        $aColortable2[$i][4] = $a[3] ;K
        $aColortable2[$i][5] = Sqrt($a[0] ^ 2 + $a[1] ^ 2 + $a[2] ^ 2 + $a[3] ^ 2)
    Next
    Local $aSort[] = [5, 3]
    _ArraySort_MultiColumn($aColortable2, $aSort, 1, 0)
    For $i = 0 To UBound($aColortable2) - 1
        $aColortable[$i] = $aColortable2[$i][0]
    Next
    Dim $aColortable2[0]
EndFunc

Func SortByLum(ByRef $aColortable)
    Local $aColortable2[UBound($aColortable)][4], $a, $i, $r, $g, $b, $lum, $h2, $lum2, $v2, $repetitions = 1
    For $i = 0 To UBound($aColortable) - 1
        $r = BitShift(BitAND($aColortable[$i], 0xFF0000), 16)
        $g = BitShift(BitAND($aColortable[$i], 0xFF00), 8)
        $b = BitAND($aColortable[$i], 0xFF)
        $lum = Sqrt(0.241 * $r + 0.691 * $g + 0.068 * $b)
        $a = RGB2HSV($aColortable[$i])
        $h2 = Int($a[0] * $repetitions)
        $lum2 = Int($lum * $repetitions)
        $v2 = Int($a[2] * $repetitions)
;~         If Mod($h2, 2) = 1 Then
;~             $v2 = $repetitions - $v2
;~             $lum2 = $repetitions - $lum
;~         EndIf
        $aColortable2[$i][0] = $aColortable[$i]
        $aColortable2[$i][1] = $h2 ;H
        $aColortable2[$i][2] = $lum2 ;S
        $aColortable2[$i][3] = $v2 ;V
    Next
;~     Local $aSort[] = [2, 3]
;~     _ArraySort_MultiColumn($aColortable2, $aSort, 0, 0)
;~     DrawColors(96, "Test", $aColortable2)
    Local $aSort2[][] = [[2, 0], [3, 0]]
    _ArrayMultiColSort($aColortable2, $aSort2)
    For $i = 0 To UBound($aColortable2) - 1
        $aColortable[$i] = $aColortable2[$i][0]
    Next
    Dim $aColortable2[0]
EndFunc

Func SortByLAB(ByRef $aColortable, $iStartRGB = 0) ;by eukalyptus
    Local $iDim = UBound($aColortable), $iDim2 = UBound($aColortable, 2)
    Local $aLAB[$iDim][2], $i

    If $iDim2 Then
        For $i = 0 To $iDim - 1
            $aLAB[$i][0] = _RGB2LAB($aColortable[$i][0])
        Next
    Else
        For $i = 0 To $iDim - 1
            $aLAB[$i][0] = _RGB2LAB($aColortable[$i])
        Next
    EndIf

    Local $aLastLAB = _RGB2LAB($iStartRGB)

    Local $aSort[$iDim], $fD, $fMin, $iIdx
    For $i = 0 To $iDim - 1
        $fMin = 2 ^ 32
        $iIdx = -1
        For $j = 0 To $iDim - 1
            If $aLAB[$j][1] Then ContinueLoop
            $fD = Sqrt((($aLAB[$j][0])[0] - $aLastLAB[0]) ^ 2 + (($aLAB[$j][0])[1] - $aLastLAB[1]) ^ 2 + (($aLAB[$j][0])[2] - $aLastLAB[2]) ^ 2)
            If $fD < $fMin Then
                $fMin = $fD
                $iIdx = $j
            EndIf
        Next
        $aSort[$i] = $iIdx
        $aLastLAB = $aLAB[$iIdx][0]
        $aLAB[$iIdx][1] = True
    Next

    $aTmp = $aColortable
    For $i = 0 To $iDim - 1
        If $iDim2 Then
            $aColortable[$i][0] = $aTmp[$aSort[$i]][0]
        Else
            $aColortable[$i] = $aTmp[$aSort[$i]]
        EndIf
    Next
EndFunc

Func _RGB2LAB($iRGB) ;by eukalyptus
    Local $aRGB[3], $i
    $aRGB[0] = BitAND(BitShift($iRGB, 16), 0xFF) / 255
    $aRGB[1] = BitAND(BitShift($iRGB, 8), 0xFF) / 255
    $aRGB[2] = BitAND($iRGB, 0xFF) / 255

    For $i = 0 To 2
        If $aRGB[$i] > 0.04045 Then
            $aRGB[$i] = (($aRGB[$i] + 0.055) / 1.055) ^ 2.4
        Else
            $aRGB[$i] = $aRGB[$i] / 12.92
        EndIf
        $aRGB[$i] *= 100
    Next

    Local $aXYZ[3]
    $aXYZ[0] = ($aRGB[0] * 0.4124 + $aRGB[1] * 0.3576 + $aRGB[2] * 0.1805) / 95.047
    $aXYZ[1] = ($aRGB[0] * 0.2126 + $aRGB[1] * 0.7152 + $aRGB[2] * 0.0722) / 100.0
    $aXYZ[2] = ($aRGB[0] * 0.0193 + $aRGB[1] * 0.1192 + $aRGB[2] * 0.9505) / 108.883

    For $i = 0 To 2
        If $aXYZ[$i] > 0.008856 Then
            $aXYZ[$i] = $aXYZ[$i] ^ 0.3333333333333333
        Else
            $aXYZ[$i] = (7.787 * $aXYZ[$i]) + (16 / 116)
        EndIf
    Next

    Local $aLAB[3]
    $aLAB[0] = (116 * $aXYZ[1]) - 16
    $aLAB[1] = 500 * ($aXYZ[0] - $aXYZ[1])
    $aLAB[2] = 200 * ($aXYZ[1] - $aXYZ[2])

    Return $aLAB
EndFunc

Func SortByDistance(ByRef $aColortable, $iDir = 0)
    Local $i, $aTmp[2], $swapped
    If $iDir = 0 Then ;sort ascending
        If UBound($aColortable, 2) Then
            Do ;bubblesort -> slow!
                $swapped = 0
                For $i = 0 To UBound($aColortable) - 2
                    Distance($aColortable[$i][0], $aColortable[$i + 1][0])
                    If @extended Then
                        $aTmp[0] = $aColortable[$i][0]
                        $aColortable[$i][0] = $aColortable[$i + 1][0]
                        $aColortable[$i + 1][0] = $aTmp[0]
                        $swapped = 1
                    EndIf
                Next
            Until $swapped = 0
        Else
            Do ;bubblesort -> slow!
                $swapped = 0
                For $i = 0 To UBound($aColortable) - 2
                    Distance($aColortable[$i], $aColortable[$i + 1])
                    If @extended Then
                        $aTmp[0] = $aColortable[$i]
                        $aColortable[$i] = $aColortable[$i + 1]
                        $aColortable[$i + 1] = $aTmp[0]
                        $swapped = 1
                    EndIf
                Next
            Until $swapped = 0
        EndIf
    Else ;sort descending
        If UBound($aColortable, 2) Then
            Do ;bubblesort -> slow!
                $swapped = 0
                For $i = UBound($aColortable) - 1 To 1 Step -1
                    Distance($aColortable[$i][0], $aColortable[$i - 1][0])
                    If @extended Then
                        $aTmp[0] = $aColortable[$i][0]
                        $aColortable[$i][0] = $aColortable[$i - 1][0]
                        $aColortable[$i - 1][0] = $aTmp[0]
                        $swapped = 1
                    EndIf
                Next
            Until $swapped = 0
        Else
            Do ;bubblesort -> slow!
                $swapped = 0
                For $i = UBound($aColortable) - 1 To 1 Step -1
                    Distance($aColortable[$i], $aColortable[$i - 1])
                    If @extended Then
                        $aTmp[0] = $aColortable[$i]
                        $aColortable[$i] = $aColortable[$i - 1]
                        $aColortable[$i - 1] = $aTmp[0]
                        $swapped = 1
                    EndIf
                Next
            Until $swapped = 0
        EndIf
    EndIf
EndFunc

Func SortByHSL(ByRef $aColortable, $sc = 3)
    Local $aColortable2[UBound($aColortable)][5]
    Local $a, $i
    For $i = 0 To UBound($aColortable) - 1
        $a = RGB2HSL($aColortable[$i])
        $aColortable2[$i][0] = $aColortable[$i]
        $aColortable2[$i][1] = $a[0] ;H
        $aColortable2[$i][2] = $a[1] ;S
        $aColortable2[$i][3] = $a[2] ;L
        $aColortable2[$i][4] = Sqrt($a[0] ^ 2 + $a[1] ^ 4 + $a[2] ^ 8) ;Sqrt(($a[0] / 360) ^ 2 + $a[1] ^ 2 + $a[2] ^ 2)
    Next
    $sc = Max(Min($sc, 4), 1)
    _ArraySort($aColortable2, 0, 0, 0, $sc)
    For $i = 0 To UBound($aColortable2) - 1
        $aColortable[$i] = $aColortable2[$i][0]
    Next
    Dim $aColortable2[0]
EndFunc

Func SortByHSV(ByRef $aColortable, $sc = 3)
    Local $aColortable2[UBound($aColortable)][4]
    Local $a, $i
    For $i = 0 To UBound($aColortable) - 1
        $a = RGB2HSV($aColortable[$i])
        $aColortable2[$i][0] = $aColortable[$i]
        $aColortable2[$i][1] = $a[0]
        $aColortable2[$i][2] = $a[1]
        $aColortable2[$i][3] = $a[2]
    Next
    $sc = Max(Min($sc, 3), 1)
    _ArraySort($aColortable2, 0, 0, 0, $sc)
    For $i = 0 To UBound($aColortable2) - 1
        $aColortable[$i] = $aColortable2[$i][0]
    Next
    Dim $aColortable2[0]
EndFunc

Func SortByGroupingHSL(ByRef $aColortable, $sc = 2, $sortmode = 2)
    Local $red[0][2], $orange[0][2], $yellow[0][2], $lime[0][2], $green[0][2], $turqoise[0][2], $cyan[0][2], $cobalt[0][2], $blue[0][2], $violet[0][2], $magenta[0][2], $crimson[0][2], $grey[0][2], $i, $j, $col
    $sc = Max(Min($sc, 2), 0)
    For $i = 0 To UBound($aColortable) - 1
        $col = $aColortable[$i]
        Switch RGBtoColorGroup($col)
            Case "red"
                _ArrayAdd($red, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "orange"
                _ArrayAdd($orange, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "yellow"
                _ArrayAdd($yellow, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "lime"
                _ArrayAdd($lime, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "green"
                _ArrayAdd($green, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "turqoise"
                _ArrayAdd($turqoise, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "cyan"
                _ArrayAdd($cyan, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "cobalt"
                _ArrayAdd($cobalt, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "blue"
                _ArrayAdd($blue, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "violet"
                _ArrayAdd($violet, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "magenta"
                _ArrayAdd($magenta, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "crimson"
                _ArrayAdd($crimson, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "grey"
                _ArrayAdd($grey, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
        EndSwitch
    Next
    $sortmode = Max(Min($sortmode, 2), 1)
    Switch $sortmode
        Case 1
            _ArraySort($red, 0, 0, 0, 1)
            _ArraySort($orange, 0, 0, 0, 1)
            _ArraySort($yellow, 0, 0, 0, 1)
            _ArraySort($lime, 0, 0, 0, 1)
            _ArraySort($green, 0, 0, 0, 1)
            _ArraySort($turqoise, 0, 0, 0, 1)
            _ArraySort($cyan, 0, 0, 0, 1)
            _ArraySort($cobalt, 0, 0, 0, 1)
            _ArraySort($blue, 0, 0, 0, 1)
            _ArraySort($violet, 0, 0, 0, 1)
            _ArraySort($magenta, 0, 0, 0, 1)
            _ArraySort($crimson, 0, 0, 0, 1)
            _ArraySort($grey, 0, 0, 0, 1)
        Case 2
            SortByDistance($red, 1)
            SortByDistance($orange)
            SortByDistance($yellow, 1)
            SortByDistance($lime)
            SortByDistance($green, 1)
            SortByDistance($turqoise)
            SortByDistance($cyan, 1)
            SortByDistance($cobalt)
            SortByDistance($blue, 1)
            SortByDistance($violet)
            SortByDistance($magenta, 1)
            SortByDistance($crimson)
            SortByDistance($grey, 1)
    EndSwitch
    $i = 0
    For $j = 0 To UBound($crimson) - 1
        $aColortable[$i] = $crimson[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($red) - 1
        $aColortable[$i] = $red[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($orange) - 1
        $aColortable[$i] = $orange[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($yellow) - 1
        $aColortable[$i] = $yellow[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($lime) - 1
        $aColortable[$i] = $lime[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($green) - 1
        $aColortable[$i] = $green[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($turqoise) - 1
        $aColortable[$i] = $turqoise[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($cyan) - 1
        $aColortable[$i] = $cyan[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($cobalt) - 1
        $aColortable[$i] = $cobalt[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($blue) - 1
        $aColortable[$i] = $blue[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($violet) - 1
        $aColortable[$i] = $violet[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($magenta) - 1
        $aColortable[$i] = $magenta[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($grey) - 1
        $aColortable[$i] = $grey[$j][0]
        $i += 1
    Next
EndFunc

Func SortByGroupingHSV(ByRef $aColortable, $sc = 2, $sortmode = 3)
    Local $red[0][2], $orange[0][2], $yellow[0][2], $lime[0][2], $green[0][2], $turqoise[0][2], $cyan[0][2], $cobalt[0][2], $blue[0][2], $violet[0][2], $magenta[0][2], $crimson[0][2], $grey[0][2], $i, $j, $col
    $sc = Max(Min($sc, 2), 0)
    For $i = 0 To UBound($aColortable) - 1
        $col = $aColortable[$i]
        Switch RGBtoColorGroup($col)
            Case "red"
                _ArrayAdd($red, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "orange"
                _ArrayAdd($orange, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "yellow"
                _ArrayAdd($yellow, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "lime"
                _ArrayAdd($lime, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "green"
                _ArrayAdd($green, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "turqoise"
                _ArrayAdd($turqoise, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "cyan"
                _ArrayAdd($cyan, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "cobalt"
                _ArrayAdd($cobalt, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "blue"
                _ArrayAdd($blue, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "violet"
                _ArrayAdd($violet, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "magenta"
                _ArrayAdd($magenta, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "crimson"
                _ArrayAdd($crimson, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "grey"
                _ArrayAdd($grey, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
        EndSwitch
    Next
    $sortmode = Max(Min($sortmode, 3), 1)
    Switch $sortmode
        Case 1
            _ArraySort($red, 0, 0, 0, 1)
            _ArraySort($orange, 0, 0, 0, 1)
            _ArraySort($yellow, 0, 0, 0, 1)
            _ArraySort($lime, 0, 0, 0, 1)
            _ArraySort($green, 0, 0, 0, 1)
            _ArraySort($turqoise, 0, 0, 0, 1)
            _ArraySort($cyan, 0, 0, 0, 1)
            _ArraySort($cobalt, 0, 0, 0, 1)
            _ArraySort($blue, 0, 0, 0, 1)
            _ArraySort($violet, 0, 0, 0, 1)
            _ArraySort($magenta, 0, 0, 0, 1)
            _ArraySort($crimson, 0, 0, 0, 1)
            _ArraySort($grey, 0, 0, 0, 1)
        Case 2
            SortByDistance($red, 1)
            SortByDistance($orange)
            SortByDistance($yellow, 1)
            SortByDistance($lime)
            SortByDistance($green, 1)
            SortByDistance($turqoise)
            SortByDistance($cyan, 1)
            SortByDistance($cobalt)
            SortByDistance($blue, 1)
            SortByDistance($violet)
            SortByDistance($magenta, 1)
            SortByDistance($crimson)
            SortByDistance($grey, 1)
        Case 3
            SortByLAB($red)
            SortByLAB($orange)
            SortByLAB($yellow)
            SortByLAB($lime)
            SortByLAB($green)
            SortByLAB($turqoise)
            SortByLAB($cyan)
            SortByLAB($cobalt)
            SortByLAB($blue)
            SortByLAB($violet)
            SortByLAB($magenta)
            SortByLAB($crimson)
            SortByLAB($grey)
    EndSwitch
    $i = 0
    For $j = 0 To UBound($red) - 1
        $aColortable[$i] = $red[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($orange) - 1
        $aColortable[$i] = $orange[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($yellow) - 1
        $aColortable[$i] = $yellow[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($lime) - 1
        $aColortable[$i] = $lime[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($green) - 1
        $aColortable[$i] = $green[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($turqoise) - 1
        $aColortable[$i] = $turqoise[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($cyan) - 1
        $aColortable[$i] = $cyan[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($cobalt) - 1
        $aColortable[$i] = $cobalt[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($blue) - 1
        $aColortable[$i] = $blue[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($violet) - 1
        $aColortable[$i] = $violet[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($magenta) - 1
        $aColortable[$i] = $magenta[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($crimson) - 1
        $aColortable[$i] = $crimson[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($grey) - 1
        $aColortable[$i] = $grey[$j][0]
        $i += 1
    Next
EndFunc

Func SortByHSL2(ByRef $aColortable) ;by Mars
    Local $aColortable2[UBound($aColortable)][9]
    Local $a, $i, $hsl_
    For $i = 0 To UBound($aColortable) - 1
        $a = _RGB2LAB($aColortable[$i])
        $hsl_ = RGB2HSL($aColortable[$i])
        $aColortable2[$i][0] = $aColortable[$i]
        $aColortable2[$i][1] = $a[0] ; LAB -> L
        $aColortable2[$i][2] = Sqrt($a[1]^2 + $a[2]^2) ; chroma
        $aColortable2[$i][3] = Abs($a[0] - 50) ; L umformen um "hell und dunkel" rauszufiltern
        $aColortable2[$i][4] = $hsl_[0] ; HSL -> H (könnte man via Farbwinkel aus LAB auch machen, hab ich ausprobiert, sah nicht so schön aus)
    Next
    Local $10 = Int(UBound($aColortable)/10)
    _ArraySort($aColortable2, 0, 0, 0, 2) ; chroma -> ziemlich "unbunte" farben herausfiltern (10%)
    _ArraySort($aColortable2, 1, 1 * $10 + 1, 0 * $10, 3) ; abs(L-50) -> sehr helle und sehr dunkle Farben herausfiltern
    _ArraySort($aColortable2, 0, 1 * $10 + 1, 5 * $10, 2) ; chroma -> von den hellen und dunklen Farben die unbuntesten raussuchen (nochmal 10%)
    _ArraySort($aColortable2, 0, 0 * $10 + 0, 2 * $10, 1) ; Die packt man links an das erste 5tel als eine Art "Pseudograustufenliste" (darin sind 20% aller Farben)
    _ArraySort($aColortable2, 0, 2 * $10 + 1, 0 * $10, 1) ; L -> sortiere nach Helligkeit
    _ArraySort($aColortable2, 0, 2 * $10 + 1, 6 * $10, 4) ; H -> Sortiere nach Hue (1x für niedrige Helligkeit)
    _ArraySort($aColortable2, 1, 6 * $10 + 1, 0 * $10, 4) ; H -> Sortiere nach Hue (1x für hohe Helligkeit)
    For $i = 0 To UBound($aColortable2) - 1
        $aColortable[$i] = $aColortable2[$i][0]
    Next
    Dim $aColortable2[0]
EndFunc

Func RGBtoColorGroup($iColor)
    Local $HSL = RGB2HSL($iColor), $H, $r
    If $HSL[0] = 0 And $HSL[1] = 0 Then
        $H = -1
    Else
        $H = $HSL[0]
    EndIf
    Switch Round($H, 0)
        Case 0 To 14, 345 To 359
            Return "red"
        Case 15 To 44
            Return "orange"
        Case 45 To 74
            Return "yellow"
        Case 75 To 104
            Return "lime"
        Case 105 To 134
            Return "green"
        Case 135 To 164
            Return "turqoise"
        Case 165 To 194
            Return "cyan"
        Case 195 To 224
            Return "cobalt"
        Case 225 To 254
            Return "blue"
        Case 255 To 284
            Return "violet"
        Case 285 To 314
            Return "magenta"
        Case 315 To 344
            Return "crimson"
        Case -1
            Return "grey"
    EndSwitch
EndFunc

Func Distance($c1, $c2)
    Local $r1 = BitShift(BitAND($c1, 0xFF0000), 16), $g1 = BitShift(BitAND($c1, 0xFF00), 8), $b1 = BitAND($c1, 0xFF)
    Local $r2 = BitShift(BitAND($c2, 0xFF0000), 16), $g2 = BitShift(BitAND($c2, 0xFF00), 8), $b2 = BitAND($c2, 0xFF)
    Local $dr = $r2 - $r1, $dg = $g2 - $g1, $db =  $b2 - $b1
    Return SetExtended($dr + $dg + $db < 0, Sqrt($dr * $dr + $dg * $dg + $db * $db))
EndFunc

Func RGB2HSL($iColor) ;http://www.easyrgb.com/en/math.php
    Local $var_r = BitAND(BitShift($iColor, 16), 255) / 255, $var_g = BitAND(BitShift($iColor, 8), 255) / 255, $var_b = BitAND($iColor, 255) / 255
    Local $H, $S, $L, $var_Min, $var_Max, $del_Max, $del_Max2, $del_R, $del_G, $del_B

    $var_Min = Min3($var_r, $var_g, $var_b)
    $var_Max = Max3($var_r, $var_g, $var_b)
    $del_Max = $var_Max - $var_Min
    $L = ($var_Max + $var_Min) / 2
    If $del_Max = 0 Then
        $H = 0
        $S = 0
    Else
        $S = $L < 0.5 ? $del_Max / ($var_Max + $var_Min) : $del_Max / (2 - $var_Max - $var_Min)
        $del_Max2 = $del_Max / 2
        $del_R = ((($var_Max - $var_R) / 6) + $del_Max2) / $del_Max
        $del_G = ((($var_Max - $var_G) / 6) + $del_Max2) / $del_Max
        $del_B = ((($var_Max - $var_B) / 6) + $del_Max2) / $del_Max
        If ($var_R = $var_Max) Then
            $H = $del_B - $del_G
        Elseif $var_G = $var_Max Then
            $H = 0.333333333333333 + $del_R - $del_B
        Elseif $var_B = $var_Max Then
            $H = 0.666666666666667 + $del_G - $del_R
        EndIf
        If $H < 0 Then $H += 1
        If $H > 1 Then $H -= 1
    EndIf
    Local $aHSL[3] = [$H * 360, $S, $L]
    Return $aHSL
EndFunc

Func RGB2HSV($iColor) ;http://www.easyrgb.com/en/math.php
    Local $var_r = BitAND(BitShift($iColor, 16), 255) / 255, $var_g = BitAND(BitShift($iColor, 8), 255) / 255, $var_b = BitAND($iColor, 255) / 255
    Local $H, $S, $V, $var_Min, $var_Max, $del_Max, $del_Max2, $del_R, $del_G, $del_B

    $var_Min = Min3($var_r, $var_g, $var_b)
    $var_Max = Max3($var_r, $var_g, $var_b)
    $del_Max = $var_Max - $var_Min
    $V = $var_Max
    If $del_Max = 0 Then
        $H = 0
        $S = 0
    Else
        $S = $del_Max / $var_Max
        $del_Max2 = $del_Max / 2
        $del_R = ((($var_Max - $var_R) / 6) + $del_Max2) / $del_Max
        $del_G = ((($var_Max - $var_G) / 6) + $del_Max2) / $del_Max
        $del_B = ((($var_Max - $var_B) / 6) + $del_Max2) / $del_Max
        If $var_R = $var_Max Then
            $H = $del_B - $del_G
        ElseIf $var_G = $var_Max Then
            $H = 0.333333333333333 + $del_R - $del_B
        ElseIf $var_B = $var_Max Then
            $H = 0.666666666666667 + $del_G - $del_R
        EndIf
        If $H < 0 Then $H += 1
        If $H > 1 Then $H -= 1
    EndIf
    Local $aHSV[3] = [$H * 360, $S, $V]
    Return $aHSV
EndFunc

Func RGA2CMYK($iColor)
    Local $r = BitAND(BitShift($iColor, 16), 255), $g = BitAND(BitShift($iColor, 8), 255), $b = BitAND($iColor, 255)
    Local $C = 1 - ($r / 255), $M = 1 - ($G / 255), $Y = 1 - ($B / 255), $K = 1
    If ($C < $K) Then $K = $C
    If ($M < $K) Then $K = $M
    If ($Y < $K) Then $K = $Y
    If ($K = 1) Then ;Black only
        $C = 0
        $M = 0
        $Y = 0
    Else
        $C = ($C - $K) / (1 - $K)
        $M = ($M - $K) / (1 - $K)
        $Y = ($Y - $K) / (1 - $K)
    EndIf
    Local $aCMYK[] = [$C, $M, $Y, $K]
    Return $aCMYK
EndFunc

Func Min($a, $b)
    Return ($a < $b) ? $a : $b
EndFunc

Func Max($a, $b)
    Return ($a > $b) ? $a : $b
EndFunc

Func Min3($a, $b, $c)
    Return Min(Min($a, $b), $C)
EndFunc

Func Max3($a, $b, $c)
    Return Max(Max($a, $b), $C)
EndFunc

; #FUNCTION# =============================================================================
; Name.............:    _ArraySort_MultiColumn
; Description ...:      sorts an array at given colums (multi colum sort)
; Syntax...........:    _ArraySort_MultiColumn(ByRef $aSort, ByRef $aIndices)
; Parameters ...:        $aSort - array to sort
;                        $aIndices - array with colum indices which should be sorted in specified order - zero based
;                        $oDir/$iDir - sort direction - if set to 1, sort descending else ascending. $oDir is for the 1st row,
;                                                      $iDir for the remaining rows
;                        $iStart - where to start to sort - 0 = 0 based array, 1 = 1 based array
; Author .........:        UEZ
; Version ........:        v0.80 build 2019-01-26 Beta
; =========================================================================================
Func _ArraySort_MultiColumn(ByRef $aSort, ByRef $aIndices, $oDir = 0, $iDir = 0, $iStart = 0)
    If Not IsArray($aIndices) Or Not IsArray($aSort) Then Return SetError(1, 0, 0) ;checks if $aIndices is an array
    If UBound($aSort, 2) = 0 Then Return SetError(4, 0, 0) ;array is 1D only
    If UBound($aIndices) > UBound($aSort, 2) Then Return SetError(2, 0, 0) ;check if $aIndices array is greater the $aSort array
    Local $1st, $2nd, $x, $j, $k, $l = 0
    For $x = 0 To UBound($aIndices) - 1 ;check if array content makes sense
        If Not IsInt($aIndices[$x]) Then Return SetError(3, 0, 0) ;array content is not numeric
    Next
    $iStart = Int($iStart) < 0 ? 0 : Int($iStart) > 1 ? 1 : Int($iStart)
    If UBound($aIndices) = 1 Then Return _ArraySort($aSort, $oDir, $iStart, 0, $aIndices[0]) ;check if only one index is given
    _ArraySort($aSort, $oDir, $iStart, 0, $aIndices[0])
    Do
        $1st = $aIndices[$l]
        $2nd = $aIndices[$l + 1]
        $j = 0
        $k = 1
        While $k < UBound($aSort)
            If $aSort[$j][$1st] <> $aSort[$k][$1st] Then
                If $k - $j > 1 Then
                    _ArraySort($aSort, $iDir, $j, $k - 1, $2nd)
                    $j = $k
                Else
                    $j = $k
                EndIf
            EndIf
            $k += 1
        WEnd
        If $k - $j > 1 Then _ArraySort($aSort, $iDir, $j, $k, $2nd)
        $l += 1
    Until $l = UBound($aIndices) - 1
    Return 1
EndFunc   ;==>_ArraySort_MultiColumn

; #FUNCTION# ====================================================================================================================
; Name...........: _ArrayMultiColSort
; Description ...: Sort 2D arrays on several columns
; Syntax.........: _ArrayMultiColSort(ByRef $aArray, $aSortData[, $iStart = 0[, $iEnd = 0]])
; Parameters ....: $aArray    - The 2D array to be sorted
;                  $aSortData - 2D array holding details of the sort format
;                               Format: [Column to be sorted, Sort order]
;                                   Sort order can be either numeric (0/1 = ascending/descending) or a ordered string of items
;                                   Any elements not matched in string are left unsorted after all sorted elements
;                  $iStart    - Element of array at which sort starts (default = 0)
;                  $iEnd      - Element of array at which sort endd (default = 0 - converted to end of array)
; Requirement(s).: v3.3.8.1 or higher
; Return values .: Success: No error
;                  Failure: @error set as follows
;                            @error = 1 with @extended set as follows (all refer to $sIn_Date):
;                                1 = Array to be sorted not 2D
;                                2 = Sort data array not 2D
;                                3 = More data rows in $aSortData than columns in $aArray
;                                4 = Start beyond end of array
;                                5 = Start beyond End
;                            @error = 2 with @extended set as follows:
;                                1 = Invalid string parameter in $aSortData
;                                2 = Invalid sort direction parameter in $aSortData
;                                3 = Invalid column index in $aSortData
; Author ........: Melba23
; Remarks .......: Columns can be sorted in any order
; Example .......; Yes
; ===============================================================================================================================
Func _ArrayMultiColSort(ByRef $aArray, $aSortData, $iStart = 0, $iEnd = 0)

    ; Errorchecking
    ; 2D array to be sorted
    If UBound($aArray, 2) = 0 Then
        Return SetError(1, 1, "")
    EndIf
    ; 2D sort data
    If UBound($aSortData, 2) <> 2 Then
        Return SetError(1, 2, "")
    EndIf
    If UBound($aSortData) > UBound($aArray) Then
        Return SetError(1, 3)
    EndIf
    For $i = 0 To UBound($aSortData) - 1
        If $aSortData[$i][0] < 0 Or $aSortData[$i][0] > UBound($aArray, 2) -1 Then
            Return SetError(2, 3, "")
        EndIf
    Next
    ; Start element
    If $iStart < 0 Then
        $iStart = 0
    EndIf
    If $iStart >= UBound($aArray) - 1 Then
        Return SetError(1, 4, "")
    EndIf
    ; End element
    If $iEnd <= 0 Or $iEnd >= UBound($aArray) - 1 Then
        $iEnd = UBound($aArray) - 1
    EndIf
    ; Sanity check
    If $iEnd <= $iStart Then
        Return SetError(1, 5, "")
    EndIf

    Local $iCurrCol, $iChunk_Start, $iMatchCol

    ; Sort first column
    __AMCS_SortChunk($aArray, $aSortData, 0, $aSortData[0][0], $iStart, $iEnd)
    If @error Then
        Return SetError(2, @extended, "")
    EndIf
    ; Now sort within other columns
    For $iSortData_Row = 1 To UBound($aSortData) - 1
        ; Determine column to sort
        $iCurrCol = $aSortData[$iSortData_Row][0]
        ; Create arrays to hold data from previous columns
        Local $aBaseValue[$iSortData_Row]
        ; Set base values
        For $i = 0 To $iSortData_Row - 1
            $aBaseValue[$i] = $aArray[$iStart][$aSortData[$i][0]]
        Next
        ; Set start of this chunk
        $iChunk_Start = $iStart
        ; Now work down through array
        For $iRow = $iStart + 1 To $iEnd
            ; Match each column
            For $k = 0 To $iSortData_Row - 1
                $iMatchCol = $aSortData[$k][0]
                ; See if value in each has changed
                If $aArray[$iRow][$iMatchCol] <> $aBaseValue[$k] Then
                    ; If so and row has advanced
                    If $iChunk_Start < $iRow - 1 Then
                        ; Sort this chunk
                        __AMCS_SortChunk($aArray, $aSortData, $iSortData_Row, $iCurrCol, $iChunk_Start, $iRow - 1)
                        If @error Then
                            Return SetError(2, @extended, "")
                        EndIf
                    EndIf
                    ; Set new base value
                    $aBaseValue[$k] = $aArray[$iRow][$iMatchCol]
                    ; Set new chunk start
                    $iChunk_Start = $iRow
                EndIf
            Next
        Next
        ; Sort final section
        If $iChunk_Start < $iRow - 1 Then
            __AMCS_SortChunk($aArray, $aSortData, $iSortData_Row, $iCurrCol, $iChunk_Start, $iRow - 1)
            If @error Then
                Return SetError(2, @extended, "")
            EndIf
        EndIf
    Next

EndFunc   ;==>_ArrayMultiColSort

; #INTERNAL_USE_ONLY# ===========================================================================================================
; Name...........: __AMCS_SortChunk
; Description ...: Sorts array section
; Author ........: Melba23
; Remarks .......:
; ===============================================================================================================================
Func __AMCS_SortChunk(ByRef $aArray, $aSortData, $iRow, $iColumn, $iChunkStart, $iChunkEnd)

    Local $aSortOrder

    ; Set default sort direction
    Local $iSortDirn = 1
    ; Need to prefix elements?
    If IsString($aSortData[$iRow][1]) Then
        ; Split elements
        $aSortOrder = StringSplit($aSortData[$iRow][1], ",")
        If @error Then
            Return SetError(1, 1, "")
        EndIf
        ; Add prefix to each element
        For $i = $iChunkStart To $iChunkEnd
            For $j = 1 To $aSortOrder[0]
                If $aArray[$i][$iColumn] = $aSortOrder[$j] Then
                    $aArray[$i][$iColumn] = StringFormat("%02i-", $j) & $aArray[$i][$iColumn]
                    ExitLoop
                EndIf
            Next
            ; Deal with anything that does not match
            If $j > $aSortOrder[0] Then
                $aArray[$i][$iColumn] = StringFormat("%02i-", $j) & $aArray[$i][$iColumn]
            EndIf
        Next
    Else
        Switch $aSortData[$iRow][1]
            Case 0, 1
                ; Set required sort direction if no list
                If $aSortData[$iRow][1] Then
                    $iSortDirn = -1
                Else
                    $iSortDirn = 1
                EndIf
            Case Else
                Return SetError(1, 2, "")
        EndSwitch
    EndIf

    ; Sort the chunk
    Local $iSubMax = UBound($aArray, 2) - 1
    __ArrayQuickSort2D($aArray, $iSortDirn, $iChunkStart, $iChunkEnd, $iColumn, $iSubMax)

    ; Remove any prefixes
    If IsString($aSortData[$iRow][1]) Then
        For $i = $iChunkStart To $iChunkEnd
            $aArray[$i][$iColumn] = StringTrimLeft($aArray[$i][$iColumn], 3)
        Next
    EndIf

EndFunc   ;==>__AMCS_SortChunk

Alles anzeigen

Ich weiß nicht, warum hier die Gruppierung nicht ganz passt. Bei der Gruppierung werden 12 + 1 Gruppen erstellt. Das +1 sind die Graustufen.

**UEZ**

@Bugix: danke für die Info.

Ich habe was in Freebasic geschrieben, um einfach die WinAPI besser zu lernen, da man in FB nicht den Luxus der UDFs hat.


Ich habe nun die Farbtabelle erweitert und dabei ist mir aufgefallen, dass die Farben nicht mehr "so schön" angezeigt werden. Daher der Ansatz die Farben entsprechend darzustellen.

**UEZ**

Zitat von SOLVE-SMART

Ist die Pixelbreite der einzelnen Farbe bzw. die Darstellung, abhängig von der Gesamtbreite der GUI? Also falls die einzelne Farbe ein Pixel breit sein sollte, skaliert diese Breite bei resize der GUI? Ich habe mir den Code nicht genau angeschaut, muss ich zugeben. Vielleicht könnte ich es auch dort erfassen - sind nun aber nicht gerade nur 50 Zeilen Code, daher frage ich lieber direkt UEZ.

Es werden zufällig 512 Farben generiert, sortiert und dargestellt. D.h. der Farbbalken ist 512 Pixel breit und 32 Pixel hoch. Die GUI wird nicht automatisch angepasst, sondern ist manuell angepasst.

Zitat von Peter S. Taler

ich finde das mit den "fragmentierten Farbgruppen" nicht schlimm. Im Gegenteil, Es hilft, zumindest mir, sich besser zu orientieren.

Ist ja auch nicht schlimm, sondern, je nach Fall, besser oder schlechter.

Zitat von eukalyptus

Eine Idee wäre, zuerst in HSL zu gruppieren u innerhalb mit LAB zu sortieren...

Die Idee hatte ich auch. Ich habe noch nach der Pixeldistanz innerhalb der Gruppe sortieren lassen. Hier das Resultat:


Code;

AutoIt

;Coded by UEZ build 2023-03-15
#include <Array.au3>
#include <GDIPlus.au3>
#include <GUIConstantsEx.au3>
#include <WindowsConstants.au3>
_GDIPlus_Startup()

Global $hGUI = GUICreate("GDI+ Color Sorting / Grouping Test", 800, 320)
GUISetState()
Global $hGraphic = _GDIPlus_GraphicsCreateFromHWND($hGUI)
Global $hPen = _GDIPlus_PenCreate(0)
_GDIPlus_GraphicsClear($hGraphic)


Global $aColortable[511], $i, $y = 0
For $i = 0 To UBound($aColortable) - 1
    $aColortable[$i] = Int(Random() * 0xFFFFFF)
Next

DrawColors($y, "Random")

SortByDistance($aColortable)
$y += 40
DrawColors($y, "Distance")

SortByHSL($aColortable)
$y += 40
DrawColors($y, "HSL")

SortByHSV($aColortable)
$y += 40
DrawColors($y, "HSV")

SortByGroupingHSL($aColortable)
$y += 40
DrawColors($y, "Grouping HSL")

SortByGroupingHSV($aColortable)
$y += 40
DrawColors($y, "Grouping HSV")

SortByLAB($aColortable)
$y += 40
DrawColors($y, "LAB")

_ArraySort($aColortable)
$y += 40
DrawColors($y, "Default Array Sort")

While GUIGetMsg() <> $GUI_EVENT_CLOSE
    Sleep(10)
WEnd

_GDIPlus_PenDispose($hPen)
_GDIPlus_GraphicsDispose($hGraphic)
_GDIPlus_Shutdown()
GUIDelete()
Exit

Func DrawColors($y, $txt = 0)
    For $i = 0 To UBound($aColortable) - 1
        _GDIPlus_PenSetColor($hPen, BitOR(0xFF000000, $aColortable[$i]))
        _GDIPlus_GraphicsDrawLine($hGraphic, $i, $y, $i, $y + 32, $hPen)
    Next
    If $txt Then _GDIPlus_GraphicsDrawString($hGraphic, $txt, $i + 8, $y + 4, "Arial", 16, Default, 0xFFFFFFFF)
EndFunc


Func SortByLAB(ByRef $aColortable, $iStartRGB = 0xFF0000) ;by eukalyptus
    Local $iDim = UBound($aColortable), $iDim2 = UBound($aColortable, 2)
    Local $aLAB[$iDim][2], $i

    For $i = 0 To $iDim - 1
        $aLAB[$i][0] = $iDim2 ? _RGB2LAB($aColortable[$i][0]) : _RGB2LAB($aColortable[$i])
    Next

    Local $aLastLAB = _RGB2LAB($iStartRGB)

    Local $aSort[$iDim], $fD, $fMin, $iIdx
    For $i = 0 To $iDim - 1
        $fMin = 2 ^ 32
        $iIdx = -1
        For $j = 0 To $iDim - 1
            If $aLAB[$j][1] Then ContinueLoop
            $fD = Sqrt((($aLAB[$j][0])[0] - $aLastLAB[0]) ^ 2 + (($aLAB[$j][0])[1] - $aLastLAB[1]) ^ 2 + (($aLAB[$j][0])[2] - $aLastLAB[2]) ^ 2)
            If $fD < $fMin Then
                $fMin = $fD
                $iIdx = $j
            EndIf
        Next
        $aSort[$i] = $iIdx
        $aLastLAB = $aLAB[$iIdx][0]
        $aLAB[$iIdx][1] = True
    Next

    $aTmp = $aColortable
    For $i = 0 To $iDim - 1
        If $iDim2 Then
            $aColortable[$i][0] = $aTmp[$aSort[$i]][0]
        Else
            $aColortable[$i] = $aTmp[$aSort[$i]]
        EndIf
    Next
EndFunc

Func _RGB2LAB($iRGB) ;by eukalyptus
    Local $aRGB[3], $i
    $aRGB[0] = BitAND(BitShift($iRGB, 16), 0xFF) / 255
    $aRGB[1] = BitAND(BitShift($iRGB, 8), 0xFF) / 255
    $aRGB[2] = BitAND($iRGB, 0xFF) / 255

    For $i = 0 To 2
        If $aRGB[$i] > 0.04045 Then
            $aRGB[$i] = (($aRGB[$i] + 0.055) / 1.055) ^ 2.4
        Else
            $aRGB[$i] = $aRGB[$i] / 12.92
        EndIf
        $aRGB[$i] *= 100
    Next

    Local $aXYZ[3]
    $aXYZ[0] = ($aRGB[0] * 0.4124 + $aRGB[1] * 0.3576 + $aRGB[2] * 0.1805) / 95.047
    $aXYZ[1] = ($aRGB[0] * 0.2126 + $aRGB[1] * 0.7152 + $aRGB[2] * 0.0722) / 100.0
    $aXYZ[2] = ($aRGB[0] * 0.0193 + $aRGB[1] * 0.1192 + $aRGB[2] * 0.9505) / 108.883

    For $i = 0 To 2
        If $aXYZ[$i] > 0.008856 Then
            $aXYZ[$i] = $aXYZ[$i] ^ 0.3333333333333333
        Else
            $aXYZ[$i] = (7.787 * $aXYZ[$i]) + (16 / 116)
        EndIf
    Next

    Local $aLAB[3]
    $aLAB[0] = (116 * $aXYZ[1]) - 16
    $aLAB[1] = 500 * ($aXYZ[0] - $aXYZ[1])
    $aLAB[2] = 200 * ($aXYZ[1] - $aXYZ[2])

    Return $aLAB
EndFunc

Func SortByDistance(ByRef $aColortable)
    Local $i, $aTmp[2], $swapped
    If UBound($aColortable, 2) Then
        Do ;bubblesort -> slow!
            $swapped = 0
            For $i = 0 To UBound($aColortable) - 2
                Distance($aColortable[$i][0], $aColortable[$i + 1][0])
                If @extended Then
                    $aTmp[0] = $aColortable[$i][0]
                    $aColortable[$i][0] = $aColortable[$i + 1][0]
                    $aColortable[$i + 1][0] = $aTmp[0]
                    $swapped = 1
                EndIf
            Next
        Until $swapped = 0
    Else
        Do ;bubblesort -> slow!
            $swapped = 0
            For $i = 0 To UBound($aColortable) - 2
                Distance($aColortable[$i], $aColortable[$i + 1])
                If @extended Then
                    $aTmp[0] = $aColortable[$i]
                    $aColortable[$i] = $aColortable[$i + 1]
                    $aColortable[$i + 1] = $aTmp[0]
                    $swapped = 1
                EndIf
            Next
        Until $swapped = 0
    EndIf
EndFunc

Func SortByHSL(ByRef $aColortable, $sc = 1)
    Local $aColortable2[UBound($aColortable)][5]
    Local $a, $i
    For $i = 0 To UBound($aColortable) - 1
        $a = RGB2HSL($aColortable[$i])
        $aColortable2[$i][0] = $aColortable[$i]
        $aColortable2[$i][1] = $a[0]
        $aColortable2[$i][2] = $a[1]
        $aColortable2[$i][3] = $a[2]
        $aColortable2[$i][4] = Sqrt(($a[0] / 360) ^ 2 + $a[1] ^ 2 + $a[2] ^ 2)
    Next
    $sc = Max(Min($sc, 4), 1)
    _ArraySort($aColortable2, 0, 0, 0, $sc)
    For $i = 0 To UBound($aColortable2) - 1
        $aColortable[$i] = $aColortable2[$i][0]
    Next
    Dim $aColortable2[0]
EndFunc

Func SortByHSV(ByRef $aColortable, $sc = 1)
    Local $aColortable2[UBound($aColortable)][4]
    Local $a, $i
    For $i = 0 To UBound($aColortable) - 1
        $a = RGB2HSV($aColortable[$i])
        $aColortable2[$i][0] = $aColortable[$i]
        $aColortable2[$i][1] = $a[0]
        $aColortable2[$i][2] = $a[1]
        $aColortable2[$i][3] = $a[2]
    Next
    $sc = Max(Min($sc, 3), 1)
    _ArraySort($aColortable2, 0, 0, 0, $sc)
    For $i = 0 To UBound($aColortable2) - 1
        $aColortable[$i] = $aColortable2[$i][0]
    Next
    Dim $aColortable2[0]
EndFunc

Func SortByGroupingHSL(ByRef $aColortable, $sc = 2, $sortmode = 2)
    Local $red[0][2], $orange[0][2], $yellow[0][2], $lime[0][2], $green[0][2], $turqoise[0][2], $cyan[0][2], $cobalt[0][2], $blue[0][2], $violet[0][2], $magenta[0][2], $crimson[0][2], $grey[0][2], $i, $j, $col
    $sc = Max(Min($sc, 2), 0)
    For $i = 0 To UBound($aColortable) - 1
        $col = $aColortable[$i]
        Switch RGBtoColorGroup($col)
            Case "red"
                _ArrayAdd($red, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "orange"
                _ArrayAdd($orange, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "yellow"
                _ArrayAdd($yellow, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "lime"
                _ArrayAdd($lime, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "green"
                _ArrayAdd($green, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "turqoise"
                _ArrayAdd($turqoise, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "cyan"
                _ArrayAdd($cyan, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "cobalt"
                _ArrayAdd($cobalt, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "blue"
                _ArrayAdd($blue, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "violet"
                _ArrayAdd($violet, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "magenta"
                _ArrayAdd($magenta, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "crimson"
                _ArrayAdd($crimson, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "grey"
                _ArrayAdd($grey, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
        EndSwitch
    Next
    $sortmode = Max(Min($sortmode, 2), 1)
    Switch $sortmode
        Case 1
            _ArraySort($red, 0, 0, 0, 1)
            _ArraySort($orange, 0, 0, 0, 1)
            _ArraySort($yellow, 0, 0, 0, 1)
            _ArraySort($lime, 0, 0, 0, 1)
            _ArraySort($green, 0, 0, 0, 1)
            _ArraySort($turqoise, 0, 0, 0, 1)
            _ArraySort($cyan, 0, 0, 0, 1)
            _ArraySort($cobalt, 0, 0, 0, 1)
            _ArraySort($blue, 0, 0, 0, 1)
            _ArraySort($violet, 0, 0, 0, 1)
            _ArraySort($magenta, 0, 0, 0, 1)
            _ArraySort($crimson, 0, 0, 0, 1)
            _ArraySort($grey, 0, 0, 0, 1)
        Case 2
            SortByDistance($red)
            SortByDistance($orange)
            SortByDistance($yellow)
            SortByDistance($lime)
            SortByDistance($green)
            SortByDistance($turqoise)
            SortByDistance($cyan)
            SortByDistance($cobalt)
            SortByDistance($blue)
            SortByDistance($violet)
            SortByDistance($magenta)
            SortByDistance($magenta)
            SortByDistance($grey)
    EndSwitch
    $i = 0
    For $j = 0 To UBound($red) - 1
        $aColortable[$i] = $red[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($orange) - 1
        $aColortable[$i] = $orange[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($yellow) - 1
        $aColortable[$i] = $yellow[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($lime) - 1
        $aColortable[$i] = $lime[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($green) - 1
        $aColortable[$i] = $green[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($turqoise) - 1
        $aColortable[$i] = $turqoise[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($cyan) - 1
        $aColortable[$i] = $cyan[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($cobalt) - 1
        $aColortable[$i] = $cobalt[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($blue) - 1
        $aColortable[$i] = $blue[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($violet) - 1
        $aColortable[$i] = $violet[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($magenta) - 1
        $aColortable[$i] = $magenta[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($crimson) - 1
        $aColortable[$i] = $crimson[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($grey) - 1
        $aColortable[$i] = $grey[$j][0]
        $i += 1
    Next
EndFunc

Func SortByGroupingHSV(ByRef $aColortable, $sc = 2, $sortmode = 3)
    Local $red[0][2], $orange[0][2], $yellow[0][2], $lime[0][2], $green[0][2], $turqoise[0][2], $cyan[0][2], $cobalt[0][2], $blue[0][2], $violet[0][2], $magenta[0][2], $crimson[0][2], $grey[0][2], $i, $j, $col
    $sc = Max(Min($sc, 2), 0)
    For $i = 0 To UBound($aColortable) - 1
        $col = $aColortable[$i]
        Switch RGBtoColorGroup($col)
            Case "red"
                _ArrayAdd($red, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "orange"
                _ArrayAdd($orange, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "yellow"
                _ArrayAdd($yellow, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "lime"
                _ArrayAdd($lime, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "green"
                _ArrayAdd($green, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "turqoise"
                _ArrayAdd($turqoise, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "cyan"
                _ArrayAdd($cyan, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "cobalt"
                _ArrayAdd($cobalt, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "blue"
                _ArrayAdd($blue, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "violet"
                _ArrayAdd($violet, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "magenta"
                _ArrayAdd($magenta, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "crimson"
                _ArrayAdd($crimson, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "grey"
                _ArrayAdd($grey, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
        EndSwitch
    Next
    $sortmode = Max(Min($sortmode, 3), 1)
    Switch $sortmode
        Case 1
            _ArraySort($red, 0, 0, 0, 1)
            _ArraySort($orange, 0, 0, 0, 1)
            _ArraySort($yellow, 0, 0, 0, 1)
            _ArraySort($lime, 0, 0, 0, 1)
            _ArraySort($green, 0, 0, 0, 1)
            _ArraySort($turqoise, 0, 0, 0, 1)
            _ArraySort($cyan, 0, 0, 0, 1)
            _ArraySort($cobalt, 0, 0, 0, 1)
            _ArraySort($blue, 0, 0, 0, 1)
            _ArraySort($violet, 0, 0, 0, 1)
            _ArraySort($magenta, 0, 0, 0, 1)
            _ArraySort($crimson, 0, 0, 0, 1)
            _ArraySort($grey, 0, 0, 0, 1)
        Case 2
            SortByDistance($red)
            SortByDistance($orange)
            SortByDistance($yellow)
            SortByDistance($lime)
            SortByDistance($green)
            SortByDistance($turqoise)
            SortByDistance($cyan)
            SortByDistance($cobalt)
            SortByDistance($blue)
            SortByDistance($violet)
            SortByDistance($magenta)
            SortByDistance($magenta)
            SortByDistance($grey)
        Case 3
            SortByLAB($red)
            SortByLAB($orange)
            SortByLAB($yellow)
            SortByLAB($lime)
            SortByLAB($green)
            SortByLAB($turqoise)
            SortByLAB($cyan)
            SortByLAB($cobalt)
            SortByLAB($blue)
            SortByLAB($violet)
            SortByLAB($magenta)
            SortByLAB($magenta)
            SortByLAB($grey)
    EndSwitch
    $i = 0
    For $j = 0 To UBound($red) - 1
        $aColortable[$i] = $red[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($orange) - 1
        $aColortable[$i] = $orange[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($yellow) - 1
        $aColortable[$i] = $yellow[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($lime) - 1
        $aColortable[$i] = $lime[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($green) - 1
        $aColortable[$i] = $green[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($turqoise) - 1
        $aColortable[$i] = $turqoise[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($cyan) - 1
        $aColortable[$i] = $cyan[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($cobalt) - 1
        $aColortable[$i] = $cobalt[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($blue) - 1
        $aColortable[$i] = $blue[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($violet) - 1
        $aColortable[$i] = $violet[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($magenta) - 1
        $aColortable[$i] = $magenta[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($crimson) - 1
        $aColortable[$i] = $crimson[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($grey) - 1
        $aColortable[$i] = $grey[$j][0]
        $i += 1
    Next
EndFunc

Func RGBtoColorGroup($iColor)
    Local $HSL = RGB2HSL($iColor), $H, $r
    If $HSL[0] = 0 And $HSL[1] = 0 Then
        $H = -1
    Else
        $H = $HSL[0]
    EndIf
    Switch $H
        Case 0 To 15, 345 To 360
            Return "red"
        Case 15 To 45
            Return "orange"
        Case 45 To 75
            Return "yellow"
        Case 75 To 105
            Return "lime"
        Case 105 To 135
            Return "green"
        Case 135 To 165
            Return "turqoise"
        Case 165 To 195
            Return "cyan"
        Case 195 To 225
            Return "cobalt"
        Case 225 To 255
            Return "blue"
        Case 255 To 285
            Return "violet"
        Case 285 To 315
            Return "magenta"
        Case 315 To 345
            Return "crimson"
        Case -1
            Return "grey"
    EndSwitch
EndFunc

Func Distance($c1, $c2)
    Local $r1 = BitShift(BitAND($c1, 0xFF0000), 16), $g1 = BitShift(BitAND($c1, 0xFF00), 8), $b1 = BitAND($c1, 0xFF)
    Local $r2 = BitShift(BitAND($c2, 0xFF0000), 16), $g2 = BitShift(BitAND($c2, 0xFF00), 8), $b2 = BitAND($c2, 0xFF)
    Local $dr = $r2 - $r1, $dg = $g2 - $g1, $db =  $b2 - $b1
    Return SetExtended($dr + $dg + $db < 0, Sqrt($dr * $dr + $dg * $dg + $db * $db))
EndFunc

Func RGB2HSL($iColor)
    Local $r = BitAND(BitShift($iColor, 16), 255) / 255, $g = BitAND(BitShift($iColor, 8), 255) / 255, $b = BitAND($iColor, 255) / 255
    Local $Cmax = Max(Max($r, $g), $b), $Cmin = Min(Min($r, $g), $b), $deltaChroma = $Cmax - $Cmin
    Local $L = ($Cmin + $Cmax) / 2, $H, $S
    If $deltaChroma = 0 Then
        $H = 0
        $S = 0
    Else
        $S = $deltaChroma / (1 - Abs(2 * $L - 1))
        Switch $Cmax
            Case $r
                $H = Mod(($g - $b) / $deltaChroma, 6)
            Case $g
                $H = ($b - $r) / $deltaChroma + 2
            Case Else
                $H = ($r - $g) / $deltaChroma + 4
        EndSwitch
        $H *= 60
        If $H < 0 Then $H += 360
    EndIf
    Local $aHSL[3] = [$H, $S, $L]
    Return $aHSL
EndFunc

Func RGB2HSV($iColor)
    Local $r = BitAND(BitShift($iColor, 16), 255) / 255, $g = BitAND(BitShift($iColor, 8), 255) / 255, $b = BitAND($iColor, 255) / 255
    Local $h, $s, $v, $c, $minRGB, $maxRGB, $deltaRGB

    $minRGB = Min3($r, $g, $b)
    $maxRGB = Max3($r, $g, $b)
    $deltaRGB = $maxRGB - $minRGB

    If $deltaRGB = 0 Then
        $h = 0
    ElseIf $maxRGB = $r Then
        $h = 60 * Mod((($g - $b) / $deltaRGB), 6)
    ElseIf $maxRGB = $g Then
        $h = 60 * ((($b - $r) / $deltaRGB) + 2)
    Else
        $h = 60 * ((($r - $g) / $deltaRGB) + 4)
    EndIf

    If $maxRGB = 0 Then
        $s = 0
    Else
        $s = $deltaRGB / $maxRGB
    EndIf

    $v = $maxRGB
    Local $aHSV[3] = [$H, $S, $V]
    Return $aHSV
EndFunc

Func Min($a, $b)
    Return ($a < $b) ? $a : $b
EndFunc

Func Max($a, $b)
    Return ($a > $b) ? $a : $b
EndFunc

Func Min3($a, $b, $c)
    Return Min(Min($a, $b), $C)
EndFunc

Func Max3($a, $b, $c)
    Return Max(Max($a, $b), $C)
EndFunc

Alles anzeigen

Da gibt es noch Hilbert-Sort. Mal sehen, ob das Result anders wird...

**UEZ**

Hi eukalyptus,

lange nichts mehr von dir "gehört".

Danke für LAB Code, sieht sehr homogen aus, nur sind die Farbgruppen relativ fragmentiert.


**UEZ**

Ich habe ein kleines Tool geschrieben, das eine Textdatei einliest (<Name der Farbe;Hex Code>) und sie in einer Listview farbig darstellt. Manchmal suche ich nach einer bestimmten Farbe und wenn die Liste unsortiert ist, dann ist das nicht so optimal, um die Farbe zu finden.

Außerdem ist das ein interessantes Thema .

**UEZ**

Für ein kleines Projekt will ich eine Liste mit Farben in einer Liste darstellen, habe aber gemerkt, dass die Darstellung nicht optimal ist.

Ideal wäre eine Darstellung der Farben so sortiert / gruppiert, dass sie einen idealen Übergang haben.

Was ich bis jetzt implementiert habe:

AutoIt

;Coded by UEZ build 2023-03-14
#include <Array.au3>
#include <GDIPlus.au3>
#include <GUIConstantsEx.au3>
#include <WindowsConstants.au3>
_GDIPlus_Startup()

Global $hGUI = GUICreate("GDI+ Color Sorting / Grouping Test", 800, 300)
GUISetState()
Global $hGraphic = _GDIPlus_GraphicsCreateFromHWND($hGUI)
Global $hPen = _GDIPlus_PenCreate(0)
_GDIPlus_GraphicsClear($hGraphic)


Global $aColortable[511], $i, $y = 0
For $i = 0 To UBound($aColortable) - 1
    $aColortable[$i] = Int(Random() * 0xFFFFFF)
Next

DrawColors($y, "Random")

SortByDistance($aColortable)
$y += 40
DrawColors($y, "Distance")

SortByHSL($aColortable)
$y += 40
DrawColors($y, "HSL")

SortByHSV($aColortable)
$y += 40
DrawColors($y, "HSV")

SortByGroupingHSL($aColortable)
$y += 40
DrawColors($y, "Grouping HSL")

SortByGroupingHSV($aColortable)
$y += 40
DrawColors($y, "Grouping HSV")

_ArraySort($aColortable)
$y += 40
DrawColors($y, "Default Array Sort")

While GUIGetMsg() <> $GUI_EVENT_CLOSE
    Sleep(10)
WEnd

_GDIPlus_PenDispose($hPen)
_GDIPlus_GraphicsDispose($hGraphic)
_GDIPlus_Shutdown()
GUIDelete()
Exit

Func DrawColors($y, $txt = 0)
    For $i = 0 To UBound($aColortable) - 1
        _GDIPlus_PenSetColor($hPen, BitOR(0xFF000000, $aColortable[$i]))
        _GDIPlus_GraphicsDrawLine($hGraphic, $i, $y, $i, $y + 32, $hPen)
    Next
    If $txt Then _GDIPlus_GraphicsDrawString($hGraphic, $txt, $i + 8, $y + 4, "Arial", 16, Default, 0xFFFFFFFF)
EndFunc

Func SortByDistance(ByRef $aColortable)
    Local $i, $aTmp[2], $swapped
    Do ;bubblesort -> slow!
        $swapped = 0
        For $i = 0 To UBound($aColortable) - 2
            Distance($aColortable[$i], $aColortable[$i + 1])
            If @extended Then
                $aTmp[0] = $aColortable[$i]
                $aColortable[$i] = $aColortable[$i + 1]
                $aColortable[$i + 1] = $aTmp[0]
                $swapped = 1
            EndIf
        Next
    Until $swapped = 0
EndFunc

Func SortByHSL(ByRef $aColortable, $sc = 1)
    Local $aColortable2[UBound($aColortable)][4]
    Local $a, $i
    For $i = 0 To UBound($aColortable) - 1
        $a = RGB2HSL($aColortable[$i])
        $aColortable2[$i][0] = $aColortable[$i]
        $aColortable2[$i][1] = $a[0]
        $aColortable2[$i][2] = $a[1]
        $aColortable2[$i][3] = $a[2]
    Next
    $sc = Max(Min($sc, 3), 1)
    _ArraySort($aColortable2, 0, 0, 0, $sc)
    For $i = 0 To UBound($aColortable2) - 1
        $aColortable[$i] = $aColortable2[$i][0]
    Next
    Dim $aColortable2[0]
EndFunc

Func SortByHSV(ByRef $aColortable, $sc = 1)
    Local $aColortable2[UBound($aColortable)][4]
    Local $a, $i
    For $i = 0 To UBound($aColortable) - 1
        $a = RGB2HSV($aColortable[$i])
        $aColortable2[$i][0] = $aColortable[$i]
        $aColortable2[$i][1] = $a[0]
        $aColortable2[$i][2] = $a[1]
        $aColortable2[$i][3] = $a[2]
    Next
    $sc = Max(Min($sc, 3), 1)
    _ArraySort($aColortable2, 0, 0, 0, $sc)
    For $i = 0 To UBound($aColortable2) - 1
        $aColortable[$i] = $aColortable2[$i][0]
    Next
    Dim $aColortable2[0]
EndFunc

Func SortByGroupingHSL(ByRef $aColortable, $sc = 2)
    Local $red[0][2], $orange[0][2], $yellow[0][2], $lime[0][2], $green[0][2], $turqoise[0][2], $cyan[0][2], $cobalt[0][2], $blue[0][2], $violet[0][2], $magenta[0][2], $crimson[0][2], $grey[0][2], $i, $j, $col
    $sc = Max(Min($sc, 2), 0)
    For $i = 0 To UBound($aColortable) - 1
        $col = $aColortable[$i]
        Switch RGBtoColorGroup($col)
            Case "red"
                _ArrayAdd($red, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "orange"
                _ArrayAdd($orange, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "yellow"
                _ArrayAdd($yellow, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "lime"
                _ArrayAdd($lime, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "green"
                _ArrayAdd($green, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "turqoise"
                _ArrayAdd($turqoise, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "cyan"
                _ArrayAdd($cyan, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "cobalt"
                _ArrayAdd($cobalt, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "blue"
                _ArrayAdd($blue, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "violet"
                _ArrayAdd($violet, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "magenta"
                _ArrayAdd($magenta, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "crimson"
                _ArrayAdd($crimson, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
            Case "grey"
                _ArrayAdd($grey, $aColortable[$i] & "|" & RGB2HSL($col)[$sc])
        EndSwitch
    Next
    _ArraySort($red, 0, 0, 0, 1)
    _ArraySort($orange, 0, 0, 0, 1)
    _ArraySort($yellow, 0, 0, 0, 1)
    _ArraySort($lime, 0, 0, 0, 1)
    _ArraySort($green, 0, 0, 0, 1)
    _ArraySort($turqoise, 0, 0, 0, 1)
    _ArraySort($cyan, 0, 0, 0, 1)
    _ArraySort($cobalt, 0, 0, 0, 1)
    _ArraySort($blue, 0, 0, 0, 1)
    _ArraySort($violet, 0, 0, 0, 1)
    _ArraySort($magenta, 0, 0, 0, 1)
    _ArraySort($crimson, 0, 0, 0, 1)
    _ArraySort($grey, 0, 0, 0, 1)
    $i = 0
    For $j = 0 To UBound($red) - 1
        $aColortable[$i] = $red[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($orange) - 1
        $aColortable[$i] = $orange[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($yellow) - 1
        $aColortable[$i] = $yellow[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($lime) - 1
        $aColortable[$i] = $lime[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($green) - 1
        $aColortable[$i] = $green[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($turqoise) - 1
        $aColortable[$i] = $turqoise[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($cyan) - 1
        $aColortable[$i] = $cyan[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($cobalt) - 1
        $aColortable[$i] = $cobalt[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($blue) - 1
        $aColortable[$i] = $blue[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($violet) - 1
        $aColortable[$i] = $violet[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($magenta) - 1
        $aColortable[$i] = $magenta[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($crimson) - 1
        $aColortable[$i] = $crimson[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($grey) - 1
        $aColortable[$i] = $grey[$j][0]
        $i += 1
    Next
EndFunc

Func SortByGroupingHSV(ByRef $aColortable, $sc = 2)
    Local $red[0][2], $orange[0][2], $yellow[0][2], $lime[0][2], $green[0][2], $turqoise[0][2], $cyan[0][2], $cobalt[0][2], $blue[0][2], $violet[0][2], $magenta[0][2], $crimson[0][2], $grey[0][2], $i, $j, $col
    $sc = Max(Min($sc, 2), 0)
    For $i = 0 To UBound($aColortable) - 1
        $col = $aColortable[$i]
        Switch RGBtoColorGroup($col)
            Case "red"
                _ArrayAdd($red, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "orange"
                _ArrayAdd($orange, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "yellow"
                _ArrayAdd($yellow, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "lime"
                _ArrayAdd($lime, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "green"
                _ArrayAdd($green, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "turqoise"
                _ArrayAdd($turqoise, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "cyan"
                _ArrayAdd($cyan, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "cobalt"
                _ArrayAdd($cobalt, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "blue"
                _ArrayAdd($blue, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "violet"
                _ArrayAdd($violet, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "magenta"
                _ArrayAdd($magenta, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "crimson"
                _ArrayAdd($crimson, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
            Case "grey"
                _ArrayAdd($grey, $aColortable[$i] & "|" & RGB2HSV($col)[$sc])
        EndSwitch
    Next
    _ArraySort($red, 0, 0, 0, 1)
    _ArraySort($orange, 0, 0, 0, 1)
    _ArraySort($yellow, 0, 0, 0, 1)
    _ArraySort($lime, 0, 0, 0, 1)
    _ArraySort($green, 0, 0, 0, 1)
    _ArraySort($turqoise, 0, 0, 0, 1)
    _ArraySort($cyan, 0, 0, 0, 1)
    _ArraySort($cobalt, 0, 0, 0, 1)
    _ArraySort($blue, 0, 0, 0, 1)
    _ArraySort($violet, 0, 0, 0, 1)
    _ArraySort($magenta, 0, 0, 0, 1)
    _ArraySort($crimson, 0, 0, 0, 1)
    _ArraySort($grey, 0, 0, 0, 1)
    $i = 0
    For $j = 0 To UBound($red) - 1
        $aColortable[$i] = $red[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($orange) - 1
        $aColortable[$i] = $orange[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($yellow) - 1
        $aColortable[$i] = $yellow[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($lime) - 1
        $aColortable[$i] = $lime[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($green) - 1
        $aColortable[$i] = $green[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($turqoise) - 1
        $aColortable[$i] = $turqoise[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($cyan) - 1
        $aColortable[$i] = $cyan[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($cobalt) - 1
        $aColortable[$i] = $cobalt[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($blue) - 1
        $aColortable[$i] = $blue[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($violet) - 1
        $aColortable[$i] = $violet[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($magenta) - 1
        $aColortable[$i] = $magenta[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($crimson) - 1
        $aColortable[$i] = $crimson[$j][0]
        $i += 1
    Next
    For $j = 0 To UBound($grey) - 1
        $aColortable[$i] = $grey[$j][0]
        $i += 1
    Next
EndFunc

Func RGBtoColorGroup($iColor)
    Local $HSL = RGB2HSL($iColor), $H, $r
    If $HSL[0] = 0 And $HSL[1] = 0 Then
        $H = -1
    Else
        $H = $HSL[0]
    EndIf
    Switch $H
        Case 0 To 15, 345 To 360
            Return "red"
        Case 15 To 45
            Return "orange"
        Case 45 To 75
            Return "yellow"
        Case 75 To 105
            Return "lime"
        Case 105 To 135
            Return "green"
        Case 135 To 165
            Return "turqoise"
        Case 165 To 195
            Return "cyan"
        Case 195 To 225
            Return "cobalt"
        Case 225 To 255
            Return "blue"
        Case 255 To 285
            Return "violet"
        Case 285 To 315
            Return "magenta"
        Case 315 To 345
            Return "crimson"
        Case -1
            Return "grey"
    EndSwitch
EndFunc

Func Distance($c1, $c2)
    Local $r1 = BitShift(BitAND($c1, 0xFF0000), 16), $g1 = BitShift(BitAND($c1, 0xFF00), 8), $b1 = BitAND($c1, 0xFF)
    Local $r2 = BitShift(BitAND($c2, 0xFF0000), 16), $g2 = BitShift(BitAND($c2, 0xFF00), 8), $b2 = BitAND($c2, 0xFF)
    Local $dr = $r2 - $r1, $dg = $g2 - $g1, $db =  $b2 - $b1
    Return SetExtended($dr + $dg + $db < 0, Sqrt($dr * $dr + $dg * $dg + $db * $db))
EndFunc

Func RGB2HSL($iColor)
    Local $r = BitAND(BitShift($iColor, 16), 255) / 255, $g = BitAND(BitShift($iColor, 8), 255) / 255, $b = BitAND($iColor, 255) / 255
    Local $Cmax = Max(Max($r, $g), $b), $Cmin = Min(Min($r, $g), $b), $deltaChroma = $Cmax - $Cmin
    Local $L = ($Cmin + $Cmax) / 2, $H, $S
    If $deltaChroma = 0 Then
        $H = 0
        $S = 0
    Else
        $S = $deltaChroma / (1 - Abs(2 * $L - 1))
        Switch $Cmax
            Case $r
                $H = Mod(($g - $b) / $deltaChroma, 6)
            Case $g
                $H = ($b - $r) / $deltaChroma + 2
            Case Else
                $H = ($r - $g) / $deltaChroma + 4
        EndSwitch
        $H *= 60
        If $H < 0 Then $H += 360
    EndIf
    Local $aHSL[3] = [$H, $S, $L]
    Return $aHSL
EndFunc

Func RGB2HSV($iColor)
    Local $r = BitAND(BitShift($iColor, 16), 255) / 255, $g = BitAND(BitShift($iColor, 8), 255) / 255, $b = BitAND($iColor, 255) / 255
    Local $h, $s, $v, $c, $minRGB, $maxRGB, $deltaRGB

    $minRGB = Min3($r, $g, $b)
    $maxRGB = Max3($r, $g, $b)
    $deltaRGB = $maxRGB - $minRGB

    If $deltaRGB = 0 Then
        $h = 0
    ElseIf $maxRGB = $r Then
        $h = 60 * Mod((($g - $b) / $deltaRGB), 6)
    ElseIf $maxRGB = $g Then
        $h = 60 * ((($b - $r) / $deltaRGB) + 2)
    Else
        $h = 60 * ((($r - $g) / $deltaRGB) + 4)
    EndIf

    If $maxRGB = 0 Then
        $s = 0
    Else
        $s = $deltaRGB / $maxRGB
    EndIf

    $v = $maxRGB
    Local $aHSV[3] = [$H, $S, $V]
    Return $aHSV
EndFunc

Func Min($a, $b)
    Return ($a < $b) ? $a : $b
EndFunc

Func Max($a, $b)
    Return ($a > $b) ? $a : $b
EndFunc

Func Min3($a, $b, $c)
    Return Min(Min($a, $b), $C)
EndFunc

Func Max3($a, $b, $c)
    Return Max(Max($a, $b), $C)
EndFunc

Alles anzeigen


Die Ergebnisse sehen ganz passable aus, aber noch nicht gut genug, da man immer noch Farbfragmente innerhalb der Farbbereiche sieht.

Habt ihr noch Ideen?

Beiträge von UEZ

Basic Image Editor als Erweiterung für ein Screenshot Tool

Basic Image Editor als Erweiterung für ein Screenshot Tool

Basic Image Editor als Erweiterung für ein Screenshot Tool

MsgBox hooken und Countdown hinzufügen

MsgBox hooken und Countdown hinzufügen

MsgBox hooken und Countdown hinzufügen

MsgBox hooken und Countdown hinzufügen

MsgBox hooken und Countdown hinzufügen

MsgBox hooken und Countdown hinzufügen

Farben Sortieren / Gruppieren

Screenshot - Bereich per Maus auswählen

Screenshot - Bereich per Maus auswählen

Farben Sortieren / Gruppieren

Farben Sortieren / Gruppieren

Farben Sortieren / Gruppieren

Farben Sortieren / Gruppieren

Farben Sortieren / Gruppieren

Farben Sortieren / Gruppieren

Farben Sortieren / Gruppieren

Farben Sortieren / Gruppieren
