Hi Community,
ich habe das Script CaptureScreen sowie die verbesserte Funktion _ScreenCapture_CaptureWndV2 ausprobiert. Vor einiger Zeit hat es auch kurz funktioniert, später dann garnicht mehr.
Problem: Nicht das Spiel wird gecaptured sondern die Desktop Oberfläche mit den Koordinaten des Spiels (wenn die Auflösung z.B. sehr niedrig ist, wird auch nur der Teil vom Dekstop genommen).
Eigentlich sollte die Funktion alles was von der Grafikkarte "gemalt" wird capturen.
Funktion:
[autoit]; #FUNCTION# ====================================================================================================================
; Name...........: _ScreenCapture_CaptureWndV2
; Description ...: Captures a screen shot of a specified window. This function is an alternative to '_ScreenCapture_CaptureWnd'.
; It is able to take screenshots of layered windows (drawn by the graphic card). See 'remarks' below.
; Syntax.........: _ScreenCapture_CaptureWndV2($sFileName, $hWnd[, $iLeft = 0[, $iTop = 0[, $iRight = -1[, $iBottom = -1[, $fCursor = True]]]]])
; Parameters ....: $sFileName - Full path and extension of the image file
; $hWnd - Handle to the window to be captured
; $iLeft - X coordinate of the upper left corner of the client rectangle
; $iTop - Y coordinate of the upper left corner of the client rectangle
; $iRight - X coordinate of the lower right corner of the rectangle
; $iBottom - Y coordinate of the lower right corner of the rectangle
; $fCursor - If True the cursor will be captured with the image
; Return values .: See remarks
; Remarks .......: 1/ If FileName is not blank this function will capture the screen and save it to file. If FileName is blank, this
; function will capture the screen and return a HBITMAP handle to the bitmap image. In this case, after you are
; finished with the bitmap you must call _WinAPI_DeleteObject to delete the bitmap handle. All coordinates are in
; client coordinate mode.
;
; 2.1/ Layered windows do not appear on screenshots taken by '_ScreenCapture_Capture' because it uses the desktop's
; handle whereas the layered windows are drawn directly by the graphic card. 2.2/ '_ScreenCapture_CaptureWnd'
; is a wrapper of '_ScreenCapture_Capture' and, therefore, has the same limitations. 2.3/ Instead,
; '_ScreenCapture_CaptureWndV2', THIS FUNCTION, is using the handle of the targetted window to perfom its task
; (in a similar way than '_ScreenCapture_Capture'uses the Desktop's handle).
;
; Author ........: Patryk Szczepankiewicz (pszczepa at gmail dot com)
; History .......: JAN 21, 2009 - Created
; OCT 18, 2010 - First release on the AutoIT forum
; OCT 28, 2010 - Cleaned the border code and fixed the capture of the cursor.
; APR 06, 2011 - Updated for AutoIT 3.3.6.1
; Related .......: _WinAPI_DeleteObject
; Link ..........; http://www.autoitscript.com/forum/index.php?showtopic=65008
; Example .......; No
; Credits .......: Based on Paul Campbell's '_ScreenCapture_Capture' function and inspired by Jennico's '_WinGetBorderSize'.
; ===============================================================================================================================
Func _ScreenCapture_CaptureWndV2($sFileName, $hWnd, $iLeft = 0, $iTop = 0, $iRight = -1, $iBottom = -1, $fCursor = True)
Local $tRect
Local $iWndX, $iWndY, $iWndW, $iWndH
Local $tClient
Local $iBorderV, $iBorderT
Local $iPicHeight, $iPicWidth
Local $iPicCursorX, $iPicCursorY
Local $hDDC, $hCDC, $hBMP, $aCursor, $aIcon, $hIcon
[/autoit][autoit][/autoit][autoit]; Get the absolute coordinates of the window
$tRect = _WinAPI_GetWindowRect($hWnd)
; Get useful variables
$iWndX = DllStructGetData($tRect, "Left")
$iWndY = DllStructGetData($tRect, "Top")
$iWndW = DllStructGetData($tRect, "Right")
$iWndH = DllStructGetData($tRect, "Bottom")
; Assign automatic values: the right and bottom are computed as
; the width and height of the absolute coordinates of the window.
If $iRight = -1 Then $iRight = $iWndW - $iWndX
If $iBottom = -1 Then $iBottom = $iWndH - $iWndY
; Check user values: check that caller is not putting the top-left
; corner out of the window.
If $iLeft > $iWndW Then $iLeft = $iWndX
If $iTop > $iWndH Then $iTop = $iWndY
; Check user values: check that caller is not asking for a
; screenshot bigger than the window itelf.
If $iRight > $iWndW Then $iRight = $iWndW
If $iBottom > $iWndH Then $iBottom = $iWndH
; Compute the size of the final picture.
$iPicWidth = $iRight - $iLeft
$iPicHeight = $iBottom - $iTop
; Compute the borders sizes
$tClient = _WinAPI_GetClientRect($hWnd)
$iBorderV = (($iWndW - $iWndX) - DllStructGetData($tClient, "Right")) / 2
$iBorderT = ($iWndH - $iWndY) - DllStructGetData($tClient, "Bottom") - $iBorderV
; Transfert color data
$hDDC = _WinAPI_GetDC($hWnd)
$hCDC = _WinAPI_CreateCompatibleDC($hDDC)
$hBMP = _WinAPI_CreateCompatibleBitmap($hDDC, $iPicWidth, $iPicHeight)
_WinAPI_SelectObject($hCDC, $hBMP)
_WinAPI_BitBlt($hCDC, 0, 0, $iPicWidth, $iPicHeight, $hDDC, $iLeft-$iBorderV, $iTop-$iBorderT, $SRCCOPY)
; Add the cursor on the screenshot
If $fCursor Then
$aCursor = _WinAPI_GetCursorInfo()
If $aCursor[1] Then
$hIcon = _WinAPI_CopyIcon($aCursor[2])
$aIcon = _WinAPI_GetIconInfo($hIcon)
$iPicCursorX = $aCursor[3] - $aIcon[2] - $iWndX - $iLeft
$iPicCursorY = $aCursor[4] - $aIcon[3] - $iWndY - $iTop
_WinAPI_DrawIcon($hCDC, $iPicCursorX, $iPicCursorY, $hIcon)
EndIf
EndIf
; Clean and save data
_WinAPI_ReleaseDC($hWnd, $hDDC)
_WinAPI_DeleteDC($hCDC)
If $sFileName = "" Then Return $hBMP
_ScreenCapture_SaveImage($sFileName, $hBMP)
EndFunc
[/autoit]Jemand eine Idee wie es funktionieren könnte?
Danke und MfG
Flo
