Beiträge von tobi_girst

[autoit]

#include <StructureConstants.au3>
#include <GUIConstants.au3>

[/autoit] [autoit][/autoit] [autoit]

$GUI = GUICreate("Windows Vista DWM", 243, 243)
$Apply = GUICtrlCreateButton("Apply", 80, 104, 83, 25, 0)
GUISetState(@SW_SHOW)

[/autoit] [autoit][/autoit] [autoit]

While 1
$iMsg = GUIGetMsg()
Switch $iMsg
Case $GUI_EVENT_CLOSE
Exit
Case $Apply
$Ret = ApplyGlass($GUI,243,243,243,243,0x000000); produces full glass window, the glass is red colored
EndSwitch
WEnd

[/autoit] [autoit][/autoit] [autoit]

Func ApplyGlass($hWnd,$leftw,$rightw,$toph,$bottomh,$glasscolor = "0x000000")
$struct=DllStructCreate("int cxLeftWidth;int cxRightWidth;int cyTopHeight;int cyBottomHeight;")
DllStructSetData($struct,"cxLeftWidth",$leftw)
DllStructSetData($struct,"cxRightWidth",$rightw)
DllStructSetData($struct,"cyTopHeight",$toph)
DllStructSetData($struct,"cyBottomHeight",$bottomh)
GUISetBkColor($glasscolor)
Return DllCall("dwmapi.dll", "int", "DwmExtendFrameIntoClientArea", "hwnd", $hWnd, "ptr", DllStructGetPtr($struct))
EndFunc

[/autoit]

http://www.autoitscript.com/forum/topic/13…-menu-estetics/

[autoit]

#region parts that are not my work:
;JamesBrooks for Vista glass functions: http://www.autoitscript.com/forum/topic/..…ions/page__hl__
;Authenticity and Yashied for glow txt on glass: http://www.autoitscript.com/forum/topic/..…owing-text-on-a
;Malkey for GDI+ gradient: http://www.autoitscript.com/forum/topic/75…ent-line-brush/
#endregion

[/autoit] [autoit][/autoit] [autoit]

#include <FontConstants.au3>
#include <WindowsConstants.au3>
#include <GuiConstantsEx.au3>
#include <GDIPlus.au3>

[/autoit] [autoit][/autoit] [autoit]

OnAutoItExitRegister( "_CleanUp" )

[/autoit] [autoit][/autoit] [autoit]

Global $IconSize = 48
Global $width = 300
Global $height = 350
Global $shine1 = 5
Global $shine2 = 5
Global $shine3 = 125
Global $menuFontSize = 16
Global $title = 'Some cool menu'
Global $temp_image = @TempDir & '\my_seven_image.bmp'
Global $Win_Back_Color = 0x636363;0xC5C5C5;454545 <--- color of lower dark grey line
For $i = 1 to Int($IconSize/4.8) ;adding space in front of the title so that it doesn't overlap top left image
$title = ' ' & $title
Next

[/autoit] [autoit][/autoit] [autoit]

#region values requires for text shine on glass area
Global Const $DTT_TEXTCOLOR = 0x00000001
Global Const $DTT_GLOWSIZE = 0x00000800
Global Const $DTT_COMPOSITED = 0x00002000
If Not IsDeclared("tagDTTOPTS") Then Global Const $tagDTTOPTS = _
"uint Size;uint Flags;uint clrText;uint clrBorder;uint clrShadow;int TextShadowType;" & $tagPOINT & _
";int BorderSize;int FontPropId;int ColorPropId;int StateId;int ApplyOverlay;int GlowSize;ptr DrawTextCallback;int lParam;"
Global $Struct = DllStructCreate("int cxLeftWidth;int cxRightWidth;int cyTopHeight;int cyBottomHeight;")
Global $sStruct = DllStructCreate("dword;int;ptr;int")
Global $Area[4] = [0, 0, $IconSize-23, 0]
#endregion

[/autoit] [autoit][/autoit] [autoit]

Global $Form1 = GUICreate($title, $width, $height, -1, -1, -1, -1)
Global $GlassArea = GUICtrlCreateLabel("", 0, 0, $width, $IconSize-23) ;area that will be filled with glass
GUICtrlSetBkColor(-1, 0x000000)
Global $DarkGreyArea = GUICtrlCreateGraphic(0, 0, $width, $height-45) ;work area (to add controls in)
GUICtrlSetBkColor(-1, 0xC5C5C5) ;with light grey area
Global $CloseButton = GUICtrlCreateButton("Close", $width-90, $height-35, 80, 25)
Global $hTheme = _WinAPI_OpenThemeData($Form1, "globals") ;required function for label shine in glass area
If (@OSVersion <> "WIN_VISTA") OR (@OSVersion <> "WIN_7") Then _Vista_ApplyGlassArea($Form1, $Area, $Win_Back_Color) ;applying glass area to main GUI (area where $GlassArea label is)

[/autoit] [autoit][/autoit] [autoit]

GUISetState(@SW_SHOW, $Form1)

[/autoit] [autoit][/autoit] [autoit]

;creating child GUI with top left image-menu-control
Global $iX = 0, $iY = 0, $iWidth = $IconSize, $iHeight = $IconSize
Global $controlGui, $HoverImage, $Mask, $FileGUI, $FileMenu, $EditGUI, $EditMenu, $HelpGUI, $HelpMenu, $DownGUI, $DownMenu

[/autoit] [autoit][/autoit] [autoit]

#region create fake GUIs with each holding a clickable control
$ImageState = 1
_CreateFakeGUI($controlGui, 'ControlGUI', 48, 48, -1, -23, 1, $HoverImage)
$FileState = 1
_CreateFakeGUI($FileGUI, 'FileGUI', 35, $menuFontSize*2-Round($menuFontSize/1.5), 52, 4, 2, $FileMenu)
$EditState = 1
_CreateFakeGUI($EditGUI, 'EditGUI', 35, $menuFontSize*2-Round($menuFontSize/1.5), 92, 4, 2, $EditMenu)
$HelpState = 1
_CreateFakeGUI($HelpGUI, 'HelpGUI', 45, $menuFontSize*2-Round($menuFontSize/1.5), 130, 4, 2, $HelpMenu)
$DownState = 1
_CreateFakeGUI($DownGUI, 'DownGUI', 20, $menuFontSize*2-Round($menuFontSize/1.5), $width-18, 4, 2, $DownMenu)
#endregion

[/autoit] [autoit][/autoit] [autoit]

#region create context menus
;----------Image Menu------------------------
$ImageDummy = GUICtrlCreateDummy()
$ImageContext = GUICtrlCreateContextMenu($ImageDummy)
$ImMinimize = GUICtrlCreateMenuItem("Minimize", $ImageContext)
$ImMaximize = GUICtrlCreateMenuItem("Maximize", $ImageContext)
GUICtrlSetState(-1, $GUI_DISABLE)
GUICtrlCreateMenuItem("", $ImageContext)
$imExit = GUICtrlCreateMenuItem("Exit", $ImageContext)
;----------File Menu------------------------
$FileDummy = GUICtrlCreateDummy()
$FileContext = GUICtrlCreateContextMenu($FileDummy)
$FileNew = GUICtrlCreateMenu("New", $FileContext)
$FileNewProject = GUICtrlCreateMenuItem("Project", $FileNew)
$FileNewFile = GUICtrlCreateMenuItem("File", $FileNew)
$FileOpen = GUICtrlCreateMenuItem("Open", $FileContext)
$FileSave = GUICtrlCreateMenuItem("Save", $FileContext)
$FileSaveAs = guictrlcreatemenuitem("Save As...", $FileContext)
GUICtrlCreateMenuItem("", $FileContext)
$FileExit = guictrlcreatemenuitem("Exit", $FileContext)
;----------Edit Menu------------------------
$EditDummy = GUICtrlCreateDummy()
$EditContext = GUICtrlCreateContextMenu($EditDummy)
$EditUndo = GUICtrlCreateMenuItem("Undo", $EditContext)
$EditRedo = GUICtrlCreateMenuItem("Redo", $EditContext)
GUICtrlCreateMenuItem("", $EditContext)
$EditCut = GUICtrlCreateMenuItem("Cut", $EditContext)
$EditCopy = GUICtrlCreateMenuItem("Copy", $EditContext)
$EditPaste = GUICtrlCreateMenuItem("Paste", $EditContext)
GUICtrlCreateMenuItem("", $EditContext)
$EditPref = GUICtrlCreateMenuItem("Preferences", $EditContext)
;----------Help Menu------------------------
$HelpDummy = GUICtrlCreateDummy()
$HelpContext = GUICtrlCreateContextMenu($HelpDummy)
$HelpHelp = GUICtrlCreateMenuItem("Help", $HelpContext)
GUICtrlCreateMenuItem("", $HelpContext)
$HelpAbout = GUICtrlCreateMenuItem("About", $HelpContext)
;----------Down arrow Menu------------------------
$DownDummy = GUICtrlCreateDummy()
$DownContext = GUICtrlCreateContextMenu($DownDummy)
$DownTab = GUICtrlCreateMenuItem("Tab Groups", $DownContext)
$DownTabOther = GUICtrlCreateMenuItem("Tabs from other computers", $DownContext)
GUICtrlCreateMenuItem("", $DownContext)
$DownTabExample = GUICtrlCreateMenuItem("Example tab", $DownContext)
#endregion

[/autoit] [autoit][/autoit] [autoit]

_Draw_menus() ;drawing all menu items

[/autoit] [autoit][/autoit] [autoit]

Global $Mask = GUICreate('Mask', $iWidth-2, $iHeight-2, 0, -22, $WS_POPUP, $WS_EX_MDICHILD, $Form1) ;another child window for shade and gloss when moving mouse over image-menu or clicking it
GUISetBkColor(0xFFFFFF, $Mask)
WinSetTrans($Mask, '', 40)
GUISetState(@SW_DISABLE, $Mask) ;still not shown, only disabled

[/autoit] [autoit][/autoit] [autoit]

GUIRegisterMsg(0xF,"MY_PAINT")

[/autoit] [autoit][/autoit] [autoit]

While 1
$iMsg = GUIGetMsg()
Switch $iMsg
Case $HelpAbout
MsgBox(48, 'About', 'Cool menus by... sandin' & @CRLF & @CRLF & '07.07.2011', -1, $Form1)
Case $ImMinimize
WinSetState($Form1, '', @SW_MINIMIZE)
Case $GUI_EVENT_CLOSE, $imExit, $CloseButton, $FileExit
Exit
Case $GlassArea ;moving window when holding glass area that isn't menu
dllcall("user32.dll","int","SendMessage","hWnd", $Form1,"int",0xA1,"int", 2,"int", 0)
EndSwitch
#region detection clicks and hovering above menu items
If WinActive($Form1) then ;<-- here's one problem, I need this in order for window not to detect any clicks if you click on another window that is above this one
;but then you can't click on any control even if the window is aside your currently active window.
_MenuBehavior($FileGUI, $FileMenu, $FileState, 'File', $FileContext)
_MenuBehavior($EditGUI, $EditMenu, $EditState, 'Edit', $EditContext)
_MenuBehavior($HelpGUI, $HelpMenu, $HelpState, 'Help', $HelpContext)
_MenuBehavior($DownGUI, $DownMenu, $DownState, ChrW(9660), $DownContext)
_MenuBehavior($controlGui, $HoverImage, $ImageState, '', $ImageContext)
EndIf
#endregion
WEnd

[/autoit] [autoit][/autoit] [autoit]

Func _MenuBehavior($WinHWND, $i_MenuItem, ByRef $i_MenuState, $i_Label, $i_ContextMenu);, $i_Shine1, $i_Shine2, $i_Shine3, $i_Color1, $i_Color2)
Local $a = GUIGetCursorInfo($WinHWND)
Switch $a[4]
Case $i_MenuItem
If $a[2] = 1 Then
If $i_MenuState <> 3 Then
$i_MenuState = 3
if ($FileState <> 1) AND ($FileMenu <> $i_MenuItem) then
$FileState = 1
_Draw_Menu_ex($FileGUI, 'File', $menuFontSize, $shine3, 0x000000)
EndIf
if ($EditState <> 1) AND ($EditMenu <> $i_MenuItem) then ;making sure that disable all other menu clicked state (if there are any)
$EditState = 1
_Draw_Menu_ex($EditGUI, 'Edit', $menuFontSize, $shine3, 0x000000)
EndIf
if ($HelpState <> 1) AND ($HelpMenu <> $i_MenuItem) Then
$HelpState = 1
_Draw_Menu_ex($HelpGUI, 'Help', $menuFontSize, $shine3, 0x000000)
EndIf
if ($DownState <> 1) AND ($DownMenu <> $i_MenuItem) Then
$DownState = 1
_Draw_Menu_ex($DownGUI, ChrW(9660), $menuFontSize-Round(Sqrt($menuFontSize)), $shine3, 0x555555)
EndIf
if ($ImageState <> 1) AND ($HoverImage <> $i_MenuItem) Then
$ImageState = 1
GUISetState(@SW_HIDE, $Mask)
EndIf
If $i_MenuItem = $DownMenu then
_Draw_Menu_ex($WinHWND, ChrW(9660), $menuFontSize-Round(Sqrt($menuFontSize)), $shine2+2, 0x000099)
ElseIf $i_MenuItem = $HoverImage Then
GUISetBkColor(0x000000, $Mask)
GUISetState(@SW_SHOWNOACTIVATE, $Mask)
Else
_Draw_Menu_ex($WinHWND, $i_Label, $menuFontSize, $shine1, 0x000099) ;clicked File menu state, drawing average glow, and red color
EndIf
ShowMenu($WinHWND, $i_MenuItem, $i_ContextMenu) ;showing context menu for File
EndIf
Else
If $i_MenuState <> 2 Then
$i_MenuState = 2
If $i_MenuItem = $DownMenu Then
_Draw_Menu_ex($WinHWND, '| ' & ChrW(9660) & ' |', $menuFontSize-Round(Sqrt($menuFontSize)), $shine2, 0x555555)
ElseIf $i_MenuItem = $HoverImage Then
GUISetBkColor(0xFFFFFF, $Mask)
GUISetState(@SW_SHOWNOACTIVATE, $Mask)
Else
_Draw_Menu_ex($WinHWND, $i_Label, $menuFontSize, $shine2, 0x000000) ;high glow, black color
EndIf
EndIf
EndIf
Case Else
If $i_MenuState <> 1 Then
$i_MenuState = 1
If $i_MenuItem = $DownMenu Then
_Draw_Menu_ex($WinHWND, ChrW(9660), $menuFontSize-Round(Sqrt($menuFontSize)), $shine3, 0x555555)
ElseIf $i_MenuItem = $HoverImage Then
GUISetState(@SW_HIDE, $Mask)
Else
_Draw_Menu_ex($WinHWND, $i_Label, $menuFontSize, $shine3, 0x000000) ;spread glow so there aren't any, black color
EndIf
EndIf
EndSwitch
EndFunc

[/autoit] [autoit][/autoit] [autoit]

Func _CreateFakeGUI(ByRef $WinHWND, $WinTitle, $WinWIdth, $WinHeight, $Win_X, $Win_Y, $AddCtrl, ByRef $CtrlHWND);, $LabelSize = 35)
$WinHWND = GUICreate($WinTitle, $WinWIdth, $WinHeight, $Win_X, $Win_Y, $WS_POPUP, $WS_EX_MDICHILD, $Form1)
If $AddCtrl = 1 then
$CtrlHWND = GUICtrlCreatePic('', 0, 0, $iWidth, $iHeight) ;control to put image later on
ElseIf $AddCtrl = 2 Then
$CtrlHWND = GUICtrlCreateLabel('', 0, 0, $WinWIdth, $menuFontSize*2-Round($menuFontSize/1.5)) ;clickable area
GUICtrlSetBkColor(-1, 0x000000)
If (@OSVersion <> "WIN_VISTA") OR (@OSVersion <> "WIN_7") Then _Vista_ApplyGlass($WinHWND, $Win_Back_Color) ;apply glass on entire child window
EndIf
GUISetState(@SW_DISABLE, $WinHWND) ;disabling window so that it doesn't take focus from parent when you click on it
GUISetState(@SW_SHOWNOACTIVATE, $WinHWND) ;show and doesn't focus
If $AddCtrl = 1 Then
_Create_7Image() ;creating image with 7 number on it (like win7)
GUICtrlSetImage($CtrlHWND, $temp_image) ;setting image into control we created earlier.
;Why did I use this method and not redrew image 7 in MY_PAINT? because it would be very slow, this method is faster.
EndIf
EndFunc

[/autoit] [autoit][/autoit] [autoit]

Func ShowMenu($hWnd, $CtrlID, $nContextID)
Local $timez = TimerInit()
Local $arPos, $x, $y
Local $hMenu = GUICtrlGetHandle($nContextID)

[/autoit] [autoit][/autoit] [autoit]

$arPos = ControlGetPos($hWnd, "", $CtrlID)

[/autoit] [autoit][/autoit] [autoit]

$x = $arPos[0]
$y = $arPos[1] + $arPos[3]

[/autoit] [autoit][/autoit] [autoit]

ClientToScreen($hWnd, $x, $y)
TrackPopupMenu($hWnd, $hMenu, $x, $y)

[/autoit] [autoit][/autoit] [autoit]

EndFunc ;==>ShowMenu

[/autoit] [autoit][/autoit] [autoit]

Func ClientToScreen($hWnd, ByRef $x, ByRef $y)
Local $stPoint = DllStructCreate("int;int")

[/autoit] [autoit][/autoit] [autoit]

DllStructSetData($stPoint, 1, $x)
DllStructSetData($stPoint, 2, $y)

[/autoit] [autoit][/autoit] [autoit]

DllCall("user32.dll", "int", "ClientToScreen", "hwnd", $hWnd, "ptr", DllStructGetPtr($stPoint))

[/autoit] [autoit][/autoit] [autoit]

$x = DllStructGetData($stPoint, 1)
$y = DllStructGetData($stPoint, 2)
$stPoint = 0
EndFunc ;==>ClientToScreen

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

Func TrackPopupMenu($hWnd, $hMenu, $x, $y)
DllCall("user32.dll", "int", "TrackPopupMenuEx", "hwnd", $hMenu, "int", 0, "int", $x, "int", $y, "hwnd", $hWnd, "ptr", 0)
EndFunc ;==>TrackPopupMenu

[/autoit] [autoit][/autoit] [autoit]

#region glass functions for aero graphic environment (link at the top of the script)
Func _Vista_ApplyGlass($hWnd, $bColor = 0x000000)
GUISetBkColor($bColor)
$Ret = DllCall("dwmapi.dll", "long", "DwmExtendFrameIntoClientArea", "hwnd", $hWnd, "long*", DllStructGetPtr($Struct))
If @error Then
Return 0
SetError(1)
Else
Return $Ret
EndIf
EndFunc ;==>_Vista_ApplyGlass

[/autoit] [autoit][/autoit] [autoit]

Func _Vista_ApplyGlassArea($hWnd, $Area, $bColor = 0x000000)
If IsArray($Area) Then
DllStructSetData($Struct, "cxLeftWidth", $Area[0])
DllStructSetData($Struct, "cxRightWidth", $Area[1])
DllStructSetData($Struct, "cyTopHeight", $Area[2])
DllStructSetData($Struct, "cyBottomHeight", $Area[3])
GUISetBkColor($bColor); Must be here!
$Ret = DllCall("dwmapi.dll", "long*", "DwmExtendFrameIntoClientArea", "hwnd", $hWnd, "ptr", DllStructGetPtr($Struct))
If @error Then
Return 0
Else
Return $Ret
EndIf
Else
MsgBox(16, "_Vista_ApplyGlassArea", "Area specified is not an array!")
EndIf
EndFunc ;==>_Vista_ApplyGlassArea
#endregion

[/autoit] [autoit][/autoit] [autoit]

Func _Draw_menus()
_Draw_Menu_ex($FileGUI, 'File', $menuFontSize, $shine3, 0x000000)
_Draw_Menu_ex($EditGUI, 'Edit', $menuFontSize, $shine3, 0x000000)
_Draw_Menu_ex($HelpGUI, 'Help', $menuFontSize, $shine3, 0x000000)
_Draw_Menu_ex($DownGUI, ChrW(9660), $menuFontSize-Round(Sqrt($menuFontSize)), $shine3, 0x555555)
EndFunc

[/autoit] [autoit][/autoit] [autoit]

Func _Draw_Menu_ex($WinHandle, $iCaption, $iSize, $iShine, $iColor)
Local $hDC = _WinAPI_GetDC($WinHandle)
Local $tClientRect = _WinAPI_GetClientRect($WinHandle)
Local $sText = $iCaption
Local $hFont = _WinAPI_CreateFont($iSize, $iSize/2-1, 0, 0, 400, False, False, False, $DEFAULT_CHARSET, _
$OUT_DEFAULT_PRECIS, $CLIP_DEFAULT_PRECIS, $DEFAULT_QUALITY, 0, 'SegoeUI')
_DrawGlowingText($hDC, $sText, $tClientRect, $iShine, $hFont, $iColor)
_WinAPI_DeleteObject($hFont)
_WinAPI_ReleaseDC($WinHandle, $hDC)
EndFunc

[/autoit] [autoit][/autoit] [autoit]

#region making label shine in glass area (Link at the top of the script)
Func _DrawGlowingText($hDC, $sText, $tRc, $iGlowSize = 10, $hFont = 0, $iTextClr = -1)
Local $hCDC
Local $hBrush, $hOldBrush
Local $tRcText
Local $tBI, $tDTO
Local $hDIBBmp, $hOldBmp
Local $hOldFont
Local $tST
Local $iFlags = BitOR($DTT_GLOWSIZE, $DTT_COMPOSITED)

[/autoit] [autoit][/autoit] [autoit]

$hCDC = _WinAPI_CreateCompatibleDC($hDC)

[/autoit] [autoit][/autoit] [autoit]

$tBI = DllStructCreate($tagBITMAPINFO)
DllStructSetData($tBI, "Size", DllStructGetSize($tBI)-4)
DllStructSetData($tBI, "Width", DllStructGetData($tRc, "Right")-DllStructGetData($tRc, "Left"))
DllStructSetData($tBI, "Height", -(DllStructGetData($tRc, "Bottom")-DllStructGetData($tRc, "Top")))
DllStructSetData($tBI, "Planes", 1)
DllStructSetData($tBI, "BitCount", 32)
DllStructSetData($tBI, "Compression", 0) ; BI_RGB

[/autoit] [autoit][/autoit] [autoit]

$hDIBBmp = _WinAPI_CreateDIBSection($hDC, $tBI)
$hOldBmp = _WinAPI_SelectObject($hCDC, $hDIBBmp)
If $hFont Then $hOldFont = _WinAPI_SelectObject($hCDC, $hFont)

[/autoit] [autoit][/autoit] [autoit]

$tDTO = DllStructCreate($tagDTTOPTS)
DllStructSetData($tDTO, "Size", DllStructGetSize($tDTO))

[/autoit] [autoit][/autoit] [autoit]

If $iTextClr <> -1 Then
$iFlags = BitOR($iFlags, $DTT_TEXTCOLOR)
DllStructSetData($tDTO, "clrText", $iTextClr)
EndIf

[/autoit] [autoit][/autoit] [autoit][/autoit] [autoit]

DllStructSetData($tDTO, "Flags", $iFlags)
DllStructSetData($tDTO, "GlowSize", $iGlowSize)

[/autoit] [autoit][/autoit] [autoit]

_WinAPI_DrawThemeTextEx($hTheme, $hCDC, 0, 0, $sText, _
BitOR($DT_SINGLELINE, $DT_CENTER, $DT_VCENTER, $DT_NOPREFIX), $tRc, $tDTO)

[/autoit] [autoit][/autoit] [autoit]

_WinAPI_BitBlt($hDC, DllStructGetData($tRc, "Left"), DllStructGetData($tRc, "Top"), _
DllStructGetData($tRc, "Right")-DllStructGetData($tRc, "Left"), _
DllStructGetData($tRc, "Bottom")-DllStructGetData($tRc, "Top"), $hCDC, 0, 0, 0xCC0020) ; SRCCOPY ;top+Sqrt($menuFontSize)

[/autoit] [autoit][/autoit] [autoit]

_WinAPI_SelectObject($hCDC, $hOldBmp)
If $hFont Then _WinAPI_SelectObject($hCDC, $hOldFont)
_WinAPI_DeleteObject($hDIBBmp)
_WinAPI_DeleteDC($hCDC)
EndFunc

[/autoit] [autoit][/autoit] [autoit]

Func _WinAPI_CreateDIBSection($hDC, Const ByRef $tBmpInfo, $iUsage = 0, $pBits = 0, $hSecond = 0, $iOffset = 0)
Local $aResult = DllCall("gdi32.dll", "hwnd", "CreateDIBSection", "hwnd", $hDC, "ptr", DllStructGetPtr($tBmpInfo), _
"uint", $iUsage, "ptr", $pBits, "hwnd", $hSecond, "uint", $iOffset)

[/autoit] [autoit][/autoit] [autoit]

If @error Then Return SetError(@error, @extended, 0)
If $aResult[0] = 87 Then Return SetError(1, 1, 0); 87 = ERROR_INVALID_PARAMETER
If $aResult[0] = 0 Then Return SetError(1, 2, 0)
Return SetError(0, 0, $aResult[0])
EndFunc

[/autoit] [autoit][/autoit] [autoit]

Func _WinAPI_DrawThemeTextEx($hTheme, $hDC, $iPartId, $iStateId, $sText, $iFlags, ByRef $tRect, Const ByRef $tDTTOPTS)
Local $aResult = DllCall("uxtheme.dll", "int", "DrawThemeTextEx", "ptr", $hTheme, "hwnd", $hDC, "int", $iPartId, "int", $iStateId, _
"wstr", $sText, "int", -1, "uint", $iFlags, "ptr", DllStructGetPtr($tRect), "ptr", DllStructGetPtr($tDTTOPTS))

[/autoit] [autoit][/autoit] [autoit]

If @error Then Return SetError(@error, @extended, 0)
If $aResult[0] <> 0 Then Return SetError(1, 0, 0)
Return SetError(0, 0, $aResult[0] = 0)
EndFunc

[/autoit] [autoit][/autoit] [autoit]

Func _WinAPI_OpenThemeData($hWnd, $sClassList)
Local $aResult = DllCall("uxtheme.dll", "hwnd", "OpenThemeData", "hwnd", $hWnd, "wstr", $sClassList)

[/autoit] [autoit][/autoit] [autoit]

If @error Then Return SetError(@error, @extended, 0)
If $aResult[0] = 0 Then Return SetError(1, 0, 0)
Return SetError(0, 0, $aResult[0])
EndFunc

[/autoit] [autoit][/autoit] [autoit]

Func _WinAPI_CloseThemeData($hTheme)
Local $aResult = DllCall("uxtheme.dll", "int", "CloseThemeData", "hwnd", $hTheme)

[/autoit] [autoit][/autoit] [autoit]

If @error Then Return SetError(@error, @extended, 0)
Return SetError(0, 0, $aResult[0] = 0)
EndFunc
#endregion

[/autoit] [autoit][/autoit] [autoit]

Func MY_PAINT($hWnd, $Msg, $wParam, $lParam)
_Draw_menus()
Return $GUI_RUNDEFMSG
EndFunc

[/autoit] [autoit][/autoit] [autoit]

Func _Create_7Image() ;drawn by myself xP
_GDIPlus_Startup()
Local $hGraphic = _GDIPlus_GraphicsCreateFromHWND($controlGui)
Local $hbitmap = _GDIPlus_BitmapCreateFromGraphics($iwidth, $iheight, $hGraphic)
Local $backbuffer = _GDIPlus_ImageGetGraphicsContext($hbitmap)
Local $LetterSize = 36
Local $Letter = '7'
Local $hbrush = _GDIPlus_BrushCreateSolid(0xFF152a3d)
Local $hbrushB = _GDIPlus_BrushCreateSolid(0xFF000000)
Local $hbrush2 = _GDIPlus_BrushCreateSolid(0x3A152a3d)
Local $hbrush3 = _GDIPlus_BrushCreateSolid(0x28FFFFFF)
Local $hFormat = _GDIPlus_StringFormatCreate ()
Local $hFamily = _GDIPlus_FontFamilyCreate ("Times New Roman")
Local $hPen = _GDIPlus_PenCreate (0xFF454545)
Local $hFont = _GDIPlus_FontCreate ($hFamily, $LetterSize, 1)
Local $tLayout
Local $tLayout2

[/autoit] [autoit][/autoit] [autoit]

#region malkey's gradient example ;creating gradient
Local $aFact[4] = [0, 0.3, 0.6, 1.0]
Local $aPosit[4] = [0.0, 0.3, 0.6, 1.0]
Local $hBrushLin2 = gdiplus_CreateLineBrushFromRect($iX, $iY, $iWidth, $iHeight, $aFact, $aPosit, _
0xFF5078fb, 0xFF91e9ff, 0x00000002, 1)
_GDIPlus_GraphicsFillRect($backbuffer, $iX, $iY, $iWidth, $iHeight, $hBrushLin2)
#endregion

[/autoit] [autoit][/autoit] [autoit]

Local $StartNum = 1 ;creating little pixels to add texture
for $j = 1 to 48
for $i = $StartNum to 48 step 3
_GDIPlus_GraphicsFillRect($backbuffer, $i-1, $j-1, 1, 1, $hbrush2)
Next
$StartNum += 1
If $StartNum > 3 then $StartNum = 1
Next
Local $3D_Depth = 3
$tLayout2 = _GDIPlus_RectFCreate ($iX+7, $iY-1, $iWidth, $iHeight)
_GDIPlus_GraphicsDrawStringEx ($backbuffer, $Letter, $hFont, $tLayout2, $hFormat, $hbrush2) ;creating shadow under character
For $i = 1 to $3D_Depth
$tLayout = _GDIPlus_RectFCreate ($iX+6-$i, $iY-$i-2, $iWidth-4, $iHeight+4)
If $i = $3D_Depth then
_GDIPlus_GraphicsDrawStringEx ($backbuffer, $Letter, $hFont, $tLayout, $hFormat, $hBrush) ;creating character
Else
_GDIPlus_GraphicsDrawStringEx ($backbuffer, $Letter, $hFont, $tLayout, $hFormat, $hBrushB) ;creating character depth
EndIf
Next

[/autoit] [autoit][/autoit] [autoit]

Local $i_a = 48 ;ellipse points
Local $i_b = 32
For $j = 1 to 48
For $i = 1 to 48
if $i >= Sqrt($i_a^2-$i_a^2*$j^2/$i_b^2) then _GDIPlus_GraphicsFillRect($backbuffer, 48-$i, 48-$j, 1, 1, $hbrush3) ;creating gloss with ellipse equation
Next
Next

[/autoit] [autoit][/autoit] [autoit]

_GDIPlus_GraphicsDrawRect($backbuffer, $iX, $iY, $iWidth-1, $iHeight-1, $hPen) ;boxing entire image with dark grey line

[/autoit] [autoit][/autoit] [autoit]

Local $GC = _GDIPlus_ImageGetGraphicsContext($hbitmap)
Local $newBmp = _GDIPlus_BitmapCreateFromGraphics($iwidth, $iheight, $GC)
Local $newGC = _GDIPlus_ImageGetGraphicsContext($newBmp)
_GDIPlus_GraphicsDrawImageRect($newGC, $hbitmap, 0, 0, $iwidth, $iheight)
_GDIPlus_ImageSaveToFile($newBmp, $temp_image) ;saving created image - it's easier to show image and leave it there, than redrawing this entire thing
;when GID+ gets disappeared
_WinAPI_DeleteObject($hbitmap) ;disposing all the unneeded stuff
_GDIPlus_GraphicsDispose($backbuffer)
_GDIPlus_GraphicsDispose($GC)
_GDIPlus_GraphicsDispose($newGC)
_GDIPlus_BitmapDispose($newBmp)
_GDIPlus_BrushDispose($hBrushLin2)
_GDIPlus_BrushDispose($hbrush)
_GDIPlus_BrushDispose($hbrushB)
_GDIPlus_BrushDispose($hbrush2)
_GDIPlus_BrushDispose($hbrush3)
_GDIPlus_PenDispose ($hPen)
_GDIPlus_FontDispose ($hFont)
_GDIPlus_FontFamilyDispose ($hFamily)
_GDIPlus_StringFormatDispose ($hFormat)
_GDIPlus_GraphicsDispose($hGraphic)
_GDIPlus_ImageDispose($temp_image)
_GDIPlus_Shutdown()
EndFunc

[/autoit] [autoit][/autoit] [autoit]

#region drawing gradient by Malkey (link at the top of the script)
Func gdiplus_CreateLineBrushFromRect($iX, $iY, $iWidth, $iHeight, $aFactors, $aPositions, _
$iArgb1 = 0xFF0000FF, $iArgb2 = 0xFFFF0000, $LinearGradientMode = 0x00000001, $WrapMode = 0)

[/autoit] [autoit][/autoit] [autoit]

Local $tRect, $pRect, $aRet, $tFactors, $pFactors, $tPositions, $pPositions, $iCount

[/autoit] [autoit][/autoit] [autoit]

If $iArgb1 = -1 Then $iArgb1 = 0xFF0000FF
If $iArgb2 = -1 Then $iArgb2 = 0xFFFF0000
If $LinearGradientMode = -1 Then $LinearGradientMode = 0x00000001
If $WrapMode = -1 Then $WrapMode = 1

[/autoit] [autoit][/autoit] [autoit]

$tRect = DllStructCreate("float X;float Y;float Width;float Height")
$pRect = DllStructGetPtr($tRect)
DllStructSetData($tRect, "X", $iX)
DllStructSetData($tRect, "Y", $iY)
DllStructSetData($tRect, "Width", $iWidth)
DllStructSetData($tRect, "Height", $iHeight)

[/autoit] [autoit][/autoit] [autoit]

;Note: Withn _GDIPlus_Startup(), $ghGDIPDll is defined
$aRet = DllCall($ghGDIPDll, "int", "GdipCreateLineBrushFromRect", "ptr", $pRect, "int", $iArgb1, _
"int", $iArgb2, "int", $LinearGradientMode, "int", $WrapMode, "int*", 0)

[/autoit] [autoit][/autoit] [autoit]

If IsArray($aFactors) = 0 Then Dim $aFactors[4] = [0.0, 0.4, 0.6, 1.0]
If IsArray($aPositions) = 0 Then Dim $aPositions[4] = [0.0, 0.3, 0.7, 1.0]

[/autoit] [autoit][/autoit] [autoit]

$iCount = UBound($aPositions)
$tFactors = DllStructCreate("float[" & $iCount & "]")
$pFactors = DllStructGetPtr($tFactors)
For $iI = 0 To $iCount - 1
DllStructSetData($tFactors, 1, $aFactors[$iI], $iI + 1)
Next
$tPositions = DllStructCreate("float[" & $iCount & "]")
$pPositions = DllStructGetPtr($tPositions)
For $iI = 0 To $iCount - 1
DllStructSetData($tPositions, 1, $aPositions[$iI], $iI + 1)
Next

[/autoit] [autoit][/autoit] [autoit]

$hStatus = DllCall($ghGDIPDll, "int", "GdipSetLineBlend", "hwnd", $aRet[6], _
"ptr", $pFactors, "ptr", $pPositions, "int", $iCount)
Return $aRet[6] ; Handle of Line Brush
EndFunc ;==>Gdiplus_CreateLineBrushFromRect
#endregion

[/autoit] [autoit][/autoit] [autoit]

Func _CleanUp()
_WinAPI_CloseThemeData($hTheme)
FileDelete($temp_image)
EndFunc

[/autoit]
